cudaUtils
// workspace for cublas gemm : 32MB#define CUBLAS_WORKSPACE_SIZE 33554432typedef struct __align__(4){ half x, y, z, w;} half4;这段代码定义了一个名为 half4 的数据类型,它是一个包含四个 half 类型分量且整体按4字节对齐的结构体。下面我们来详细解析它的各个部分。
结构体成员
• 结构体包含四个成员: x,y,z,w,它们都是half类型。• half类型:这是一种半精度浮点数,通常占用 16 位(2 字节) 存储空间。它的数值范围和精度低于标准的单精度浮点数(float),但能节省内存和带宽,在对精度要求不极端的场景下非常有用,常见于图形编程和移动设备上的着色器。• 因此,这个结构体四个成员的理论总大小是 4 × 2 字节 = 8 字节。
内存对齐说明
• __align__(4):这个关键字(或类似语法,如__attribute__((aligned(4)))或_Alignas(4),取决于编译器)指示编译器将此结构体实例在内存中的起始地址安排在 4 字节的整数倍 上。• 对齐的重要性:现代计算机的CPU对内存的读写操作在数据位于特定地址边界(通常是数据大小的整数倍)时效率最高。如果数据没有正确对齐,在某些架构(如ARM)上可能导致性能下降甚至运行错误。
结构体大小与内存布局
虽然四个 half 成员本身只占 8 字节,但 __align__(4) 的对齐要求会影响整个结构体的大小和布局。
• 结构体的最终大小通常会是其成员中最大对齐要求的整数倍,这主要是为了确保在定义结构体数组时,每一个元素都能正确对齐。 • 在这个例子中,由于每个 half的大小是2字节,并且指定了4字节对齐,编译器可能会在成员之间或结构体末尾添加填充字节(Padding)来满足对齐要求。最终sizeof(half4)很可能仍然是 8 字节,因为 8 字节已经是 4 字节的整数倍。但在更复杂的结构体中,填充字节可能会更明显。
主要用途
• 数据封装:将四个相关的半精度浮点数(例如,表示一个颜色RGBA或一个四维向量)逻辑上捆绑在一起,方便统一管理。 • 性能优化:通过指定对齐方式,可以确保在特定硬件(如某些DSP或GPU)上获得高效的内存访问速度。 • 空间与精度平衡:使用 half类型在保证一定精度的同时,相比使用四个float(共16字节)能显著节省存储空间和传输带宽,这在处理大量数据(如顶点数据、纹理)时尤为重要。
注意事项
• 平台差异: half类型的精度和支持程度可能因平台和编译器而异。在一些PC平台上,它可能仍被当作float处理。• 语法变体: __align__(4)是编译器相关的扩展语法。在C11标准中,更便携的关键字是_Alignas或头文件stdalign.h中定义的alignas。
/* **************************** type definition ***************************** */enum CublasDataType{ FLOAT_DATATYPE = 0, HALF_DATATYPE = 1, BFLOAT16_DATATYPE = 2, INT8_DATATYPE = 3, FP8_DATATYPE = 4};enum TRTLLMCudaDataType{ FP32 = 0, FP16 = 1, BF16 = 2, INT8 = 3, FP8 = 4};enum class OperationType{ FP32, FP16, BF16, INT8, FP8};/* **************************** debug tools ********************************* */static const char* _cudaGetErrorEnum(cudaError_t error){ return cudaGetErrorString(error);}static const char* _cudaGetErrorEnum(cublasStatus_t error){ switch (error) { case CUBLAS_STATUS_SUCCESS: return "CUBLAS_STATUS_SUCCESS"; case CUBLAS_STATUS_NOT_INITIALIZED: return "CUBLAS_STATUS_NOT_INITIALIZED"; case CUBLAS_STATUS_ALLOC_FAILED: return "CUBLAS_STATUS_ALLOC_FAILED"; case CUBLAS_STATUS_INVALID_VALUE: return "CUBLAS_STATUS_INVALID_VALUE"; case CUBLAS_STATUS_ARCH_MISMATCH: return "CUBLAS_STATUS_ARCH_MISMATCH"; case CUBLAS_STATUS_MAPPING_ERROR: return "CUBLAS_STATUS_MAPPING_ERROR"; case CUBLAS_STATUS_EXECUTION_FAILED: return "CUBLAS_STATUS_EXECUTION_FAILED"; case CUBLAS_STATUS_INTERNAL_ERROR: return "CUBLAS_STATUS_INTERNAL_ERROR"; case CUBLAS_STATUS_NOT_SUPPORTED: return "CUBLAS_STATUS_NOT_SUPPORTED"; case CUBLAS_STATUS_LICENSE_ERROR: return "CUBLAS_STATUS_LICENSE_ERROR"; } return "<unknown>";}template <typename T>void check(T result, char const* const func, const char* const file, int const line){ if (result) { throw TllmException( file, line, fmtstr("[TensorRT-LLM][ERROR] CUDA runtime error in %s: %s", func, _cudaGetErrorEnum(result))); }}#define check_cuda_error(val) check((val), #val, __FILE__, __LINE__)#define check_cuda_error_2(val, file, line) check((val), #val, file, line)inline bool isCudaLaunchBlocking(){ static bool firstCall = true; static bool result = false; if (firstCall) { const char* env = std::getenv("CUDA_LAUNCH_BLOCKING"); result = env != nullptr && std::string(env) == "1"; firstCall = false; } return result;}inline void syncAndCheck(const char* const file, int const line){#ifndef NDEBUG const bool checkError = true;#else const bool checkError = isCudaLaunchBlocking();#endif if (checkError) { cudaError_t result = cudaDeviceSynchronize(); check(result, "cudaDeviceSynchronize", file, line); }}#define sync_check_cuda_error() tensorrt_llm::common::syncAndCheck(__FILE__, __LINE__)/* * Macros compliant with TensorRT coding conventions */#define TLLM_CUDA_CHECK(stat) \ do \ { \ tensorrt_llm::common::check((stat), #stat, __FILE__, __LINE__); \ } while (0)#define PRINT_FUNC_NAME_() \ do \ { \ std::cout << "[TensorRT-LLM][CALL] " << __FUNCTION__ << " " << std::endl; \ } while (0)template<typename T> struct packed_type;template <> struct packed_type<float> { using type = float; }; // we don't need to pack float by defaulttemplate <> struct packed_type<half> { using type = half2; };#ifdef ENABLE_BF16template<>struct packed_type<__nv_bfloat16> { using type = __nv_bfloat162;};#endif#ifdef ENABLE_FP8template<>struct packed_type<__nv_fp8_e4m3> { using type = __nv_fp8x2_e4m3;};#endiftemplate<typename T> struct num_elems;template <> struct num_elems<float> { static constexpr int value = 1; };template <> struct num_elems<float2> { static constexpr int value = 2; };template <> struct num_elems<float4> { static constexpr int value = 4; };template <> struct num_elems<half> { static constexpr int value = 1; };template <> struct num_elems<half2> { static constexpr int value = 2; };#ifdef ENABLE_BF16template <> struct num_elems<__nv_bfloat16> { static constexpr int value = 1; };template <> struct num_elems<__nv_bfloat162> { static constexpr int value = 2; };#endif#ifdef ENABLE_FP8template <> struct num_elems<__nv_fp8_e4m3> { static constexpr int value = 1; };template <> struct num_elems<__nv_fp8x2_e4m3> { static constexpr int value = 2; };#endiftemplate<typename T, int num> struct packed_as;template<typename T> struct packed_as<T, 1> { using type = T; };template<> struct packed_as<half, 2> { using type = half2; };template<> struct packed_as<float, 2> { using type = float2; };template<> struct packed_as<int8_t, 2> { using type = int16_t; };template<> struct packed_as<int32_t, 2> { using type = int2; };template<> struct packed_as<half2, 1> { using type = half; };template<> struct packed_as<float2, 1> { using type = float; };#ifdef ENABLE_BF16template<> struct packed_as<__nv_bfloat16, 2> { using type = __nv_bfloat162; };template<> struct packed_as<__nv_bfloat162, 1> { using type = __nv_bfloat16; };#endif#ifdef ENABLE_FP8template<> struct packed_as<__nv_fp8_e4m3, 2> { using type = __nv_fp8x2_e4m3; };template<> struct packed_as<__nv_fp8x2_e4m3, 1> { using type = __nv_fp8_e4m3; };template<> struct packed_as<__nv_fp8_e5m2, 2> { using type = __nv_fp8x2_e5m2; };template<> struct packed_as<__nv_fp8x2_e5m2, 1> { using type = __nv_fp8_e5m2; };#endifinline __device__ float2 operator*(float2 a, float2 b) { return make_float2(a.x * b.x, a.y * b.y); }inline __device__ float2 operator+(float2 a, float2 b) { return make_float2(a.x + b.x, a.y + b.y); }inline __device__ float2 operator-(float2 a, float2 b) { return make_float2(a.x - b.x, a.y - b.y); }inline __device__ float2 operator*(float2 a, float b) { return make_float2(a.x * b, a.y * b); }inline __device__ float2 operator+(float2 a, float b) { return make_float2(a.x + b, a.y + b); }inline __device__ float2 operator-(float2 a, float b) { return make_float2(a.x - b, a.y - b); }template <typename T>struct CudaDataType{};template <>struct CudaDataType<float>{ static constexpr cudaDataType_t value = cudaDataType::CUDA_R_32F;};template <>struct CudaDataType<half>{ static constexpr cudaDataType_t value = cudaDataType::CUDA_R_16F;};#ifdef ENABLE_BF16template <>struct CudaDataType<__nv_bfloat16>{ static constexpr cudaDataType_t value = cudaDataType::CUDA_R_16BF;};#endifinline int getSMVersion(){ int device{-1}; check_cuda_error(cudaGetDevice(&device)); int sm_major = 0; int sm_minor = 0; check_cuda_error(cudaDeviceGetAttribute(&sm_major, cudaDevAttrComputeCapabilityMajor, device)); check_cuda_error(cudaDeviceGetAttribute(&sm_minor, cudaDevAttrComputeCapabilityMinor, device)); return sm_major * 10 + sm_minor;}• 函数签名 inline int getSMVersion():inline关键字建议编译器将函数体直接展开在调用处以避免函数调用开销,适用于短小且频繁使用的函数。返回值是一个整数,表示计算能力(Compute Capability),格式为主版本号 × 10 + 次版本号。例如,若设备计算能力为7.5,则返回75• 用途:计算能力版本决定了GPU支持的硬件功能(如线程块大小、内存层次等),常用于条件编译或运行时优化(例如,为不同架构选择不同的内核代码)
inline int getDevice(){ int current_dev_id = 0; check_cuda_error(cudaGetDevice(¤t_dev_id)); return current_dev_id;}inline int getDeviceCount(){ int count = 0; check_cuda_error(cudaGetDeviceCount(&count)); return count;}/// Get the memory info/// \return The free and total amount of memory in bytesinline std::tuple<size_t, size_t> getDeviceMemoryInfo(){ size_t free, total; check_cuda_error(cudaMemGetInfo(&free, &total)); return {free, total};}inline int getMultiProcessorCount(){ int device_id; int multi_processor_count; check_cuda_error(cudaGetDevice(&device_id)); check_cuda_error(cudaDeviceGetAttribute(&multi_processor_count, cudaDevAttrMultiProcessorCount, device_id)); return multi_processor_count;}inline int divUp(int a, int n){ return (a + n - 1) / n;}template <typename T, typename U, typename = std::enable_if_t<std::is_integral<T>::value>, typename = std::enable_if_t<std::is_integral<U>::value>>auto constexpr ceilDiv(T numerator, U denominator){ return (numerator + denominator - 1) / denominator;}这段C++代码定义了一个名为ceilDiv的函数模板,用于执行向上取整的整数除法。它通过模板元编程技术对参数类型进行了约束,并确保函数能在编译期计算。下面我们来详细解析它的各个组成部分。
模板参数与类型约束
代码中的模板参数列表使用了std::enable_if_t来施加类型约束,这是实现SFINAE(Substitution Failure Is Not An Error)的常见手法。
template <typename T, typename U, typename = std::enable_if_t<std::is_integral<T>::value>, typename = std::enable_if_t<std::is_integral<U>::value>>• std::is_integral<T>::value:这是一个类型特质(type trait),在编译期检查类型T是否为整型(如int,long,char等)。如果是,其value成员为true;否则为false。• std::enable_if_t<Condition>:它是std::enable_if<Condition>::type的别名模板(C++14引入)。当Condition为true时,std::enable_if_t代表一个有效的类型(默认为void);当Condition为false时,它不产生任何类型,导致模板参数替换失败。• SFINAE效果:这两个默认模板参数共同作用,确保了编译器只有在 T和U都是整型时,才会选择实例化这个模板函数。如果传入浮点数等非整型参数,编译将会失败。
函数声明与实现
auto constexpr ceilDiv(T numerator, U denominator){ return (numerator + denominator - 1) / denominator;}• auto返回类型:使用auto让编译器自动推导返回类型。返回类型将是表达式(numerator + denominator - 1) / denominator的结果类型,通常是T和U在经过算术转换后的公共整数类型。• constexpr函数说明符:这表明该函数是一个常量表达式函数。当传入的参数是编译期常量时,整个计算过程可以在编译期完成,结果直接作为常量嵌入代码中,有助于提升运行时效率。例如,ceilDiv(10, 3)会在编译期直接计算出结果4。• 向上取整的算法:公式 (numerator + denominator - 1) / denominator是整数运算中实现向上取整的经典技巧。• 当 numerator能被denominator整除时,例如numerator=10,denominator=5:(10 + 5 - 1) / 5 = 14 / 5 = 2,结果正确。• 当不能整除时,例如 numerator=10,denominator=3:(10 + 3 - 1) / 3 = 12 / 3 = 4,而10 / 3的整数除法结果是3,向上取整正好是4。
应用场景与注意事项
这种向上取整的除法在计算分页数量、数组块分配等场景中非常有用。使用此函数模板时需要注意:
• 它只接受整型参数,这是通过模板约束强制实现的。 • 函数被设计为 constexpr,适合用于编译期需要常量表达式的上下文,如数组大小定义、模板非类型参数等。• 需要注意**分母为零(zero denominator)**的情况,因为这会引发未定义行为。在实际使用中,应确保 denominator不为零。
总结
这个ceilDiv函数模板巧妙地结合了模板元编程(通过std::enable_if_t和std::is_integral进行类型约束)、常量表达式计算(constexpr)和高效的算术算法,提供了一个类型安全且性能优越的向上取整除法工具。
template <typename T>void printAbsMean(const T* buf, uint64_t size, cudaStream_t stream, std::string name = ""){ if (buf == nullptr) { TLLM_LOG_WARNING("%s is an nullptr, skip!", name.c_str()); return; } cudaDeviceSynchronize(); check_cuda_error(cudaGetLastError()); T* h_tmp = new T[size]; cudaMemcpyAsync(h_tmp, buf, sizeof(T) * size, cudaMemcpyDeviceToHost, stream); cudaDeviceSynchronize(); check_cuda_error(cudaGetLastError()); double sum = 0.0f; uint64_t zero_count = 0; float max_val = -1e10; bool find_inf = false; for (uint64_t i = 0; i < size; i++) { if (std::isinf((float) (h_tmp[i]))) { find_inf = true; continue; } sum += abs((double) h_tmp[i]); if ((float) h_tmp[i] == 0.0f) { zero_count++; } max_val = max_val > abs(float(h_tmp[i])) ? max_val : abs(float(h_tmp[i])); } TLLM_LOG_INFO("%20s size: %u, abs mean: %f, abs sum: %f, abs max: %f, find inf: %s", name.c_str(), size, sum / size, sum, max_val, find_inf ? "true" : "false"); delete[] h_tmp; cudaDeviceSynchronize(); check_cuda_error(cudaGetLastError());}template <typename T>void printToStream(const T* result, const int size, FILE* strm){ const bool split_rows = (strm == stdout); if (result == nullptr) { TLLM_LOG_WARNING("It is an nullptr, skip! \n"); return; } T* tmp = reinterpret_cast<T*>(malloc(sizeof(T) * size)); check_cuda_error(cudaMemcpy(tmp, result, sizeof(T) * size, cudaMemcpyDeviceToHost)); for (int i = 0; i < size; ++i) { fprintf(strm, "%f, ", static_cast<float>(tmp[i])); if (split_rows && ((i + 1) % 10) == 0) fprintf(strm, "\n"); } if (!split_rows || (size % 10) != 0) { fprintf(strm, "\n"); } free(tmp);}template <typename T>void printToScreen(const T* result, const int size){ printToStream(result, size, stdout);}template <typename T>void print2dToStream(const T* result, const int r, const int c, const int stride, FILE* strm){ if (result == nullptr) { TLLM_LOG_WARNING("It is an nullptr, skip! \n"); return; } for (int ri = 0; ri < r; ++ri) { const T* ptr = result + ri * stride; printToStream(ptr, c, strm); } fprintf(strm, "\n");}template <typename T>void print2dToScreen(const T* result, const int r, const int c, const int stride){ print2dToStream(result, r, c, stride, stdout);}inline void print_float_(float x){ printf("%7.3f ", x);}inline void print_element_(float x){ print_float_(x);}inline void print_element_(half x){ print_float_((float) x);}#ifdef ENABLE_BF16inline void print_element_(__nv_bfloat16 x){ print_float_((float) x);}#endifinline void print_element_(uint32_t ul){ printf("%7" PRIu32, ul);}inline void print_element_(uint64_t ull){ printf("%7" PRIu64, ull);}inline void print_element_(int32_t il){ printf("%7" PRId32, il);}inline void print_element_(int64_t ill){ printf("%7" PRId64, ill);}template <typename T>inline void printMatrix(const T* ptr, int m, int k, int stride, bool is_device_ptr){ T* tmp; if (is_device_ptr) { // k < stride ; stride = col-dimension. tmp = reinterpret_cast<T*>(malloc(m * stride * sizeof(T))); check_cuda_error(cudaMemcpy(tmp, ptr, sizeof(T) * m * stride, cudaMemcpyDeviceToHost)); cudaDeviceSynchronize(); } else { tmp = const_cast<T*>(ptr); } for (int ii = -1; ii < m; ++ii) { if (ii >= 0) { printf("%07d ", ii); } else { printf(" "); } for (int jj = 0; jj < k; jj += 1) { if (ii >= 0) { print_element_(tmp[ii * stride + jj]); } else { printf("%7d ", jj); } } printf("\n"); } if (is_device_ptr) { free(tmp); }}template void printMatrix(const float* ptr, int m, int k, int stride, bool is_device_ptr);template void printMatrix(const half* ptr, int m, int k, int stride, bool is_device_ptr);#ifdef ENABLE_BF16template void printMatrix(const __nv_bfloat16* ptr, int m, int k, int stride, bool is_device_ptr);#endiftemplate void printMatrix(const uint32_t* ptr, int m, int k, int stride, bool is_device_ptr);template void printMatrix(const uint64_t* ptr, int m, int k, int stride, bool is_device_ptr);template void printMatrix(const int* ptr, int m, int k, int stride, bool is_device_ptr);代码 printf("%7" PRId64, ill) 是C/C++语言中一种用于格式化输出64位有符号整数的跨平台写法。下面我来详细解释它的各个部分。
代码含义详解
1. int64_t类型代码中的变量ill应该是int64_t类型(从格式符推断)。这是在stdint.h(C语言)或cstdint(C++)头文件中定义的固定宽度整数类型,保证在所有平台上都恰好占用64位(8字节)。使用这种类型可以确保代码在不同平台上有明确的数据长度。2. 格式说明符 %7" PRId64这是整个格式字符串的核心,由两部分拼接而成:• %7:这是一个字段宽度说明符。数字7指定了输出值的最小宽度为7个字符。如果实际数值的位数少于7位,输出会在左侧(默认右对齐)用空格填充以达到指定宽度;如果数值位数超过7位,则会按实际宽度完整输出。• PRId64:这是一个在inttypes.h(C语言)或cinttypes(C++)中定义的宏。它的主要作用是提供一个与int64_t类型匹配的格式化符号(如d),并确保跨平台兼容性。在预编译阶段,PRId64会根据当前编译环境被展开为特定的字符串。例如,在64位Linux系统上,它通常被定义为"ld";而在32位系统或Windows环境下,则可能被定义为"lld"或"I64d"。3. 字符串字面量的拼接C/C++语法允许将多个用空格分隔的字符串字面量自动连接成一个字符串。因此, "%7"和宏展开后的PRId64会在编译前合并。例如,在64位Linux系统上,"%7" PRId64最终会组合成字符串"%7ld"。4. 整行代码的效果所以, printf("%7" PRId64, ill)这行代码的最终目的是:以至少7个字符的宽度,右对齐打印一个64位有符号整数ill。
使用注意事项与最佳实践
1. 包含正确的头文件为了使用 PRId64和int64_t,你需要在源代码中包含相应的头文件。• 在C语言中: #include <inttypes.h>和#include <stdint.h>。• 在C++中:推荐使用 #include <cinttypes>和#include <cstdint>。2. C++中的特殊处理在某些C编译标准下(如C11之前),使用 PRId64可能需要先定义宏__STDC_FORMAT_MACROS以启用这些格式宏。最稳妥的做法是:• 使用C++11或更新标准进行编译。 • 或者在包含头文件之前定义该宏: #define __STDC_FORMAT_MACROS#include <cinttypes>// 或者 #include <inttypes.h>3. 正确的参数类型确保传递给 printf的变量ill的类型确实是int64_t(或等价的long long,long,这取决于平台和typedef)。类型不匹配可能导致未定义行为。
一个简单的例子
#include <stdio.h>#include <stdint.h> // 提供 int64_t 的定义#include <inttypes.h> // 提供 PRId64 的定义int main() { int64_t my_number = -12345; printf("The value is: '%7" PRId64 "'\n", my_number); return 0;}假设在64位系统上,PRId64 展开为 "ld",输出可能类似于:
The value is: ' -12345'(注意数字 -12345 连负号共6个字符,因此在左侧填充了一个空格以达到总共7个字符的宽度。)
cudaAllocator
#include <cuda_runtime.h>class CudaAllocator : public IAllocator{public:explicit CudaAllocator(runtime::BufferManager bufferManager); ~CudaAllocator() override = default;void free(void** ptr) override;protected:bool contains(void const* ptr) const override{ return mPointerMapping.find(ptr) != mPointerMapping.end(); } ReallocType reallocType(void const* ptr, size_t size) const override;void* malloc(size_t size, bool setZero) override;void memSet(void* ptr, int val, size_t size) override;private: runtime::BufferManager mBufferManager; std::unordered_map<void const*, runtime::BufferManager::IBufferPtr> mPointerMapping{};};using namespace tensorrt_llm::common;namespace tr = tensorrt_llm::runtime;CudaAllocator::CudaAllocator(tr::BufferManager bufferManager) : mBufferManager(std::move(bufferManager)){}ReallocType CudaAllocator::reallocType(void const* ptr, size_t size) const{ TLLM_CHECK(contains(ptr)); auto const currentSize = mPointerMapping.at(ptr)->getSize(); TLLM_LOG_DEBUG("current_buffer_size: %d, original buffer: %p, new buffer: %d", currentSize, ptr, size); if (currentSize < size) { return ReallocType::INCREASE; } else if (currentSize == size) { return ReallocType::REUSE; } else { return ReallocType::DECREASE; }}void* CudaAllocator::malloc(std::size_t size, bool const setZero){ TLLM_LOG_DEBUG(__PRETTY_FUNCTION__); auto bufferPtr = mBufferManager.gpu(size); if (setZero) { mBufferManager.setZero(*bufferPtr); } void* ptr{bufferPtr->data()}; TLLM_LOG_DEBUG("malloc buffer %p with size %ld", ptr, size); mPointerMapping.insert({ptr, std::move(bufferPtr)}); return ptr;}void CudaAllocator::free(void** ptr){ TLLM_LOG_DEBUG(__PRETTY_FUNCTION__); mPointerMapping.erase(*ptr); *ptr = nullptr;}void CudaAllocator::memSet(void* ptr, int const val, size_t const size){ check_cuda_error(cudaMemsetAsync(ptr, val, size, mBufferManager.getStream().get()));}参考文献
• https://github.com/NVIDIA/TensorRT-LLM/blob/release/0.5.0/cpp/tensorrt_llm/common/cudaAllocator.h • https://github.com/NVIDIA/TensorRT-LLM/blob/release/0.5.0/cpp/tensorrt_llm/common/cudaUtils.h
