前言
最近有个项目需求是实现前端页面可以对word文档进行编辑，并且可以进行保存，于是一顿搜索，找到开源第三方onlyoffice，实际上onlyOffice有很多功能，例如文档转化、多人协同编辑文档、文档打印等，我们只用到了文档编辑功能。
1、onlyoffice的部署
部署分为docker部署方式和本地直接安装的方式，比较两种部署方式，docker是比较简单的一种，因为只要拉取相关镜像，然后启动时配置好对应的配置文件即可。
由于搜索的时候先看到的是linux本地部署，所以采用了第二种方式，下面我将给出两个参考博客：
docker的方式：（我未进行尝试，对于是否能成功是不知的）
“https://blog.csdn.net/wangchange/article/details/140185623
ubuntu部署方式：（我按照这个方式走下来是可以走通的）
“https://blog.csdn.net/qq_36437991/article/details/139859247
2、代码逻辑开发
前端使用的element框架vue版本，后端采用springboot
2.1、前端代码
参考官方文档API
“https://api.onlyoffice.com/docs/docs-api/get-started/basic-concepts/
参考文档
“https://api.onlyoffice.com/docs/docs-api/usage-api/advanced-parameters/
记得添加下面的js文件
<div id="placeholder"></div><script type="text/javascript" src="https://documentserver/web-apps/apps/api/documents/api.js"></script>记得将documentserver替换为部署onlyoffice的地址。
const config = { document: { mode: 'edit', fileType: 'docx', key: String( Math.floor(Math.random() * 10000)), title: route.query.name + '.docx', url: import.meta.env.VITE_APP_API_URL+`/getFile/${route.query.id}`, permissions: { comment: true, download: true, modifyContentControl: true, modifyFilter: true, edit: true, fillForms: true, review: true, }, }, documentType: 'word', editorConfig: { user: { id: 'liu', name: 'liu', }, // 隐藏插件菜单 customization: { plugins: false, forcesave: true, }, lang: 'zh', // callbackUrl: `${import.meta.env.VITE_APP_API_URL} +'/callback' `, callbackUrl: import.meta.env.VITE_APP_API_URL+`/callback`, }, height: '100%', width: '100%', }newwindow.DocsAPI.DocEditor('onlyoffice', config)其中import.meta.env.VITE_APP_API_URL为你实际的后端地址，http：ip：端口号/访问路径，例如我们就是：http:192.168.123.123:8089/getFile/12，其中12为会议号，用于得到文件地址。
其中import.meta.env.VITE_APP_API_URL+/callback为回调函数，即文档有什么操作后，都会通过这个函数进行回调，例如：编辑保存操作。
2.2、后端代码
pom依赖
<!-- httpclient start --><dependency> <groupId>org.apache.httpcomponents</groupId> <artifactId>httpclient</artifactId></dependency><dependency> <groupId>org.apache.httpcomponents</groupId> <artifactId>httpmime</artifactId></dependency>package com.ruoyi.web.controller.meetingminutes.onlyoffice;/** * @Author 不要有情绪的 ljy * @Date 2024/10/31 20:26 * @Description: */import com.ruoyi.system.domain.MeetingTable;import com.ruoyi.system.service.IMeetingTableService;import com.ruoyi.web.controller.meetingminutes.utils.HttpsKitWithProxyAuth;import io.swagger.annotations.Api;import io.swagger.annotations.ApiOperation;import lombok.Getter;import lombok.Setter;import org.springframework.beans.factory.annotation.Autowired;import org.springframework.http.HttpHeaders;import org.springframework.http.HttpStatus;import org.springframework.http.MediaType;import org.springframework.http.ResponseEntity;import org.springframework.web.bind.annotation.*;import javax.servlet.http.HttpServletResponse;import java.io.*;import java.net.URISyntaxException;import java.net.URLEncoder;import java.util.Collections;/** * */@Api(value = "OnlyOfficeController")@RestControllerpublicclass OnlyOfficeController { @Autowired private IMeetingTableService meetingTableService; //这里仅写死路径测试 // private String meetingMinutesFilePath = "C:\\Users\\qrs-ljy\\Desktop\\王勋\\c1f15837-d8b4-4380-8161-b85e970ad174\\123435_会议纪要（公开）.docx"; //这里仅写死路径测试 private String meetingMinutesFilePath; /** * 传入参数 会议id，得到会议纪要文件流，并进行打开 * * @param response * @param meeting_id * @return * @throws IOException */ @ApiOperation(value = "OnlyOffice") @GetMapping("/getFile/{meeting_id}") public ResponseEntity<byte[]> getFile(HttpServletResponse response, @PathVariable Long meeting_id) throws IOException { MeetingTable meetingTable = meetingTableService.selectMeetingTableById(meeting_id); meetingMinutesFilePath = meetingTable.getMeetingMinutesFilePath();if (meetingMinutesFilePath == null || "".equals(meetingMinutesFilePath)) { returnnull; //当会议纪要文件为空的时候，就返回null } File file = new File(meetingMinutesFilePath); FileInputStream fileInputStream = null; InputStream fis = null; try { fileInputStream = new FileInputStream(file); fis = new BufferedInputStream(fileInputStream); byte[] buffer = newbyte[fis.available()]; fis.read(buffer); fis.close(); HttpHeaders headers = new HttpHeaders(); headers.setContentType(MediaType.APPLICATION_OCTET_STREAM); // 替换为实际的文档名称 headers.setContentDispositionFormData("attachment", URLEncoder.encode(file.getName(), "UTF-8")); returnnew ResponseEntity<>(buffer, headers, HttpStatus.OK); } catch (Exception e) { thrownew RuntimeException("e -> ", e); } finally { try {if (fis != null) fis.close(); } catch (Exception e) { } try {if (fileInputStream != null) fileInputStream.close(); } catch (Exception e) { } } } @CrossOrigin(origins = "*", methods = {RequestMethod.GET, RequestMethod.POST, RequestMethod.OPTIONS}) @PostMapping("/callback") public ResponseEntity<Object> handleCallback(@RequestBody CallbackData callbackData) { //状态监听 //参见https://api.onlyoffice.com/editors/callback Integer status = callbackData.getStatus(); switch (status) { case1: { //document is being edited 文档已经被编辑break; } case2: { //document is ready for saving,文档已准备好保存 System.out.println("document is ready for saving"); String url = callbackData.getUrl(); try { saveFile(url); //保存文件 } catch (Exception e) { System.out.println("保存文件异常"); } System.out.println("save success.");break; } case3: { //document saving error has occurred,保存出错 System.out.println("document saving error has occurred,保存出错");break; } case4: { //document is closed with no changes,未保存退出 System.out.println("document is closed with no changes,未保存退出");break; } case6: { //document is being edited, but the current document state is saved,编辑保存 String url = callbackData.getUrl(); try { saveFile(url); //保存文件 } catch (Exception e) { System.out.println("保存文件异常"); } System.out.println("save success."); } case7: { //error has occurred while force saving the document. 强制保存文档出错 System.out.println("error has occurred while force saving the document. 强制保存文档出错"); } default: { } } // 返回响应return ResponseEntity.<Object>ok(Collections.singletonMap("error", 0)); } public void saveFile(String downloadUrl) throws URISyntaxException, IOException { HttpsKitWithProxyAuth.downloadFile(downloadUrl, meetingMinutesFilePath); } @Setter @Getter publicstaticclass CallbackData { /** * 用户与文档的交互状态。0：用户断开与文档共同编辑的连接；1：新用户连接到文档共同编辑；2：用户单击强制保存按钮 */// @IsArray()// actions?:IActions[] =null; /** * 字段已在 4.2 后版本废弃，请使用 history 代替 */ Object changeshistory; /** * 文档变更的历史记录，仅当 status 等于 2 或者 3 时该字段才有值。其中的 serverVersion 字段也是 refreshHistory 方法的入参 */ Object history; /** * 文档编辑的元数据信息，用来跟踪显示文档更改记录，仅当 status 等于 2 或者 2 时该字段才有值。该字段也是 setHistoryData（显示与特定文档版本对应的更改，类似 Git 历史记录）方法的入参 */ String changesurl; /** * url 字段下载的文档扩展名，文件类型默认为 OOXML 格式，如果启用了 assemblyFormatAsOrigin（https://api.onlyoffice.com/editors/save#assemblyFormatAsOrigin） 服务器设置则文件以原始格式保存 */ String filetype; /** * 文档强制保存类型。0：对命令服务（https://api.onlyoffice.com/editors/command/forcesave）执行强制保存；1：每次保存完成时都会执行强制保存请求，仅设置 forcesave 等于 true 时生效；2：强制保存请求由计时器使用服务器中的设置执行。该字段仅 status 等于 7 或者 7 时才有值 */ Integer forcesavetype; /** * 文档标识符，类似 id，在 Onlyoffice 服务内部唯一 */ String key; /** * 文档状态。1：文档编辑中；2：文档已准备好保存；3：文档保存出错；4：文档没有变化无需保存；6：正在编辑文档，但保存了当前文档状态；7：强制保存文档出错 */ Integer status; /** * 已编辑文档的链接，可以通过它下载到最新的文档，仅当 status 等于 2、3、6 或 7 时该字段才有值 */ String url; /** * 自定义参数，对应指令服务的 userdata 字段 */ Object userdata; /** * 打开文档进行编辑的用户标识列表，当文档被修改时，该字段将返回最后编辑文档的用户标识符，当 status 字段等于 2 或者 6 时有值 */ String[] users; /** * 最近保存时间 */ String lastsave; /** * 加密令牌 */ String token; }}代码中使用了其他类，这儿贴出（我也是参考的别人的博客，后面会给出参考链接）
package com.ruoyi.web.controller.meetingminutes.utils;/** * @Author 不要有情绪的 ljy * @Date 2024/10/31 20:34 * @Description: */import java.io.File;import java.io.FileOutputStream;import java.io.IOException;import java.io.InputStream;import java.io.InterruptedIOException;import java.net.Authenticator;import java.net.InetSocketAddress;import java.net.MalformedURLException;import java.net.PasswordAuthentication;import java.net.Proxy;import java.net.Socket;import java.net.UnknownHostException;import java.security.KeyManagementException;import java.security.KeyStoreException;import java.security.NoSuchAlgorithmException;import java.security.cert.CertificateException;import java.security.cert.X509Certificate;import java.util.ArrayList;import java.util.HashMap;import java.util.List;import java.util.Map;import java.util.TimerTask;import java.util.concurrent.Executors;import java.util.concurrent.ScheduledExecutorService;import java.util.concurrent.TimeUnit;import javax.net.ssl.SSLContext;import javax.net.ssl.SSLException;import javax.net.ssl.SSLHandshakeException;import org.apache.commons.codec.CharEncoding;import org.apache.commons.io.IOUtils;import org.apache.http.Consts;import org.apache.http.HttpEntity;import org.apache.http.HttpEntityEnclosingRequest;import org.apache.http.HttpHost;import org.apache.http.HttpRequest;import org.apache.http.NameValuePair;import org.apache.http.NoHttpResponseException;import org.apache.http.auth.AUTH;import org.apache.http.auth.AuthState;import org.apache.http.auth.MalformedChallengeException;import org.apache.http.auth.UsernamePasswordCredentials;import org.apache.http.client.HttpRequestRetryHandler;import org.apache.http.client.config.RequestConfig;import org.apache.http.client.entity.UrlEncodedFormEntity;import org.apache.http.client.methods.CloseableHttpResponse;import org.apache.http.client.methods.HttpGet;import org.apache.http.client.methods.HttpPost;import org.apache.http.client.methods.HttpPut;import org.apache.http.client.protocol.HttpClientContext;import org.apache.http.config.Registry;import org.apache.http.config.RegistryBuilder;import org.apache.http.conn.ConnectTimeoutException;import org.apache.http.conn.socket.ConnectionSocketFactory;import org.apache.http.conn.socket.LayeredConnectionSocketFactory;import org.apache.http.conn.socket.PlainConnectionSocketFactory;import org.apache.http.conn.ssl.NoopHostnameVerifier;import org.apache.http.conn.ssl.SSLConnectionSocketFactory;import org.apache.http.conn.ssl.TrustStrategy;import org.apache.http.entity.ContentType;import org.apache.http.entity.StringEntity;import org.apache.http.entity.mime.MultipartEntityBuilder;import org.apache.http.entity.mime.content.InputStreamBody;import org.apache.http.entity.mime.content.StringBody;import org.apache.http.impl.auth.BasicScheme;import org.apache.http.impl.client.CloseableHttpClient;import org.apache.http.impl.client.HttpClients;import org.apache.http.impl.conn.PoolingHttpClientConnectionManager;import org.apache.http.message.BasicHeader;import org.apache.http.message.BasicNameValuePair;import org.apache.http.protocol.HttpContext;import org.apache.http.ssl.SSLContextBuilder;import org.slf4j.Logger;import org.slf4j.LoggerFactory;/** * httpclient Sock5支持参考：https://blog.csdn.net/weixin_34075268/article/details/92040047 * @author liujh * */publicclass HttpsKitWithProxyAuth { privatestatic Logger logger = LoggerFactory.getLogger(HttpsKitWithProxyAuth.class); privatestaticfinalint CONNECT_TIMEOUT = 10000;// 设置连接建立的超时时间为10000ms privatestaticfinalint SOCKET_TIMEOUT = 30000; // 多少时间没有数据传输 privatestaticfinalint HttpIdelTimeout = 30000;//空闲时间 privatestaticfinalint HttpMonitorInterval = 10000;//多久检查一次 privatestaticfinalint MAX_CONN = 200; // 最大连接数 privatestaticfinalint Max_PRE_ROUTE = 200; //设置到路由的最大连接数, privatestatic CloseableHttpClient httpClient; // 发送请求的客户端单例 privatestatic PoolingHttpClientConnectionManager manager; // 连接池管理类 privatestatic ScheduledExecutorService monitorExecutor; privatestaticfinal String APPLICATION_FORM_URLENCODED = "application/x-www-form-urlencoded"; privatestaticfinal String APPLICATION_JSON = "application/json"; privatestaticfinal String USER_AGENT = "Mozilla/5.0 (Windows NT 6.1; WOW64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/73.0.3683.86 Safari/537.36"; privatestaticfinal Object syncLock = new Object(); // 相当于线程锁,用于线程安全 /** * 代理相关的变量, */ publicstaticfinal String HTTP = "http";//proxyType的取值之一http publicstaticfinal String SOCKS = "socks";//proxyType的取值之一socks privatestaticboolean needProxy = false; //是否需要代理连接 privatestaticboolean needLogin = false;//代理连接是否需要账号和密码，为true时填上proxyUsername和proxyPassword privatestatic String proxyType = HTTP; //代理类型,http,socks分别为http代理和sock5代理 privatestatic String proxyHost = "127.0.0.1"; //代理IP privatestaticint proxyPort = 1080; //代理端口 privatestatic String proxyUsername = "sendi";//代理账号，needLogin为true时不能为空 privatestatic String proxyPassword = "123456";//代理密码，needLogin为true时不能为空 privatestatic RequestConfig requestConfig = RequestConfig.custom() .setConnectionRequestTimeout(CONNECT_TIMEOUT) .setConnectTimeout(CONNECT_TIMEOUT) //.setCookieSpec(CookieSpecs.IGNORE_COOKIES) .setSocketTimeout(SOCKET_TIMEOUT).build(); static { /** * Sock5代理账号和密码设置 * 如果账号和密码都不为空表示需要账号密码认证,因为这个是全局生效，因此在这里直接设置 * 可通过Authenticator.setDefault(null)取消全局配置 * Authenticator.setDefault(Authenticator a)关于a参数的说明如下： * (The authenticator to be set. If a is {@code null} then any previously set authenticator is removed.) */if(needProxy && SOCKS.equals(proxyType) && needLogin){ //用户名和密码验证 Authenticator.setDefault(new Authenticator(){ protected PasswordAuthentication getPasswordAuthentication(){ PasswordAuthentication p = new PasswordAuthentication(proxyUsername, proxyPassword.toCharArray());return p; } }); } } /** * 设置代理信息，可以在发请求前进行调用，用于替换此类中的代理相关的变量,全局设置一次就可 * needProxy 是否需要代理连接 * needLogin 代理连接是否需要账号和密码，为true时填上proxyUsername和proxyPassword * proxyType 代理类型,http,socks分别为http代理和sock5代理 * proxyHost 代理IP * proxyPort 代理端口 * proxyUsername 代理账号，needLogin为true时不能为空 * proxyPassword 代理密码，needLogin为true时不能为空 */ public static void setProxy(boolean needProxy,boolean needLogin,String proxyType,String proxyHost,int proxyPort,String proxyUserName,String proxyPassword){ HttpsKitWithProxyAuth.needProxy = needProxy; HttpsKitWithProxyAuth.needLogin = needLogin; HttpsKitWithProxyAuth.proxyType = proxyType; HttpsKitWithProxyAuth.proxyHost = proxyHost; HttpsKitWithProxyAuth.proxyPort = proxyPort; HttpsKitWithProxyAuth.proxyUsername = proxyUserName; HttpsKitWithProxyAuth.proxyPassword = proxyPassword; } private static CloseableHttpClient getHttpClient() {if (httpClient == null) { // 多线程下多个线程同时调用getHttpClient容易导致重复创建httpClient对象的问题,所以加上了同步锁 synchronized (syncLock) {if (httpClient == null) { try { httpClient = createHttpClient(); } catch (KeyManagementException e) { logger.error("error",e); } catch (NoSuchAlgorithmException e) { logger.error("error",e); } catch (KeyStoreException e) { logger.error("error",e); } // 开启监控线程,对异常和空闲线程进行关闭 monitorExecutor = Executors.newScheduledThreadPool(1); monitorExecutor.scheduleAtFixedRate(new TimerTask() { @Override public void run() { // 关闭异常连接 manager.closeExpiredConnections(); // 关闭5s空闲的连接 manager.closeIdleConnections(HttpIdelTimeout,TimeUnit.MILLISECONDS); //logger.info(manager.getTotalStats().toString()); //logger.info("close expired and idle for over "+HttpIdelTimeout+"ms connection"); } }, HttpMonitorInterval, HttpMonitorInterval, TimeUnit.MILLISECONDS); } } }return httpClient; } /** * 构建httpclient实例 * @return * @throws KeyStoreException * @throws NoSuchAlgorithmException * @throws KeyManagementException */ private static CloseableHttpClient createHttpClient() throws NoSuchAlgorithmException, KeyStoreException, KeyManagementException { SSLContextBuilder builder = new SSLContextBuilder(); // 全部信任 不做身份鉴定 builder.loadTrustMaterial(null, new TrustStrategy() { @Override public boolean isTrusted(X509Certificate[] x509Certificates, String s) throws CertificateException { returntrue; } }); ConnectionSocketFactory plainSocketFactory = null; LayeredConnectionSocketFactory sslSocketFactory = null; /** * 如果需要进行Sock5代理访问开放如下代码 * */if(needProxy && SOCKS.endsWith(proxyType)){ plainSocketFactory = new MyConnectionSocketFactory(); sslSocketFactory = new MySSLConnectionSocketFactory(builder.build()); }else { plainSocketFactory = PlainConnectionSocketFactory.getSocketFactory(); sslSocketFactory = new SSLConnectionSocketFactory(builder.build(), NoopHostnameVerifier.INSTANCE); } Registry<ConnectionSocketFactory> registry = RegistryBuilder .<ConnectionSocketFactory> create() .register("http", plainSocketFactory) .register("https", sslSocketFactory).build(); manager = new PoolingHttpClientConnectionManager(registry); // 设置连接参数 manager.setMaxTotal(MAX_CONN); // 最大连接数 manager.setDefaultMaxPerRoute(Max_PRE_ROUTE); // 路由最大连接数 // 请求失败时,进行请求重试 HttpRequestRetryHandler handler = new HttpRequestRetryHandler() { @Override public boolean retryRequest(IOException e, int i, HttpContext httpContext) {if (i > 3) { // 重试超过3次,放弃请求 logger.error("retry has more than 3 time, give up request"); returnfalse; }if (e instanceof NoHttpResponseException) { // 服务器没有响应,可能是服务器断开了连接,应该重试 logger.error("receive no response from server, retry"); returntrue; }if (e instanceof SSLHandshakeException) { // SSL握手异常 logger.error("SSL hand shake exception"); returnfalse; }if (e instanceof InterruptedIOException) { // 超时 logger.error("InterruptedIOException"); returnfalse; }if (e instanceof UnknownHostException) { // 服务器不可达 logger.error("server host unknown"); returnfalse; }if (e instanceof ConnectTimeoutException) { // 连接超时 logger.error("Connection Time out"); returnfalse; }if (e instanceof SSLException) { logger.error("SSLException"); returnfalse; } HttpClientContext context = HttpClientContext.adapt(httpContext); HttpRequest request = context.getRequest();if (!(request instanceof HttpEntityEnclosingRequest)) { // 如果请求不是关闭连接的请求 returntrue; } returnfalse; } }; CloseableHttpClient client = null; /** * 如果需要进行HTTPS代理访问开放如下代码 * */if(needProxy && HTTP.endsWith(proxyType)){ client = HttpClients.custom() .setConnectionManager(manager) .setProxy(new HttpHost(proxyHost, proxyPort)) .setRetryHandler(handler).build(); }else { client = HttpClients.custom() .setConnectionManager(manager) .setRetryHandler(handler).build(); }return client; } public static String get(String url) {return get(url, null); } public static String get(String url,Map<String,Object> headerParams) { HttpGet httpGet = new HttpGet(url); httpGet.setHeader("User-Agent",USER_AGENT); httpGet.setConfig(requestConfig);if(headerParams != null && headerParams.size()>0){for(String headerName : headerParams.keySet()) { httpGet.setHeader(headerName,headerParams.get(headerName)+""); } } CloseableHttpResponse response = null; InputStream in = null; String result = null; try { HttpClientContext ctx = createContext(); response = getHttpClient().execute(httpGet,ctx); HttpEntity entity = response.getEntity();if (entity != null) {in = entity.getContent(); result = IOUtils.toString(in, "utf-8"); } } catch (Exception e) { logger.error("error",e); } finally { try {if (in != null) in.close(); } catch (IOException e) { logger.error("error",e); } try {if (response != null) response.close(); } catch (IOException e) { logger.error("error",e); } }return result; } public static String postJson(String url,Map<String,Object> requestParams) {return postJson(url, JsonUtil.toJSONString(requestParams)); } public static String postJson(String url,Map<String,Object> requestParams,Map<String,String> headerParams) {return postJson(url, JsonUtil.toJSONString(requestParams),headerParams); } public static String postJson(String url,String requestParamStr) {return postJson(url, requestParamStr, null); } /** * PUT方式调用http请求方法 * @param url * @param requestParamStr * @param headerParams * @return */ public static String put(String url,String requestParamStr,Map<String,String> headerParams) { HttpPut httpput = new HttpPut(url); httpput.setHeader("Content-Type", APPLICATION_JSON+";charset=" + CharEncoding.UTF_8); httpput.setHeader("Accept",APPLICATION_JSON+";charset=" +CharEncoding.UTF_8); httpput.setHeader("User-Agent",USER_AGENT);if(headerParams != null && headerParams.size()>0){for(String headerName : headerParams.keySet()) { httpput.setHeader(headerName,headerParams.get(headerName)+""); } } StringEntity se = new StringEntity(requestParamStr,CharEncoding.UTF_8); se.setContentType(APPLICATION_JSON+";charset=" +CharEncoding.UTF_8); httpput.setEntity(se); httpput.setConfig(requestConfig); CloseableHttpResponse response = null; InputStream in = null; String result = null; try { HttpClientContext ctx = createContext(); response = getHttpClient().execute(httpput,ctx); HttpEntity entity = response.getEntity();if (entity != null) {in = entity.getContent(); result = IOUtils.toString(in, "utf-8"); } } catch (Exception e) { logger.error("error",e); } finally { try {if (in != null) in.close(); } catch (IOException e) { logger.error("error",e); } try {if (response != null) response.close(); } catch (IOException e) { logger.error("error",e); } }return result; } /** * 创建一个HttpClientContext * @return * @throws MalformedChallengeException */ public static HttpClientContext createContext() throws MalformedChallengeException{ HttpClientContext ctx = HttpClientContext.create(); /** * 如果需要进行Sock5代理访问 */if(needProxy && SOCKS.endsWith(proxyType)){ InetSocketAddress socksaddr = new InetSocketAddress(proxyHost,proxyPort); ctx.setAttribute("socks.address", socksaddr); }else{ /** * 如果需要进行HTTPS代理访问开放如下代码 */if(needProxy && HTTP.endsWith(proxyType)){ /** * 代理连接认证如果需要认证账号和密码时处理 */if(needLogin){ AuthState authState = new AuthState(); BasicScheme basicScheme = new BasicScheme(); basicScheme.processChallenge(new BasicHeader(AUTH.PROXY_AUTH, "BASIC realm=default")); authState.update(basicScheme, new UsernamePasswordCredentials(proxyUsername, proxyPassword)); ctx.setAttribute(HttpClientContext.PROXY_AUTH_STATE, authState); } } }return ctx; } public static String postJson(String url,String requestParamStr,Map<String,String> headerParams) { HttpPost httppost = new HttpPost(url); httppost.setHeader("Content-Type", APPLICATION_JSON+";charset=" + CharEncoding.UTF_8); httppost.setHeader("Accept",APPLICATION_JSON+";charset=" +CharEncoding.UTF_8); httppost.setHeader("User-Agent",USER_AGENT);if(headerParams != null && headerParams.size()>0){for(String headerName : headerParams.keySet()) { httppost.setHeader(headerName,headerParams.get(headerName)+""); } } StringEntity se = new StringEntity(requestParamStr,CharEncoding.UTF_8); se.setContentType(APPLICATION_JSON+";charset=" +CharEncoding.UTF_8); httppost.setEntity(se); httppost.setConfig(requestConfig); CloseableHttpResponse response = null; InputStream in = null; String result = null; try { HttpClientContext ctx = createContext(); response = getHttpClient().execute(httppost,ctx); HttpEntity entity = response.getEntity();if (entity != null) {in = entity.getContent(); result = IOUtils.toString(in, "utf-8"); } } catch (Exception e) { logger.error("error",e); } finally { try {if (in != null) in.close(); } catch (IOException e) { logger.error("error",e); } try {if (response != null) response.close(); } catch (IOException e) { logger.error("error",e); } }return result; } //requestParamStr---------->>> name=test&age=12 public static String postFormUrlencoded(String url,String requestParamStr) {return postFormUrlencoded(url, requestParamStr ,null); } public static String postFormUrlencoded(String url,String requestParamStr,Map<String,Object> headerParams) { Map<String,String> requestParams = new HashMap<String,String>(); String[] strs = requestParamStr.split("&");for(String str : strs) { String[] keyValues = str.split("=");if(keyValues.length == 2) { requestParams.put(keyValues[0], keyValues[1]); } }return postFormUrlencoded(url, requestParams,headerParams); } public static String postFormUrlencoded(String url,Map<String,String> requestParams) {return postFormUrlencoded(url,requestParams,null); } public static String postFormUrlencoded(String url,Map<String,String> requestParams,Map<String,Object> headerParams) { HttpPost httppost = new HttpPost(url); //application/json httppost.setHeader("Content-Type", APPLICATION_FORM_URLENCODED+";charset=" + CharEncoding.UTF_8); httppost.setHeader("Accept",APPLICATION_JSON+";charset=" +CharEncoding.UTF_8); httppost.setHeader("User-Agent",USER_AGENT);if(headerParams != null && headerParams.size()>0){for(String headerName : headerParams.keySet()) { httppost.setHeader(headerName,headerParams.get(headerName)+""); } } List<NameValuePair> formparams = new ArrayList<NameValuePair>();for(String keyStr : requestParams.keySet()) { formparams.add(new BasicNameValuePair(keyStr, requestParams.get(keyStr))); } UrlEncodedFormEntity uefe = new UrlEncodedFormEntity(formparams, Consts.UTF_8); httppost.setEntity(uefe); httppost.setConfig(requestConfig); CloseableHttpResponse response = null; InputStream in = null; String result = null; try { HttpClientContext ctx = createContext(); response = getHttpClient().execute(httppost,ctx); HttpEntity entity = response.getEntity();if (entity != null) {in = entity.getContent(); result = IOUtils.toString(in, "utf-8"); } } catch (Exception e) { logger.error("error",e); } finally { try {if (in != null) in.close(); } catch (IOException e) { logger.error("error",e); } try {if (response != null) response.close(); } catch (IOException e) { logger.error("error",e); } }return result; } //文件上传的通用方法例子测试, 除了file部分参数外，写死了格外的字段参数如scene,output，后台将接收到file,scene,output三个参数，可以根据需求修改 public static String postFormMultipart(String url,InputStream fin,String originalFilename) { HttpPost httppost = new HttpPost(url); httppost.setConfig(requestConfig); InputStreamBody bin = new InputStreamBody(fin, originalFilename); MultipartEntityBuilder multipartEntityBuilder = MultipartEntityBuilder.create(); multipartEntityBuilder.addPart("file",bin); multipartEntityBuilder.addPart("fileName",new StringBody(originalFilename,ContentType.TEXT_PLAIN)); multipartEntityBuilder.addPart("fileSize",new StringBody("1024",ContentType.TEXT_PLAIN)); multipartEntityBuilder.addPart("scene", new StringBody("default",ContentType.TEXT_PLAIN)); multipartEntityBuilder.addPart("output", new StringBody("json2",ContentType.TEXT_PLAIN)); HttpEntity reqEntity = multipartEntityBuilder.build(); httppost.setEntity(reqEntity); CloseableHttpResponse response = null; InputStream in = null; String result = null; try { HttpClientContext ctx = createContext(); response = getHttpClient().execute(httppost,ctx); HttpEntity entity = response.getEntity();if (entity != null) {in = entity.getContent(); result = IOUtils.toString(in, "utf-8"); } } catch (Exception e) { logger.error("error",e); } finally { try {if (in != null) in.close(); } catch (IOException e) { logger.error("error",e); } try {if (response != null) response.close(); } catch (IOException e) { logger.error("error",e); } }return result; } /** * 下载文件到本地 * @param downloadUrl * @param savePathAndName */ public static void downloadFile(String downloadUrl,String savePathAndName){ HttpGet httpGet = new HttpGet(downloadUrl); httpGet.setHeader("User-Agent",USER_AGENT); httpGet.setConfig(requestConfig); CloseableHttpResponse response = null; InputStream in = null; try { response = getHttpClient().execute(httpGet,HttpClientContext.create()); HttpEntity entity = response.getEntity();if (entity != null) {in = entity.getContent(); //如果path传进来是/结束的话处理一下，先去掉。 FileOutputStream out = new FileOutputStream(new File(savePathAndName)); IOUtils.copy(in, out); out.close(); } } catch (IOException e) { logger.error("error",e); } finally { try {if (in != null) in.close(); } catch (IOException e) { logger.error("error",e); } try {if (response != null) response.close(); } catch (IOException e) { logger.error("error",e); } } } /** * 下载文件到本地 * @param downloadUrl * @param saveFileName * @param savePath */ public static void downloadFile(String downloadUrl,String saveFileName,String savePath){ //如果path传进来是/结束的话处理一下，先去掉。 String savePathAndName = savePath.endsWith("/") ? savePath.substring(0,savePath.lastIndexOf("/")) : savePath; downloadFile(downloadUrl, savePathAndName); } /** * 关闭连接池 */ public static void closeConnectionPool() {if(manager != null) manager.close();if(monitorExecutor != null) monitorExecutor.shutdown(); try {if(httpClient != null) httpClient.close();} catch (IOException e) {logger.error("error",e);} manager = null; monitorExecutor = null; httpClient = null; } privatestaticclass MyConnectionSocketFactory extends PlainConnectionSocketFactory { @Override public Socket createSocket(final HttpContext context) throws IOException { InetSocketAddress socksaddr = (InetSocketAddress) context.getAttribute("socks.address"); Proxy proxy = new Proxy(Proxy.Type.SOCKS, socksaddr); returnnew Socket(proxy); } @Override public Socket connectSocket(int connectTimeout, Socket socket, HttpHost host, InetSocketAddress remoteAddress, InetSocketAddress localAddress, HttpContext context) throws IOException { // Convert address to unresolved InetSocketAddress unresolvedRemote = InetSocketAddress .createUnresolved(host.getHostName(), remoteAddress.getPort()); returnsuper.connectSocket(connectTimeout, socket, host, unresolvedRemote, localAddress, context); } } privatestaticclass MySSLConnectionSocketFactory extends SSLConnectionSocketFactory { public MySSLConnectionSocketFactory(final SSLContext sslContext) { // You may need this verifier if target site's certificate is not secure super(sslContext, NoopHostnameVerifier.INSTANCE); } @Override public Socket createSocket(final HttpContext context) throws IOException { InetSocketAddress socksaddr = (InetSocketAddress) context.getAttribute("socks.address"); Proxy proxy = new Proxy(Proxy.Type.SOCKS, socksaddr); returnnew Socket(proxy); } @Override public Socket connectSocket(int connectTimeout, Socket socket, HttpHost host, InetSocketAddress remoteAddress, InetSocketAddress localAddress, HttpContext context) throws IOException { // Convert address to unresolved InetSocketAddress unresolvedRemote = InetSocketAddress .createUnresolved(host.getHostName(), remoteAddress.getPort()); returnsuper.connectSocket(connectTimeout, socket, host, unresolvedRemote, localAddress, context); } } public static void main(String[] args) throws InterruptedException, MalformedURLException { String url = "https://api.openai.com/v1/chat/completions"; url = "https://www.baidu.com"; System.out.println(HttpsKitWithProxyAuth.get(url)); //关闭连接池，正式环境中这个不要关闭 HttpsKitWithProxyAuth.closeConnectionPool(); }}package com.ruoyi.web.controller.meetingminutes.utils;/** * @Author 不要有情绪的 ljy * @Date 2024/10/31 20:35 * @Description: */import java.io.IOException;import java.text.SimpleDateFormat;import java.time.LocalDate;import java.time.LocalDateTime;import java.time.format.DateTimeFormatter;import java.util.List;import java.util.Map;import java.util.TimeZone;import org.slf4j.Logger;import org.slf4j.LoggerFactory;import com.fasterxml.jackson.annotation.JsonAutoDetect.Visibility;import com.fasterxml.jackson.annotation.JsonInclude;import com.fasterxml.jackson.annotation.PropertyAccessor;import com.fasterxml.jackson.core.JsonProcessingException;import com.fasterxml.jackson.core.type.TypeReference;import com.fasterxml.jackson.databind.DeserializationFeature;import com.fasterxml.jackson.databind.JavaType;import com.fasterxml.jackson.databind.ObjectMapper;import com.fasterxml.jackson.databind.SerializationFeature;import com.fasterxml.jackson.datatype.jsr310.JavaTimeModule;import com.fasterxml.jackson.datatype.jsr310.deser.LocalDateDeserializer;import com.fasterxml.jackson.datatype.jsr310.deser.LocalDateTimeDeserializer;import com.fasterxml.jackson.datatype.jsr310.ser.LocalDateSerializer;import com.fasterxml.jackson.datatype.jsr310.ser.LocalDateTimeSerializer;//https://www.cnblogs.com/christopherchan/p/11071098.htmlpublicclass JsonUtil { privatefinalstatic Logger logger = LoggerFactory.getLogger(JsonUtil.class); //日期格式化 privatestaticfinal String STANDARD_FORMAT = "yyyy-MM-dd HH:mm:ss"; privatestatic ObjectMapper objectMapper; static{ /** * ObjectobjectMapper是JSON操作的核心，Jackson的所有JSON操作都是在ObjectobjectMapper中实现。 * ObjectobjectMapper有多个JSON序列化的方法，可以把JSON字符串保存File、OutputStream等不同的介质中。 * writeValue(File arg0, Object arg1)把arg1转成json序列，并保存到arg0文件中。 * writeValue(OutputStream arg0, Object arg1)把arg1转成json序列，并保存到arg0输出流中。 * writeValueAsBytes(Object arg0)把arg0转成json序列，并把结果输出成字节数组。 * writeValueAsString(Object arg0)把arg0转成json序列，并把结果输出成字符串。 */ objectMapper = new ObjectMapper(); //对象的所有字段全部列入 objectMapper.setSerializationInclusion(JsonInclude.Include.ALWAYS); //取消默认转换timestamps形式 objectMapper.configure(SerializationFeature.WRITE_DATES_AS_TIMESTAMPS,false); //忽略空Bean转json的错误 objectMapper.configure(SerializationFeature.FAIL_ON_EMPTY_BEANS,false); //所有的日期格式都统一为以下的样式，即yyyy-MM-dd HH:mm:ss objectMapper.setDateFormat(new SimpleDateFormat(STANDARD_FORMAT)); //忽略 在json字符串中存在，但是在java对象中不存在对应属性的情况。防止错误 objectMapper.configure(DeserializationFeature.FAIL_ON_UNKNOWN_PROPERTIES,false); objectMapper.setTimeZone(TimeZone.getTimeZone("GMT+8")); objectMapper.setVisibility(PropertyAccessor.ALL, Visibility.ANY); //开启美化功能 //objectMapper.enable(SerializationFeature.INDENT_OUTPUT); //解决Java8 LocalDate,LocalDateTime等序列化问题 JavaTimeModule module=new JavaTimeModule(); module.addSerializer(LocalDateTime.class,new LocalDateTimeSerializer(DateTimeFormatter.ofPattern("yyyy-MM-dd HH:mm:ss"))); module.addDeserializer(LocalDateTime.class,new LocalDateTimeDeserializer(DateTimeFormatter.ofPattern("yyyy-MM-dd HH:mm:ss"))); module.addSerializer(LocalDate.class,new LocalDateSerializer(DateTimeFormatter.ofPattern("yyyy-MM-dd"))); module.addDeserializer(LocalDate.class,new LocalDateDeserializer(DateTimeFormatter.ofPattern("yyyy-MM-dd"))); objectMapper.registerModule(module); } /** * 对象转Json格式字符串 * @param obj 对象 * @return Json格式字符串 */ public static String toJSONString(Object o) { if (o == null) { returnnull; } if (o instanceof String) return (String) o; String jsonValue = null; try { jsonValue = objectMapper.writeValueAsString(o); } catch (JsonProcessingException e) { logger.error("Parse Object to String error",e); } return jsonValue; } @SuppressWarnings("unchecked") public static Map<String,Object> castToObject(String fromValue){ if(fromValue == null || "".equals(fromValue) ){ returnnull; } try { return objectMapper.readValue(fromValue, Map.class); } catch (Exception e) { logger.error("Parse String to Object error:", e); returnnull; } } /** * 字符串转换为自定义对象 * @param str 要转换的字符串 * @param clazz 自定义对象的class对象 * @return 自定义对象 */ @SuppressWarnings("unchecked") publicstatic <T> T castToObject(String fromValue, Class<T> clazz){ if(fromValue == null || "".equals(fromValue) || clazz == null){ returnnull; } try { return clazz.equals(String.class) ? (T) fromValue : objectMapper.readValue(fromValue, clazz); } catch (Exception e) { logger.error("Parse String to Object error:", e); returnnull; } } @SuppressWarnings("unchecked") publicstatic <T> T castToObject(String fromValue, TypeReference<T> typeReference) { if (fromValue == null || "".equals(fromValue) || typeReference == null) { returnnull; } try { return (T) (typeReference.getType().equals(String.class) ? fromValue : objectMapper.readValue(fromValue, typeReference)); } catch (IOException e) { logger.error("Parse String to Object error:", e); returnnull; } } publicstatic <T> T castToObject(String fromValue, Class<?> collectionClazz, Class<?>... elementClazzes) { JavaType javaType = objectMapper.getTypeFactory().constructParametricType(collectionClazz, elementClazzes); try { return objectMapper.readValue(fromValue, javaType); } catch (IOException e) { logger.error("Parse String to Object error : ", e.getMessage()); returnnull; } } publicstatic <T> T getValue(String fromValue, Class<T> clazz){ return castToObject(fromValue,clazz); } publicstatic <T> T getValue(String fromValue, TypeReference<T> toValueTypeRef){ return castToObject(fromValue, toValueTypeRef); } publicstatic <T> T getValue(String fromValue, Class<?> collectionClazz, Class<?>... elementClazzes){ return castToObject(fromValue, collectionClazz, elementClazzes); } //可通过点语法获取数据，如getValue("data.list","xxxxxxxx",List.class); publicstatic <T> T getValue(String key, String fromValue, Class<T> clazz){ Map<String,Object> infoMap = castToObject(fromValue); if(infoMap == null) returnnull; return getValue(key, infoMap, clazz); } //可通过点语法获取数据，如getValue("data.list","xxxxxxxx",new TypeReference<List<User>>(){}); publicstatic <T> T getValue(String key, String fromValue, TypeReference<T> toValueTypeRef){ Map<String,Object> infoMap = castToObject(fromValue); if(infoMap == null) returnnull; return getValue(key, infoMap, toValueTypeRef); } publicstatic <T> T getValue(String key, String fromValue, Class<?> collectionClazz, Class<?>... elementClazzes){ Map<String,Object> infoMap = castToObject(fromValue); if(infoMap == null) returnnull; return getValue(key, infoMap, collectionClazz, elementClazzes); } //可通过点语法获取数据，如getValue("data.list",new TypeReference<List<User>>(){}); @SuppressWarnings("rawtypes") publicstatic <T> T getValue(String key, Map fromMap, Class<T> clazz){ try { // 首先将key进行拆分 String[] keys = key.split("[.]"); for (int i = 0; i < keys.length; i++) { Object value = fromMap.get(keys[i]); if(value == null) returnnull; if (i < keys.length - 1) { fromMap = (Map) value; }else { return objectMapper.convertValue(value, clazz); } } } catch (Exception e) { logger.error("getValue error : ", e.getMessage()); returnnull; } returnnull; } @SuppressWarnings("rawtypes") publicstatic <T> T getValue(String key, Map fromMap, Class<?> collectionClazz, Class<?>... elementClazzes){ try { // 首先将key进行拆分 String[] keys = key.split("[.]"); for (int i = 0; i < keys.length; i++) { Object value = fromMap.get(keys[i]); if(value == null) returnnull; if (i < keys.length - 1) { fromMap = (Map) value; }else { JavaType javaType = objectMapper.getTypeFactory().constructParametricType(collectionClazz, elementClazzes); return objectMapper.convertValue(value, javaType); } } } catch (Exception e) { logger.error("getValue error : ", e.getMessage()); returnnull; } returnnull; } @SuppressWarnings("rawtypes") publicstatic <T> T getValue(String key, Map fromMap, TypeReference<T> toValueTypeRef){ try { // 首先将key进行拆分 String[] keys = key.split("[.]"); for (int i = 0; i < keys.length; i++) { Object value = fromMap.get(keys[i]); if(value == null) returnnull; if (i < keys.length - 1) { fromMap = (Map) value; }else { return objectMapper.convertValue(value, toValueTypeRef); } } } catch (Exception e) { logger.error("getValue error : ", e.getMessage()); returnnull; } returnnull; } /** * 将对像转换成具体的其他Bean对像 * @param fromValue * @param toValueTypeRef * @return */ publicstatic <T> T convertValue(Object fromValue, TypeReference<T> toValueTypeRef){ try { return objectMapper.convertValue(fromValue, toValueTypeRef); } catch (Exception e) { logger.error("convertValue error : ", e.getMessage()); returnnull; } } publicstatic <T> T convertValue(Object fromValue, Class<T> toValueType){ try { return objectMapper.convertValue(fromValue, toValueType); } catch (Exception e) { logger.error("convertValue error : ", e.getMessage()); returnnull; } } public static String getString(Map<String,Object> fromMap, String fieldName){ return fromMap.get(fieldName)==null ? null : fromMap.get(fieldName).toString(); } //根据filedName的key查找map为空时，使用对应的defaultValue默认值替换返回 public static String getString(Map<String,Object> jsonObject, String fieldName,String defaultValue){ return jsonObject.get(fieldName)==null ? defaultValue : jsonObject.get(fieldName).toString(); } public static Integer getInteger(Map<String,Object> jsonObject, String fieldName){ return jsonObject.get(fieldName)==null ? null : (Integer)jsonObject.get(fieldName); } public static Double getDouble(Map<String,Object> jsonObject, String fieldName){ return jsonObject.get(fieldName)==null ? null : (Double)jsonObject.get(fieldName); } public static Boolean getBoolean(Map<String,Object> jsonObject, String fieldName){ return jsonObject.get(fieldName)==null ? false : (Boolean)jsonObject.get(fieldName); } public static Long getLong(Map<String,Object> jsonObject, String fieldName){ return jsonObject.get(fieldName)==null ? null : (Long)jsonObject.get(fieldName); } publicstatic <T> List<T> getList(Map<String,Object> jsonObject, String fieldName,Class<T> clazz){ return jsonObject.get(fieldName)==null ? null : JsonUtil.getValue(fieldName, jsonObject, List.class,clazz); }}3、问题总结
开始敲黑板了
3.1、访问案例失败
部署完成后，可能存在很多问题，例如：访问example访问失败，那么使用
systemctl status ds*查看有没有启动对应的服务
3.2、加载word文档失败
修改启动的配置文件，将token去除，更改配置文件local.json和default.json，配置文件位置
/etc/onlyoffice/documentserverlocal.json中将参数token都改为false，去除token
"token": {"enable": {"request": {"inbox": false,"outbox": false },"browser": false },default.json中将参数request-filtering-agent改为true，token也改为false，rejectUnauthorized改为false
"request-filtering-agent" : {"allowPrivateIPAddress": true,"allowMetaIPAddress": true },"token": {"enable": {"browser": false,"request": {"inbox": false,"outbox": false } },"rejectUnauthorized": false修改了以上配置参数后，重启服务，再次测试。
以上更基本能解决报错文档权限问题，文档保存失败问题，文档下载问题等报错信息。
3.3、系统后端有token验证问题
如果你访问的地址需要携带token，进行token验证（自己的系统后台，并非onlyoffice的token），那么可以通过配置下面代码的形式进行解决，例如：我的访问路径为http:192.168.123.123:8089/getFile/12，去除token验证（requests.antMatchers("/callback", "/getFile/*", "/login", "/register", "/captchaImage").permitAll()）
@Beanprotected SecurityFilterChain filterChain(HttpSecurity httpSecurity) throws Exception {return httpSecurity // CSRF禁用，因为不使用session .csrf(csrf -> csrf.disable()) // 禁用HTTP响应标头 .headers((headersCustomizer) -> { headersCustomizer.cacheControl(cache -> cache.disable()).frameOptions(options -> options.sameOrigin()); }) // 认证失败处理类 .exceptionHandling(exception -> exception.authenticationEntryPoint(unauthorizedHandler)) // 基于token，所以不需要session .sessionManagement(session -> session.sessionCreationPolicy(SessionCreationPolicy.STATELESS)) // 注解标记允许匿名访问的url .authorizeHttpRequests((requests) -> { permitAllUrl.getUrls().forEach(url -> requests.antMatchers(url).permitAll()); // 对于登录login 注册register 验证码captchaImage 允许匿名访问 requests.antMatchers("/callback", "/getFile/*", "/login", "/register", "/captchaImage").permitAll() // 静态资源，可匿名访问 .antMatchers(HttpMethod.GET, "/", "/*.html", "/**/*.html", "/**/*.css", "/**/*.js", "/profile/**").permitAll() .antMatchers("/swagger-ui.html", "/swagger-resources/**", "/webjars/**", "/*/api-docs", "/druid/**").permitAll() // 除上面外的所有请求全部需要鉴权认证 .anyRequest().authenticated(); }) // 添加Logout filter .logout(logout -> logout.logoutUrl("/logout").logoutSuccessHandler(logoutSuccessHandler)) // 添加JWT filter .addFilterBefore(authenticationTokenFilter, UsernamePasswordAuthenticationFilter.class) 添加CORS filter .addFilterBefore(corsFilter, JwtAuthenticationTokenFilter.class) .addFilterBefore(corsFilter, LogoutFilter.class) .build();}3.4、使用文档地址访问问题
如果你不采用上面的方式，即http:192.168.123.123:8089/getFile/12 的方式，你想采用http:192.168.123.123:8089/word/1234.docx 的方式，也是可以的，但是你需要将文档挂到一个服务上，例如使用ngnix作为代理，进行/word/1234.docx的重定向。
下面你可以直接使用一个在线的docx链接来测试你是否部署成功，在线链接：
“https://d2nlctn12v279m.cloudfront.net/assets/docs/samples/zh/demo.docx
即将前端代码中的url替换为上面的链接。
4、后记
如果你看到这里，那么代表你将要成功了，整个过程比较艰难，前后弄了两三天，还好最后结果是好的，所以简单总结一下，勉励自己。
