【PDF原理图交互】全新体验,无感交互,全网首发今天，PDF原理图交互工具，迎来了一次大版本更新，摒弃了原通过剪切板复制文本，再到PCB里去触发读取的方案，实现PDF原理图和PCB的一次深入交互，实现真正的“握手”。PDF中像DSN一样，点击需要选择的器件或者Net，即可实现PCB的同步选择。同时支持反向选择，让我们能更友好的查看原理图！与Cadence原生功能深入融合，支持所有Cadence原生命令，比如高亮、移动、Fix、Ratsnet等常用操作。-----------------------------------------------------------《版本：zsking_clipboard_crossref》-----------------------------
