OpenViking 使用与 OpenClaw 集成

1. OpenViking 简介

1.1 适用场景

问题	OpenViking 的做法
上下文碎片化	用文件系统范式统一管理：记忆、资源、技能都映射到 `viking://`虚拟目录，像管理文件一样管理上下文
Token 消耗大	L0/L1/L2 分层：L0 摘要约 100 token 做检索，L1 概览约 2k token 做决策，L2 按需加载全文，显著节省成本
检索效果差	目录递归检索：先向量定位到高分区目录，再在目录内递归细化，结合语义与层级结构，提升准确率
检索不可观测	检索路径对应明确 URI，支持可视化检索轨迹，便于调试和优化
记忆难以迭代	自动会话管理：对话结束后自动压缩、归档，并用 LLM 抽取长期记忆写入 `user/memories`、`agent/memories`，越用越准

1.2 核心概念

三种上下文类型

Resource（用户添加的知识与文档）、Memory（用户/Agent 的记忆）、Skill（可调用的能力），统一用 Viking URI 组织

存储架构

VikingFS 做 URI 抽象；底层 AGFS 存内容（L0/L1/L2 文件），Vector Index 存向量与元数据，二者分离便于扩展

检索流程

支持 find()（单查询向量检索）和 search()（意图分析 → 分层检索 → Rerank）；结果按 URI 返回，可区分 memories/resources/skills

2. OpenViking 部署

mkdir -p openviking/datachmod -R 777 openviking

生成 ROOT_API_KEY

openssl rand -hex 32

825a3a0183950b1bfa6c21b7afd8357b103e49c0478ae0f651515d76969f8ac4

准备配置文件

export OPENAI_API_KEY=sk-xxxexport OPENAI_API_BASE=https://llmapi.xxx.com/v1export ROOT_API_KEY="825a3a0183950b1bfa6c21b7afd8357b103e49c0478ae0f651515d76969f8ac4"

cat > openviking/ov.conf <<EOF{"server": {"host": "0.0.0.0","port": 1933,"root_api_key": "$ROOT_API_KEY","cors_origins": ["*"]  },"storage": {"workspace": "/app/data","vectordb": {"name": "context","backend": "local"    },"agfs": {"backend": "local","port": 1833,"log_level": "warn"    }  },"embedding": {"max_concurrent": 10,"dense": {"provider": "openai","api_key": "$OPENAI_API_KEY","api_base": "$OPENAI_API_BASE","model": "text-embedding-v4","dimension": 1024,"input": "text","batch_size": 32    }  },"vlm": {"provider": "openai","api_key": "$OPENAI_API_KEY","api_base": "$OPENAI_API_BASE","model": "qwen3.5-plus","temperature": 0.0,"max_retries": 2,"max_concurrent": 100  },"log": {"level": "INFO","output": "stdout"  }}EOF

embedding 配置用于向量化，vlm 配置用于摘要、L0/L1、记忆抽取，图像和内容理解。这里没有配置 rerank 模型。

运行 OpenViking 容器

nerdctl run -d \   --name openviking \   --restart always \   -p 1933:1933 \   -v $(pwd)/openviking/data:/app/data \   -v $(pwd)/openviking/ov.conf:/app/ov.conf \   ghcr.io/volcengine/openviking:v0.2.9

删除 OpenViking 容器

nerdctl rm -f openviking

验证 OpenViking 服务是否正常

curl http://127.0.0.1:1933/health

返回 {"status":"ok","healthy":true,"version":"v0.2.9"}即表示服务就绪。

3. OpenViking 用户管理

设置环境变量

export OPENVIKING_BASE_URL="http://10.10.10.10:1933"export ROOT_API_KEY="825a3a0183950b1bfa6c21b7afd8357b103e49c0478ae0f651515d76969f8ac4"

列出 accounts

curl -fsS -H "X-API-Key: $ROOT_API_KEY" \"${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts"

{"status":"ok","result":[{"account_id":"default","created_at":"2026-03-23T09:58:40.472608+00:00","user_count":0}],"error":null,"telemetry":null}

创建 account 和 admin user

curl -fsS -X POST "${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts" \  -H "Content-Type: application/json" \  -H "X-API-Key: $ROOT_API_KEY" \  -d '{"account_id":"my-team","admin_user_id":"my-admin"}'

{"status":"ok","result":{"account_id":"my-team","admin_user_id":"my-admin","user_key":"49331c3c1cafb6e5670f316d47aabfaae6c628b6ae72a0d05f35b7c93da763a2"},"error":null,"telemetry":null}

新建 user

需要提供 account 下的 admin user key

export ADMIN_USER_KEY="49331c3c1cafb6e5670f316d47aabfaae6c628b6ae72a0d05f35b7c93da763a2"curl -fsS -X POST "${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts/my-team/users" \  -H "Content-Type: application/json" \  -H "X-API-Key: $ADMIN_USER_KEY" \  -d '{"user_id":"my-user","role":"user"}'

{"status":"ok","result":{"account_id":"my-team","user_id":"my-user","user_key":"ad133ab241f779f19e2efe0c69655bd97dd67ac3a26a58d36a4a30c346e4b53f"},"error":null,"telemetry":null}

列出 account 下的 users

curl -fsS -H "X-API-Key: $ADMIN_USER_KEY" \"${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts/my-team/users"

{"status":"ok","result":[{"user_id":"my-admin","role":"admin"},{"user_id":"my-user","role":"user"}],"error":null,"telemetry":null}

修改 user 角色

curl -fsS -X PUT "${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts/my-team/users/my-user/role" \  -H "Content-Type: application/json" \  -H "X-API-Key: $ROOT_API_KEY" \  -d '{"role":"admin"}'

{"status":"ok","result":{"account_id":"my-team","user_id":"my-user","role":"admin"},"error":null,"telemetry":null}

重新生成用户 Key（旧 Key 立刻失效；用 Root 或 Admin User Key）

curl -fsS -X POST "${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts/my-team/users/my-user/key" \  -H "Content-Type: application/json" \  -H "X-API-Key: $ADMIN_USER_KEY" \  -d '{}'

{"status":"ok","result":{"user_key":"97b790bed56e40d288d3c60ee09abb41d821fb039fb2a53f92fe4fbd629ea8cd"},"error":null,"telemetry":null}

删除用户

curl -fsS -X DELETE "${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts/my-team/users/my-user" \  -H "X-API-Key: $ADMIN_USER_KEY"

删除整个 account

curl -fsS -X DELETE "${OPENVIKING_BASE_URL%/}/api/v1/admin/accounts/my-team" \  -H "X-API-Key: $ROOT_API_KEY"

4. OpenViking 功能使用

设置环境变量

export OPENVIKING_BASE_URL="http://10.10.10.10:1933"export USER_ID="my-user"export USER_KEY="97b790bed56e40d288d3c60ee09abb41d821fb039fb2a53f92fe4fbd629ea8cd"

curl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/fs/mkdir" \  -H "Content-Type: application/json" \  -H "X-API-Key: $USER_KEY" \  -d '{"uri":"viking://resources/lifecycle-demo/"}'

{"status":"ok","result":{"uri":"viking://resources/lifecycle-demo/"},"error":null,"telemetry":null}

export FILE_PATH="/tmp/ov-lifecycle.md"echo'Hello OpenViking lifecycle' > $FILE_PATHcurl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/resources/temp_upload" \  -H "X-API-Key: $USER_KEY" \  -F "file=@$FILE_PATH"

{"status":"ok","result":{"temp_path":"/app/data/temp/upload/upload_3c5f30d789b9439e91f16da9b22555cc.md"}}

export TEMP_PATH="/app/data/temp/upload/upload_3c5f30d789b9439e91f16da9b22555cc.md"curl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/resources" \  -H "Content-Type: application/json" \  -H "X-API-Key: $USER_KEY" \  -d "{    \"temp_path\": \"$TEMP_PATH\",    \"parent\": \"viking://resources/lifecycle-demo/\",    \"wait\": false,    \"reason\": \"curl lifecycle\"  }"

{"status":"ok","result":{"status":"success","errors":[],"source_path":"/app/data/temp/upload/upload_3c5f30d789b9439e91f16da9b22555cc.md","meta":{},"root_uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc","temp_uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc"}}

curl -fsS -G \  -H "X-API-Key: $USER_KEY" \  --data-urlencode "uri=viking://resources/lifecycle-demo/" \  --data-urlencode "recursive=true" \"$OPENVIKING_BASE_URL/api/v1/fs/ls"

{"status":"ok","result":[{"uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc","size":88,"isDir":true,"modTime":"09:02:48","rel_path":"upload_3c5f30d789b9439e91f16da9b22555cc","abstract":""},{"uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc/upload_3c5f30d789b9439e91f16da9b22555cc.md","size":27,"isDir":false,"modTime":"09:02:48","rel_path":"upload_3c5f30d789b9439e91f16da9b22555cc/upload_3c5f30d789b9439e91f16da9b22555cc.md","abstract":""}],"error":null,"telemetry":null}

读全文

export FILE_URI="viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc/upload_3c5f30d789b9439e91f16da9b22555cc.md"curl -fsS -G \  -H "X-API-Key: $USER_KEY" \  --data-urlencode "uri=$FILE_URI" \"$OPENVIKING_BASE_URL/api/v1/content/read"

{"status":"ok","result":"Hello OpenViking lifecycle\n","error":null,"telemetry":null}

看元信息

export FILE_URI="viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc/upload_3c5f30d789b9439e91f16da9b22555cc.md"curl -fsS -G \  -H "X-API-Key: $USER_KEY" \  --data-urlencode "uri=$FILE_URI" \"$OPENVIKING_BASE_URL/api/v1/fs/stat"

{"status":"ok","result":{"isDir":false,"modTime":"2026-03-24T09:02:48.710880298Z","mode":420,"name":"upload_3c5f30d789b9439e91f16da9b22555cc.md","size":27},"error":null,"telemetry":null}

find 语义检索

可以配置 rerank 模型。

curl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/search/find" \  -H "Content-Type: application/json" \  -H "X-API-Key: $USER_KEY" \  -d '{    "query": "Hello",    "target_uri": "viking://resources/lifecycle-demo/",    "limit": 5  }'

响应会比较慢，会有模型调用。

{"status":"ok","result":{"memories":[],"resources":[{"context_type":"resource","uri":"viking://resources/lifecycle-demo/upload_a67d1858a30f4c4d91df60e7a489448c/upload_a67d1858a30f4c4d91df60e7a489448c_1.md","level":2,"score":0.09988392326968897,"category":"","match_reason":"","relations":[],"abstract":"","overview":null}],"skills":[],"total":2}}

grep 文本匹配

curl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/search/grep" \  -H "Content-Type: application/json" \  -H "X-API-Key: $USER_KEY" \  -d '{"uri":"viking://resources/lifecycle-demo/","pattern":"Hello"}'

{"status":"ok","result":{"matches":[{"line":24,"uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc/.overview.md","content":""},{"line":1,"uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc/upload_3c5f30d789b9439e91f16da9b22555cc.md","content":"Hello OpenViking lifecycle"},{"line":1,"uri":"viking://resources/lifecycle-demo/upload_d318b2c6f0494e88af77f9d1afbc18de/upload_d318b2c6f0494e88af77f9d1afbc18de.md","content":"Hello OpenViking lifecycle"}],"count":3},"error":null,"telemetry":null}

search 语义、意图检索，可选带 session。

curl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/sessions" \  -H "Content-Type: application/json" \  -H "X-API-Key: $USER_KEY" \  -d '{}'

{"status":"ok","result":{"session_id":"d46e0160-1ebc-483d-971f-32d60bb1de9a","user":{"account_id":"my-team","user_id":"my-user","agent_id":"default"}},"error":null,"telemetry":null}

export SESSION_ID="d46e0160-1ebc-483d-971f-32d60bb1de9a"curl -fsS -X POST "$OPENVIKING_BASE_URL/api/v1/search/search" \  -H "Content-Type: application/json" \  -H "X-API-Key: $USER_KEY" \  -d '{    "query": "Hello",    "session_id": "$SESSION_ID",    "limit": 5  }'

也会有模型调用。

删文件

curl -fsS -X DELETE \  -H "X-API-Key: $USER_KEY" \  --get "$OPENVIKING_BASE_URL/api/v1/fs" \  --data-urlencode "uri=$FILE_URI"

{"status":"ok","result":{"uri":"viking://resources/lifecycle-demo/upload_3c5f30d789b9439e91f16da9b22555cc/upload_3c5f30d789b9439e91f16da9b22555cc.md"},"error":null,"telemetry":null}

curl -fsS -X DELETE \  -H "X-API-Key: $USER_KEY" \"$OPENVIKING_BASE_URL/api/v1/fs?uri=viking://resources/lifecycle-demo/&recursive=true"

{"status":"ok","result":{"uri":"viking://resources/lifecycle-demo/"},"error":null,"telemetry":null}

确认已空

curl -fsS -G \  -H "X-API-Key: $USER_KEY" \  --data-urlencode "uri=viking://resources/" \"$OPENVIKING_BASE_URL/api/v1/fs/ls"

{"status":"ok","result":[],"error":null,"telemetry":null}

5. OpenClaw 集成 OpenViking

OpenClaw：建议 2026.3.11，高版本可能存在兼容性问题

进入 OpenClaw 容器

nerdctl exec -it openclaw bash

关闭默认记忆后端

openclaw config set agents.defaults.memorySearch.enabled false --jsonopenclaw config set memory.qmd.includeDefaultMemory false --jsonopenclaw config set hooks.internal.entries.session-memory.enabled false --jsonopenclaw config set agents.defaults.compaction.memoryFlush.enabled false --json

安装配置向导

npm install -g openclaw-openviking-setup-helper

开始配置

ov-install

选择 remote，填写 OpenViking 服务地址和 USER_KEY。

启用插件

openclaw config set plugins.slots.memory openviking

重启 OpenClaw

openclaw gateway restart

查看插件配置

openclaw config get plugins.entries.openviking.config

🦞 OpenClaw 2026.3.11 (unknown) — I've survived more breaking changes than your last three relationships.{  "mode": "remote",  "baseUrl": "http://10.10.10.10:1933",  "apiKey": "__OPENCLAW_REDACTED__",  "agentId": "openclaw-viking"}

查看插件状态

node openclaw.mjs status |grep Memory

│ Memory          │ enabled (plugin openviking)       │

验证集成是否成功

尝试与 OpenClaw 对话，可以看到 OpenViking 创建相关记忆的日志。

nerdctl logs openviking -f

2026-03-24 10:20:59,392 - openviking.session.memory_extractor - INFO - uri viking://user/my-user/memories/events/mem_372fc569-f140-4a31-a266-6a795bf49af0.md abstract: 正在学习参考 LVM 日常运维文章作为速查手册，将其作为运维工作的速查手册使用。文章内容涵盖物理卷（PV）、卷组（VG）、逻辑卷（LV）的管理命令，以及 RAID 逻辑卷配置、扩容缩容操作等实用内容。

6. 参考

https://github.com/volcengine/OpenViking/issues/406
