ThreadForge 源码解读二:一个 Task 从 submit 到完成,内部到底发生了什么?

上一篇讲的是边界：ThreadScope 负责把一批并发任务收进同一个生命周期。

这一篇往里再走一层，直接来看执行链路，带着问题来看：

❝
一个 Task 从 submit(...) 到最后成功、失败或取消，中间到底经历了什么？
❞

1. 为什么要有 `Task<T>`

CompletableFuture 本身已经非常强大了，但业务代码处理并发阶段时，往往还需要这些东西：

明确的任务名称
一眼就能看明白的状态机
实际执行线程的记录
稳定的取消入口
生命周期绑定
更贴近业务的等待和异常语义

所以 ThreadForge 额外包装了一层 Task<T> 做对外暴露。

Task 的核心字段在 src/main/java/io/threadforge/Task.java：

ounter(lineounter(lineounter(lineounter(lineounter(lineprivate final long id;private final String name;private final CompletableFuture<T> future;private final AtomicReference<State> state;private final AtomicReference<Thread> runnerThread;

状态定义如下：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linepublic enum State {    PENDING,    RUNNING,    SUCCESS,    FAILED,    CANCELLED}

可以先这样来理解：

❝
Task<T> 是带状态机、元信息和取消能力的任务句柄。
❞

2. Task 状态流转：从 PENDING 到终态

5 个状态，5 个状态切换方法，路径很少，清晰明了：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linestateDiagram-v2    [*] --> PENDING: new Task    PENDING --> RUNNING: markRunning(thread)    RUNNING --> SUCCESS: markSuccess()    RUNNING --> FAILED: markFailed()    RUNNING --> CANCELLED: markCancelled()    PENDING --> CANCELLED: cancel before run    PENDING --> FAILED: rejected / timeout    SUCCESS --> [*]    FAILED --> [*]    CANCELLED --> [*]

状态切换的入口都在 Task 上，包级可见，外部只能读：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(line// 包级 — 由 ThreadScope 在正确时机调用boolean markRunning(Thread runner)void markSuccess()void markFailed()void markCancelled()void interruptRunner()

先看 markRunning(...)：

ounter(lineounter(lineounter(lineounter(lineboolean marked = state.compareAndSet(State.PENDING, State.RUNNING);if (marked) {    runnerThread.set(runner);}

主要做了两件事：

CAS 从 PENDING 切到 RUNNING——只有一个线程能成功
成功后把执行线程记下来——后面取消时知道该中断谁

如果 CAS 失败（比如任务在排队的间隙被 cancel 了），方法返回 false，调用方跳过执行。这就是 cancel 和 markRunning 之间的竞态保护：cancel 先改状态为 CANCELLED，markRunning 的 CAS 就会失败，任务不会开始跑。

其余三个终态方法结构对称——清掉 runner 引用，设置状态：

ounter(lineounter(lineounter(linevoid markSuccess()    { runnerThread.set(null); state.set(State.SUCCESS); }void markFailed()     { runnerThread.set(null); state.set(State.FAILED); }void markCancelled()  { runnerThread.set(null); state.set(State.CANCELLED); }

终态后 runnerThread 清理成 null，避免外界持有一个已终止线程的句柄。

3. cancel：三步走，协作式终止

Task.cancel() 实现很简洁：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linepublic boolean cancel() {    state.set(State.CANCELLED);    Thread runner = runnerThread.get();    if (runner != null) {        runner.interrupt();    }    return future.cancel(true);}

其实就三步，保持顺序：

「先设状态为 CANCELLED」——这一步配合上一节讲的 markRunning CAS，抢占式阻止任务启动
「再中断 runner」——如果任务已经在跑，发中断信号；如果还没拿到 runner，跳过
「最后取消底层 future」——future.cancel(true) 会尝试中断 future 内部的执行线程

注意为什么是「协作式」终止：Thread.interrupt() 只是发信号，不是强行杀线程。任务代码、阻塞点、中断处理逻辑要一起配合才能停下来。ThreadForge 靠三层协作：

Thread.interrupt() —— 唤醒阻塞中的线程
CancellationToken.throwIfCancelled() —— 任务代码主动检查取消点
任务业务逻辑对中断的响应 —— 捕获 InterruptedException 后做清理并退出

单独哪一层都不够，三层叠加才算是可靠。

4. submit 的完整时序：从参数校验到进入调度器

ThreadScope 有十几个 submit(...) 重载，全部收敛到一个私有方法。去掉参数校验和并发许可申请后，核心构造逻辑如下：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linefinal CompletableFuture<T> future = new CompletableFuture<T>();final Task<T> task = new Task<T>(id, name, future);final TaskInfo info = new TaskInfo(scopeId, id, name, Instant.now(), scheduler.name());final ExecutionContextCarrier executionContext = ExecutionContextCarrier.capture();final ScheduledTask timeoutTask = scheduleTaskTimeout(task, info, taskTimeout);tasks.add(task);future.whenComplete((value, throwable) -> {    tasks.remove(task);    if (timeoutTask != null) {        timeoutTask.cancel();    }});

然后交给调度器：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(linescheduler.executor().execute(Scheduler.prioritized(    executionContext.wrapRunnable(() -> runTask(task, info, callable, taskRetryPolicy,        permitAcquired ? semaphore : null)),    taskPriority,    id));

如果调度器拒绝执行（RejectedExecutionException），框架会释放并发许可、标记任务失败并触发 hook。

逐行看：

建 CompletableFuture — 任务结果的载体
建 Task — 带状态机和元信息的句柄
建 TaskInfo — 观测用的快照数据
捕获上下文 — Context 和 OpenTelemetry 双份
注册任务级 timeout — 可选的独立时间预算
登记到 tasks — scope 后续可以捞出所有任务
「注册 whenComplete 回调」 — 任务无论成功、失败还是取消，结束时自动从 tasks 队列移除，同时取消关联的 timeout 任务
包成带优先级的 runnable，交给调度器

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linesequenceDiagram    participant User    participant Scope as ThreadScope    participant Context as ExecutionContextCarrier    participant Scheduler    participant Task    participant Retry as RetryExecutor    participant Hook as ThreadHook    participant Metrics    User->>Scope: submit(name, callable)    Scope->>Scope: lockConfiguration()    Scope->>Scope: acquireSubmissionPermit()    Scope->>Task: new Task(id, name, future)    Scope->>Context: capture()    Scope->>Scope: scheduleTaskTimeout()    Scope->>Scope: tasks.add(task)    Scope->>Scheduler: executor.execute(prioritizedRunnable)    Scheduler->>Scope: runTask(task, callable)    Scope->>Task: markRunning(currentThread)    Scope->>Hook: onStart(info)    Scope->>Metrics: recordStart()    Scope->>Retry: execute(callable, retryPolicy, token)    alt callable success        Retry-->>Scope: value        Scope->>Task: markSuccess()        Scope->>Hook: onSuccess(info, duration)        Scope->>Metrics: recordTerminal(SUCCESS)    else callable failed        Retry-->>Scope: throwable        Scope->>Task: markFailed()        Scope->>Hook: onFailure(info, error, duration)        Scope->>Metrics: recordTerminal(FAILED)    else cancelled        Scope->>Task: markCancelled()        Scope->>Hook: onCancel(info, duration)        Scope->>Metrics: recordTerminal(CANCELLED)    end

上半段提交，下半段执行，最后按成功、失败、取消三条路径收尾。

5. `runTask(...)`：真正执行任务的内核

runTask(...) 是整条链路的执行引擎。完整方法约 40 行，精简后主结构如下：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linelong started = System.nanoTime();CompletableFuture<T> future = task.toCompletableFuture();try {    // ① 启动前双重取消检查    if (task.isCancelled() || token.isCancelled()) {        completeTaskCancelled(task, future, new CancelledException("..."), info, started);        return;    }    // ② 状态机: PENDING → RUNNING    if (!task.markRunning(Thread.currentThread())) {        return;    }    // ③ 触发观测    safeHookStart(info);    token.throwIfCancelled();    // ④ 真正执行（含重试）    T value = RetryExecutor.execute(callable, retryPolicy, token);    if (future.complete(value)) {        task.markSuccess();        safeHookSuccess(info, elapsedNanos(started));    }} catch (InterruptedException e) {    Thread.currentThread().interrupt();    completeTaskCancelled(task, future, new CancelledException("..."), info, started);} catch (CancelledException e) {    completeTaskCancelled(task, future, e, info, started);} catch (Throwable t) {    completeTaskFailure(task, future, t, info, started);} finally {    if (acquiredSemaphore != null) {        acquiredSemaphore.release(); // 释放并发许可    }}

异常走了三条分叉：

InterruptedException → 重置线程中断标志后走取消路径
CancelledException → 直接走取消路径
其他 Throwable → 走失败路径（completeTaskFailure 内部通过 future.completeExceptionally(...) 把异常写入 future，再调用 task.markFailed() 和 hook）

失败、取消、重试、并发许可——全收在这一个方法里。

6. Scheduler：执行策略和所有权分离

ounter(lineounter(lineounter(lineounter(lineprivate final ExecutorService executor;private final boolean ownsExecutor;private final String name;private final boolean virtualThreadMode;

四个字段，四个职责：

executor — 任务交给谁执行
ownsExecutor — scope 关闭时要不要连带关掉执行器
name — 日志和观测里的标识
virtualThreadMode — 是否跑在虚拟线程上

6.1 `Scheduler.detect()`

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(linepublic static Scheduler detect() {    if (isVirtualThreadSupported()) {        return virtualThreads();    }    return commonPool();}

isVirtualThreadSupported() 通过反射探测 Executors.newVirtualThreadPerTaskExecutor()，virtualThreads() 内部 DCL 延迟创建。反射找不到方法或调用失败，自动回退到 commonPool()。调用方一行不用改。

6.2 `Scheduler.fixed(int size)`

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineint queueCapacity = Math.max(256, size * 100);new ThreadPoolExecutor(    size, size, 60L, TimeUnit.SECONDS,    new LinkedBlockingQueue<Runnable>(queueCapacity),    new NamedThreadFactory("threadforge-fixed"),    new ThreadPoolExecutor.CallerRunsPolicy());executor.allowCoreThreadTimeOut(true);

core = max，固定线程数；线程打满后任务入有界队列
queueCapacity 至少 256，随线程数线性放大
CallerRunsPolicy：队列满时提交线程自己执行，形成自然反压
allowCoreThreadTimeOut(true)：空闲超过 60 秒的核心线程也回收，避免高峰过后空转

6.3 `Scheduler.priority(int size)`

同样固定线程池，但队列换成无界的 PriorityBlockingQueue：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(linenew ThreadPoolExecutor(    size, size, 60L, TimeUnit.SECONDS,    new PriorityBlockingQueue<Runnable>(),    new NamedThreadFactory("threadforge-priority"),    new ThreadPoolExecutor.CallerRunsPolicy());

队列无界，CallerRunsPolicy 一般不会被触发。优先级靠 PrioritizedRunnable.compareTo(...) 实现：

ounter(lineounter(lineounter(lineint byPriority = Integer.compare(this.taskPriority.rank(), other.taskPriority.rank());if (byPriority != 0) return byPriority;return Long.compare(this.sequence, other.sequence);

先按 TaskPriority 排，同优先级按提交顺序（FIFO）。

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineflowchart TD    A[Scheduler.detect] --> B{JDK 支持虚拟线程?}    B -->|是| C[virtualThreads]    B -->|否| D[commonPool]    E[Scheduler.fixed] --> F[ThreadPoolExecutor + LinkedBlockingQueue]    G[Scheduler.priority] --> H[ThreadPoolExecutor + PriorityBlockingQueue]    I[Scheduler.from] --> J[外部 ExecutorService]    C --> K[executor.execute]    D --> K    F --> K    H --> K    J --> K

无论哪种方式创建，最后都从 executor.execute(...) 出去。

7. ExecutionContextCarrier：线程切换时，上下文怎么跟着走

线程切换后，提交线程里的 Context 和 OpenTelemetry 上下文就断了——两者都基于线程局部变量。ExecutionContextCarrier 专门解决这个问题：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(line// 提交时捕获static ExecutionContextCarrier capture() {    return new ExecutionContextCarrier(        Context.capture(),        OpenTelemetryBridge.currentContext()    );}// 执行时安装，结束后恢复Context.Snapshot previous = Context.install(contextSnapshot);Object scope = OpenTelemetryBridge.makeCurrent(otelParentContext);try {    return callable.call();} finally {    OpenTelemetryBridge.closeScope(scope);    Context.restore(previous);}

传播了两类上下文：

Context —— ThreadForge 自己的线程局部变量
OpenTelemetry —— 外部 Tracing 系统的当前 span

❝
submit 时 capture，执行时 install，结束后 restore。
❞

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linesequenceDiagram    participant Main as 提交线程    participant Carrier as ExecutionContextCarrier    participant Worker as 工作线程    participant Context    participant OTel as OpenTelemetryBridge    Main->>Context: Context.put(traceId)    Main->>Carrier: capture()    Carrier->>Context: Context.capture()    Carrier->>OTel: currentContext()    Worker->>Carrier: wrapCallable.call()    Carrier->>Context: install(snapshot)    Carrier->>OTel: makeCurrent(parentContext)    Worker->>Worker: 执行业务 callable    Carrier->>OTel: closeScope()    Carrier->>Context: restore(previous)

8. RetryExecutor：重试为什么必须感知取消

RetryExecutor 的核心循环是这样的：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linewhile (true) {    token.throwIfCancelled();    try {        return callable.call();    } catch (InterruptedException e) {        throw e;                    // 中断直接透传，不重试    } catch (CancelledException e) {        throw e;                    // 取消直接透传，不重试    } catch (Throwable failure) {        if (!retryPolicy.allowsRetry(attempt, failure)) {            // 不再重试，把之前所有失败附加到 suppressed            if (previousFailures != null) {                for (Throwable prev : previousFailures) {                    if (prev != failure) failure.addSuppressed(prev);                }            }            throw failure;        }        previousFailures.add(failure);        sleepBeforeRetry(retryPolicy.nextDelay(attempt, failure), token);        attempt++;    }}

「中断和取消直接透传」——不是业务失败，不能重试，框架必须立即响应
「每次循环先检查 token」——上次执行成功后，下一轮也要看 scope 是否已取消
「sleep 分片」——每 100ms 醒来检查一次取消

sleepBeforeRetry(...) 实现：

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(linelong remainingMillis = delay.toMillis();while (remainingMillis > 0L) {    token.throwIfCancelled();    long chunk = Math.min(remainingMillis, 100L);    Thread.sleep(chunk);    remainingMillis -= chunk;}

❝
重试也要服从作用域的取消和 deadline。
❞

如果最终还是失败，前面每次失败的异常会累加到最终异常的 suppressed 里——排查时能看到完整的失败历史，不是只有最后一次的错误信息。

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineflowchart TD    A[RetryExecutor.execute] --> B[token.throwIfCancelled]    B --> C[callable.call]    C -->|成功| D[返回结果]    C -->|InterruptedException| E[直接抛出]    C -->|CancelledException| F[直接抛出]    C -->|其他异常| G{RetryPolicy 允许重试?}    G -->|否| H[附加 suppressed failures]    H --> I[抛出最终异常]    G -->|是| J[记录本次失败]    J --> K[计算 nextDelay]    K --> L[分片 sleep, 每 100ms 检查取消]    L --> M[attempt++]    M --> B

分片 sleep 是关键：假设重试要等 5 秒，整段睡过去，中途收到取消信号就会反应慢半拍。分成 100ms 的小段，每段醒来检查一次取消，scope 一喊停就能更快响应。

9. 两层时间预算：scope deadline + task timeout

9.1 scope 级 deadline

ounter(linewithDeadline(Duration)

配置整个 ThreadScope 的截止时间。到达后：

deadlineTriggered = true，token.cancel()
作用域内所有任务收到取消信号
后续等待抛出 ScopeTimeoutException

9.2 task 级 timeout

ounter(linescope.submit("rpc-a", callable, Duration.ofMillis(200));

给单个任务设置独立预算。内部注册一个超时任务：

ounter(lineounter(lineounter(lineounter(lineounter(lineif (task.toCompletableFuture().completeExceptionally(timeoutException)) {    task.markFailed();    task.interruptRunner();    safeHookFailure(info, timeoutException, timeout.toNanos());}

只影响当前任务：标记失败、中断执行线程、触发 hook。不影响 scope 内其他任务。

类型	作用范围	触发后影响	适合场景
scope deadline	整个 `ThreadScope`	取消整个作用域	一个请求、一个批处理的总预算
task timeout	单个 `Task`	当前任务失败并中断 runner	某个 RPC、IO 的独立预算

一个管全局，一个管局部。

10. Hook 和 Metrics：观测内嵌在执行链路里

ThreadHook 是 interface，4 个方法全是 default——只覆写需要的：

ounter(lineounter(lineounter(lineounter(linedefault void onStart(TaskInfo info) {}default void onSuccess(TaskInfo info, Duration duration) {}default void onFailure(TaskInfo info, Throwable error, Duration duration) {}default void onCancel(TaskInfo info, Duration duration) {}

通过 andThen(...) 组合多个 hook，每个回调内部独立 catch 异常——前一个抛异常不阻止后续执行：

ounter(lineThreadHook combined = hook1.andThen(hook2).andThen(hook3);

元信息来自 TaskInfo：

ounter(linenew TaskInfo(scopeId, id, name, Instant.now(), scheduler.name())

内置指标由 ScopeMetrics 维护，LongAdder + AtomicLong，竞争开销低：

ounter(lineounter(linestarted / succeeded / failed / cancelledtotalDurationNanos / maxDurationNanos

观测和执行事件发生在同一时刻：

ounter(lineounter(lineounter(linesafeHookStart(info);   metrics.recordStart();// ... 执行 ...safeHookSuccess(...)   metrics.recordTerminal(Task.State.SUCCESS, ...)

ounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineounter(lineflowchart TD    A[runTask 开始] --> B[safeHookStart]    B --> C[metrics.recordStart]    C --> D[执行业务 Callable]    D -->|成功| E[safeHookSuccess]    E --> F[metrics.recordTerminal SUCCESS]    D -->|失败| G[safeHookFailure]    G --> H[metrics.recordTerminal FAILED]    D -->|取消| I[safeHookCancel]    I --> J[metrics.recordTerminal CANCELLED]

任务走到哪个生命周期节点，hook 和 metrics 就跟到哪里。

写在最后

最近换工作，刚进了一个新团队。上家的节奏比较正常，现在几乎每天加班赶进度。

说不清忙和闲哪个更好。

职位又往上走了一步，压力也跟着翻了一倍。

向上对齐、向下兜底，还是技术最纯粹。没有汇报，没有上下级，简单而美好。

这一篇是 ThreadForge 源码解读的执行链路部分，下一篇继续，解读高阶编排怎么在一个 scope 里协同工作。也算是给整个系列收官。

项目地址：github.com/wuuJiawei/ThreadForge，欢迎提 issue，也欢迎 star。
