TensorRT-LLM 0.5.0 源码之七
graph_rewriting.py
Layer
class Layer:
'''
Layer is a wrapper for TensorRT's ILayer with several python-friendly helper functions.
'''
def __init__(self, network: Network, trt_layer: trt.ILayer):
self.network = network
self.trt_layer = trt_layer
assert isinstance(self.network, Network)
assert isinstance(self.trt_layer, trt.ILayer)
def get_inputs(self, *indices: int):
'''
Get the input tensors of the layer.
Parameters:
idx: the indices of the input tensor, will return all inputs if left empty
Returns:
List[Tensor]
'''
from .functional import Tensor
indices = indices if indices else range(self.trt_layer.num_inputs)
ret = []
for i in indices:
assert i < self.trt_layer.num_inputs, f"Invalid input index {i} for layer {self.trt_layer.name}"
tensor = self.trt_layer.get_input(i)
tensor = Tensor(trt_tensor=tensor,
network=self.network,
is_network_input=False)
ret.append(tensor)
return ret
def get_outputs(self, *indices: int):
'''
Get the output tensor of the layer.
Parameters:
idx: the index of the output tensor
Returns:
List[Tensor]
'''
from .functional import Tensor
indices = indices if indices else range(self.trt_layer.num_outputs)
ret = []
for i in indices:
assert i < self.trt_layer.num_outputs, f"Invalid output index {i} for layer {self.trt_layer.name}"
tensor = self.trt_layer.get_output(i)
tensor = Tensor(trt_tensor=tensor,
network=self.network,
is_network_input=False)
ret.append(tensor)
return ret
def is_removed(self):
return self.network.is_removed_layer(self)
def mark_as_removed(self):
'''
Mark the layer as removed, this will remove the layer from the network.
'''
# NOTE, since INetwork python API doesn't provide a way to remove a layer, we actually mark the layer as removed in the network.
self.network.mark_removed_layer(self)
# remove the FLayerInfo if exists
FLayerInfoMemo.instance().remove(self.name)
def __eq__(self, other: "Layer") -> bool:
if isinstance(other, Layer):
return self.trt_layer == other.trt_layer
if isinstance(other, trt.tensorrt.ILayer):
return self.trt_layer == other
return False
def __getattr__(self, name: str) -> Any:
return getattr(self.trt_layer, name)
# Refer to https://docs.nvidia.com/deeplearning/tensorrt/api/python_api/infer/Graph/Layers.html?highlight=elementwise#layers for a complete
# list of TRT layers.
TRT_LAYER_TYPE_TO_LAYER = {
trt.LayerType.CONVOLUTION: trt.IConvolutionLayer,
trt.LayerType.FULLY_CONNECTED: trt.IFullyConnectedLayer,
trt.LayerType.ACTIVATION: trt.IActivationLayer,
trt.LayerType.POOLING: trt.IPoolingLayer,
trt.LayerType.LRN: trt.ILRNLayer,
trt.LayerType.SCALE: trt.IScaleLayer,
trt.LayerType.SOFTMAX: trt.ISoftMaxLayer,
trt.LayerType.DECONVOLUTION: trt.IDeconvolutionLayer,
trt.LayerType.CONCATENATION: trt.IConcatenationLayer,
trt.LayerType.ELEMENTWISE: trt.IElementWiseLayer,
trt.LayerType.UNARY: trt.IUnaryLayer,
trt.LayerType.PADDING: trt.IPaddingLayer,
trt.LayerType.SHUFFLE: trt.IShuffleLayer,
trt.LayerType.REDUCE: trt.IReduceLayer,
trt.LayerType.TOPK: trt.ITopKLayer,
trt.LayerType.GATHER: trt.IGatherLayer,
trt.LayerType.MATRIX_MULTIPLY: trt.IMatrixMultiplyLayer,
trt.LayerType.RAGGED_SOFTMAX: trt.IRaggedSoftMaxLayer,
trt.LayerType.CONSTANT: trt.IConstantLayer,
trt.LayerType.RNN_V2: trt.IRNNv2Layer,
trt.LayerType.IDENTITY: trt.IIdentityLayer,
trt.LayerType.PLUGIN_V2: trt.IPluginV2Layer,
trt.LayerType.SLICE: trt.ISliceLayer,
trt.LayerType.SHAPE: trt.IShapeLayer,
trt.LayerType.PARAMETRIC_RELU: trt.IParametricReLULayer,
trt.LayerType.RESIZE: trt.IResizeLayer,
trt.LayerType.TRIP_LIMIT: trt.ITripLimitLayer,
trt.LayerType.RECURRENCE: trt.IRecurrenceLayer,
trt.LayerType.ITERATOR: trt.IIteratorLayer,
trt.LayerType.LOOP_OUTPUT: trt.ILoopOutputLayer,
trt.LayerType.SELECT: trt.ISelectLayer,
trt.LayerType.FILL: trt.IFillLayer,
trt.LayerType.QUANTIZE: trt.IQuantizeLayer,
trt.LayerType.DEQUANTIZE: trt.IDequantizeLayer,
trt.LayerType.CONDITION: trt.IConditionLayer,
trt.LayerType.CONDITIONAL_INPUT: trt.IIfConditionalInputLayer,
trt.LayerType.CONDITIONAL_OUTPUT: trt.IIfConditionalOutputLayer,
trt.LayerType.ASSERTION: trt.IAssertionLayer,
trt.LayerType.SCATTER: trt.IScatterLayer,
trt.LayerType.EINSUM: trt.IEinsumLayer,
trt.LayerType.GRID_SAMPLE: trt.IGridSampleLayer,
trt.LayerType.ONE_HOT: trt.IOneHotLayer,
trt.LayerType.NON_ZERO: trt.INonZeroLayer,
trt.LayerType.NMS: trt.INMSLayer,
trt.LayerType.REVERSE_SEQUENCE: trt.IReverseSequenceLayer,
trt.LayerType.NORMALIZATION: trt.INormalizationLayer,
trt.LayerType.CAST: trt.ICastLayer,
}
def as_layer(self) -> Any:
'''
Convert to a actual TensorRT layer object, such as IPluginV2Layer or IConvolutionLayer so
that we can access the actual layer information.
'''
if self.type in self.TRT_LAYER_TYPE_TO_LAYER:
# bypass TRT's bug of retrieving a specific ILayer type in TensorRT
self.trt_layer.__class__ = self.TRT_LAYER_TYPE_TO_LAYER[self.type]
return self.trt_layer
raise NotImplementedError(f"Unkown layer type: {self.type}")
def __hash__(self):
return id(self.trt_layer)Pattern
@dataclass
class _Pattern:
name: str
# args helps to pass in/out some information
args: Dict[str, Any] = field(default_factory=dict, init=False)
def log_info(self, msg: str):
logger.info(f"Pattern {self.name}: {msg}")
def log_error(self, msg: str):
logger.error(f"Pattern {self.name}: {msg}")
def log_warn(self, msg: str):
logger.warning(f"Pattern {self.name}: {msg}")
class PatternRewriter(_Pattern):
'''
A pattern rewriter is a class that can match a pattern in the graph and rewrite the matched pattern.
There are two ways to implement a pattern rewriter, either override match() and rewrite() separately, or override match_and_rewrite().
'''
def __init__(self,
name: str,
root_layer: Optional[Set[trt.LayerType]] = None,
seperate_match_rewrite=False):
'''
Parameters:
name: the name of the rewrite pattern
root_layer: the root layer types to start the pattern matching, if not provided, the pattern will traverse all the layers in the graph.
seperate_match_rewrite: if set to True, the pattern should override match() and rewrite() separately, otherwise, the pattern should override match_and_rewrite()
'''
super().__init__(name)
self.root_layer = root_layer
self._seperate_match_rewrite = seperate_match_rewrite
def match(self, layer: Layer) -> bool:
raise NotImplementedError()
def rewrite(self, layer: Layer) -> None:
raise NotImplementedError()
def match_and_rewrite(self, layer: Layer) -> bool:
raise NotImplementedError()
class PatternAnalyzer(_Pattern):
def __init__(self, name: str,
root_layer: Optional[Set[trt.LayerType]]) -> None:
super().__init__(name)
self.root_layer = root_layer
def match(self, layer: Layer) -> bool:
raise NotImplementedError()
def analyze(self, subgraph: List[Layer]) -> None:
raise NotImplementedError()PatternManager
class _PatternManager:
PatternType = TypeVar('PatternType')
def __init__(self):
# records of (benefit, pattern, id)
self.patterns: Dict[str, Tuple[int, _PatternManager.PatternType]] = {}
def add(self,
label: str,
pattern: "_PatternManager.PatternType",
benefit: int = 0):
assert label not in self.patterns, f"Pattern {label} already exists"
self.patterns[label] = (benefit, pattern)
def get(self, label: str) -> "_PatternManager.PatternType":
return self.patterns[label][1]
class RewritePatternManager(_PatternManager):
def rewrite(self, net: Network, args=None):
modified = True
# TODO: we can optimize this by asking TRT to expose a graph iterator consistent even after the graph is modified
while modified:
modified = False
# Since the graph iterator is hold by the underlying INetwork, we can only rebuild the graph cache and match the nodes again.
for layer in net.get_layers():
if layer.is_removed():
continue
for (profit, pattern) in sorted(self.patterns.values(),
key=lambda x: x[0]):
pattern.args = args
if pattern.root_layer is not None and layer.type not in pattern.root_layer:
continue
if pattern._seperate_match_rewrite:
if pattern.match(layer):
pattern.rewrite(layer)
modified = True
else:
if pattern.match_and_rewrite(layer):
modified = True
@staticmethod
def instance():
return _global_rewrite_pattern_managerclass AnalysisPatternManager(_PatternManager):
def analyze(self, graph: Network, args=None):
for layer in graph.get_layers():
if layer.name in graph.removed_layers:
continue
for (benefit, pattern) in sorted(self.patterns.values(),
key=lambda x: x[0]):
pattern.args = args
if pattern.root_layer is not None and layer.type not in pattern.root_layer:
continue
if pattern.match(layer):
subgraph = pattern.match(layer)
pattern.analyze(subgraph)
@staticmethod
def instance():
return _global_analysis_pattern_manager
# singletons
_global_rewrite_pattern_manager = RewritePatternManager()
_global_analysis_pattern_manager = AnalysisPatternManager()FLayerInfo
@dataclass
class FLayerInfo:
'''
The FLayerInfo is used to track the functional layers in the INetwork, and it is used to help the graph rewriting.
The lifetime of a FLayer is the same as the corresponding plugin instance in the INetwork. Once the
plugin instance is removed by the graph rewriting, the FLayer will be removed as well.
WHY this is needed?
In the current implementation, for functional methods, once it is called in Python, it will lower to a plugin instance in the INetwork. However,
the plugin interface is black box with customized logic, we cannot retrieve necessary information from it, this is quite different from ILayer,
which provides a set of APIs to retrieve the information. Therefore, we need to record the high level information in the FLayerInfo, and keep
it consistent during the graph rewriting.
'''
layer_kind: str # the method name in the functional.py
# Record the raw inputs of the functional layer to be used in the graph rewrite
# NOTE: the raw inputs contains both the constants and Tensors, the Tensors will be also updated by graph rewriting
# APIs such as `replace_all_uses_with`
raw_inputs: Dict[str, Any]
raw_outputs: List[Any] = field(default_factory=list, init=False)
# the corresponding ILayer name
layer_name: str = field(init=False, default="")
# the signature of the functional layer
signature: Any = field(init=False, default=None)
def __post_init__(self):
from .functional import Tensor
assert self.layer_kind
def replace_with_symbols(arg) -> Any:
if arg is None:
return None
if isinstance(arg, Tensor):
return Tensor
if isinstance(arg, (list, tuple)):
return [replace_with_symbols(x) for x in arg]
if isinstance(arg, dict):
return {k: replace_with_symbols(v) for k, v in arg.items()}
return arg
def amend_tensor(arg) -> Any:
if arg is None:
return None
if isinstance(arg, Tensor):
arg.network = self.network
if isinstance(arg, (list, tuple)):
[replace_with_symbols(x) for x in arg]
if isinstance(arg, dict):
{k: replace_with_symbols(v) for k, v in arg.items()}
return arg
self.signature = self.layer_kind, {
name: replace_with_symbols(value)
for name, value in self.raw_inputs.items()
}
amend_tensor(self.raw_inputs)
def set_outputs(self, outputs: List[Any]):
self.raw_outputs = outputs
def get_input(self, name: str) -> Any:
return self.raw_inputs[name]
def clone_inputs(self):
'''
Get a shallow copy of the inputs.
'''
return copy(self.raw_inputs)
def replace_input_with(self, src, dst):
'''
Replace the input `src` with the input `dst` in the raw_inputs.
src: Tensor
dst: Tensor
'''
from .functional import Tensor
def replace(arg: Any):
if isinstance(arg, Tensor):
if arg.trt_tensor is src.trt_tensor:
return dst
return arg
elif isinstance(arg, (list, tuple)):
return [replace(x) for x in arg]
elif isinstance(arg, dict):
return {k: replace(v) for k, v in arg.items()}
return arg
replace(self.raw_inputs)
def replace_outputs_uses_with(self, net: Network, new_outs: List[Any]):
'''
Replace the output users with the new outputs.
new_outs: List[Tensor], the new outputs to replace with
'''
from .functional import Tensor
assert len(self.raw_outputs) == len(new_outs)
for old_out, new_out in zip(self.raw_outputs, new_outs):
assert type(old_out) == type(
new_out
), f"rewrite error, the output type {type(old_out)} is different from the new output type {type(new_out)} not match the original output type {type(old_out)}"
def _swap_tensor_info(new, deprecated):
name = deprecated.trt_tensor.name
deprecated.trt_tensor.name = name + '_deprecated'
new.trt_tensor.name = name
new.trt_tensor.dtype = deprecated.trt_tensor.dtype
def _reset_network_output_tensors(network, out, new_out):
net_outputs = list()
num_outputs = network._trt_network.num_outputs
need_to_mark = False
for i in range(num_outputs):
net_outputs.append(network._trt_network.get_output(i))
if out.trt_tensor is net_outputs[i]: need_to_mark = True
if need_to_mark is False: return
for output in net_outputs:
network.trt_network.unmark_output(output)
for i in range(num_outputs):
network.trt_network.mark_output(
new_out.trt_tensor
) if net_outputs[
i] is out.trt_tensor else network.trt_network.mark_output(
net_outputs[i])
def replace_all_uses_with(out, new_out):
if isinstance(out, Tensor):
assert isinstance(new_out, Tensor)
out.replace_all_uses_with(new_out)
_swap_tensor_info(new_out, out)
_reset_network_output_tensors(net, out, new_out)
elif isinstance(out, list):
assert isinstance(new_out, list)
for x, y in zip(out, new_out):
replace_all_uses_with(x, y)
elif isinstance(out, dict):
assert isinstance(new_out, dict)
for k, v in out.items():
replace_all_uses_with(v, new_out[k])
elif isinstance(out, tuple):
assert isinstance(new_out, tuple)
for x, y in zip(out, new_out):
replace_all_uses_with(x, y)
replace_all_uses_with(self.raw_outputs, new_outs)
def __hash__(self) -> int:
return hash(self.signature)
def __repr__(self) -> str:
return '<FLayer {}>'.format(self.signature)
@staticmethod
def _get_spec(arg):
'''
Get the spec that could impact on the Module's topology in the `forward` method.
'''
from .functional import Tensor
# For scalars, we track their value since they are constant
if arg is None:
return None
elif isinstance(arg, (bool, int, str)):
return arg
# For tensors, currently we only track their type, since they are variables
elif isinstance(arg, Tensor):
return Tensor
elif isinstance(arg, (list, tuple)):
return [FLayerInfo._get_spec(x) for x in arg]
# NOTE Free to add more types here is broken, carefully note that, from the engine building angle, all the constants
# should be captured while for the network variables, their types as placeholders are enough
else:
raise TypeError(f"unsupported input type detected: {type(arg)}")
@dataclass
class FLayerInfoMemo:
'''
FLayerInfoMemo holds the FLayer of all the necessary functional layers.
'''
data: Dict[str, FLayerInfo] = field(default_factory=dict, init=False)
cur_flayer: ClassVar[Optional[FLayerInfo]] = None
def add(self, layer_name: str, layer: FLayerInfo) -> None:
assert layer_name not in self.data, f"FLayer {layer_name} already exists in FLayerMemo"
self.data[layer_name] = layer
def create(self, fn: Callable, *args, **kwargs) -> FLayerInfo:
'''
Add a FLayer to the memo.
'''
return FLayerInfo(fn.__name__,
self.get_function_arg_dict(fn, *args, **kwargs))
def get(self, layer_name: str) -> Optional[FLayerInfo]:
return self.data.get(layer_name, None)
def remove(self, layer_name: str) -> None:
if layer_name in self.data:
del self.data[layer_name]
@staticmethod
def instance() -> "FLayerInfoMemo":
'''
A singleton instance of FLayerMemo.
'''
from ._common import default_net
return default_net().flayer_memo
@staticmethod
def get_function_arg_dict(f: Callable, *args, **kwargs):
'''
Get the input argument dict of a function.
'''
sig = inspect.signature(f)
bound_args = sig.bind(*args, **kwargs)
bound_args.apply_defaults()
return {k: v for k, v in bound_args.arguments.items() if k != 'self'}class FLayerScope:
'''
FLayerScope is used to capture the plugin within a functional method.
'''
def __init__(self, fn, *args, **kwargs):
self.layer = FLayerInfoMemo.instance().create(fn, *args, **kwargs)
def __enter__(self):
assert FLayerInfoMemo.cur_flayer is None, "FLayerMemo is not reentrant"
# There is no FLayer hierarchy, since the functional layers are not nested
FLayerInfoMemo.cur_flayer = self.layer
def __exit__(self, exc_type, exc_val, exc_tb):
assert self.layer.layer_name != "", f"FLayer {self.layer.layer_kind} without a plugin name detected"
FLayerInfoMemo.instance().add(self.layer.layer_name, self.layer)
FLayerInfoMemo.cur_flayer = None
class FLayerScope:
'''
FLayerScope is used to capture the plugin within a functional method.
'''
def __init__(self, fn, *args, **kwargs):
self.layer = FLayerInfoMemo.instance().create(fn, *args, **kwargs)
def __enter__(self):
assert FLayerInfoMemo.cur_flayer is None, "FLayerMemo is not reentrant"
# There is no FLayer hierarchy, since the functional layers are not nested
FLayerInfoMemo.cur_flayer = self.layer
def __exit__(self, exc_type, exc_val, exc_tb):
assert self.layer.layer_name != "", f"FLayer {self.layer.layer_kind} without a plugin name detected"
FLayerInfoMemo.instance().add(self.layer.layer_name, self.layer)
FLayerInfoMemo.cur_flayer = None
def record_signature(f):
'''
Helps to decorate a functional method and record its metadata with a FLayerInfo.
'''
@wraps(f)
def wrapper(*args, **kwargs):
with FLayerScope(f, *args, **kwargs):
outs = f(*args, **kwargs)
FLayerInfoMemo.cur_flayer.set_outputs(outs)
return outs
return wrapper
optimize
class FuseAttentionWithBiasPass(PatternRewriter):
def __init__(self):
super().__init__(name="fuse_attention_with_bias",
seperate_match_rewrite=False)
@staticmethod
def is_attention_plugin(layer: Layer) -> bool:
if layer.as_layer().type != trt.LayerType.PLUGIN_V2:
return False
p = layer.as_layer().plugin
conds = [
p.plugin_namespace == 'tensorrt_llm',
p.plugin_type == 'GPTAttention', p.num_outputs == 2
]
return all(conds)
@staticmethod
def is_elementwise_sum(layer: Layer) -> bool:
l = layer.as_layer()
if l.type != trt.LayerType.ELEMENTWISE:
return False
return l.op == trt.ElementWiseOperation.SUM
@staticmethod
def get_eltwise_inputs(layer: Layer):
const_inputs = []
mutable_inputs = []
from .functional import Tensor
def const_foldable(tensor: Tensor, depth=0) -> bool:
max_depth = 10
layer = tensor.get_parent()
if layer is None or depth > max_depth:
return False
if layer.type == trt.LayerType.CONSTANT and len(
layer.get_inputs()) == 0:
return True
for _ in layer.get_inputs():
if not const_foldable(_, depth + 1): return False
return True
for input in layer.get_inputs():
if const_foldable(input):
const_inputs.append(input)
else:
mutable_inputs.append(input)
return const_inputs, mutable_inputs
def match_and_rewrite(self, layer: Layer) -> bool:
from tensorrt_llm.network import net_guard
with net_guard(layer.network):
if not self.is_attention_plugin(layer):
return False
plugin_flayer = FLayerInfoMemo.instance().get(layer.name)
input = plugin_flayer.raw_inputs['tensor']
if input is None or len(list(input.get_users())) != 1:
return False
parent_layer = input.get_parent()
if not self.is_elementwise_sum(parent_layer):
return False
eltwise_const_inputs, eltwise_mutable_inputs = self.get_eltwise_inputs(
parent_layer)
if len(eltwise_const_inputs) != 1 or len(
eltwise_mutable_inputs) != 1:
return False
if plugin_flayer.raw_inputs['qkv_bias'] is not None:
return False
plugin_flayer.raw_inputs['tensor'] = eltwise_mutable_inputs[0]
plugin_flayer.raw_inputs['qkv_bias'] = eltwise_const_inputs[0]
from .functional import gpt_attention
new_outputs = gpt_attention(**plugin_flayer.raw_inputs)
plugin_flayer.replace_outputs_uses_with(layer.network, new_outputs)
return True
def optimize(net):
patterns = RewritePatternManager()
patterns.add(
label='fuse_attention_with_bias',
pattern=FuseAttentionWithBiasPass(),
)
patterns.rewrite(net)参考文献
-
• https://github.com/NVIDIA/TensorRT-LLM/blob/v0.5.0/tensorrt_llm/graph_rewriting.py
