Qemu中PCI设备透传源码分析

很多人说Qemu的PCI-Assign透传不支持IOMMU，而VFIO透传却可以。而从原理上来说，VFIO跟IOMMU并非有必然联系，都是软件实现的，为什么PCI-Assign不可以，而VFIO可以呢？这不科学！还是到源码里看一下吧！

PCI-Assign透传的基本使用步骤

随便在网上找一个PCI-Assign透传的使用方法：

How to use 'pci pass-through' to run Linux in Qemu accessing real Ath9k adapter===============================================================================# Boot kernel with 'intel_iommu=on'# Unbind driver from the device and bind 'pci-stub' to it$ echo"168c 0030" > /sys/bus/pci/drivers/pci-stub/new_id$ echo 0000:0b:00.0 > /sys/bus/pci/devices/0000:0b:00.0/driver/unbind$ echo 0000:0b:00.0 > /sys/bus/pci/drivers/pci-stub/bind# Then just run$ sudo qemu-system-i386 -m 1024 \ -device pci-assign,host=0b:00.0,rombar=0 \ -enable-kvm \ -kernel $KERNEL \ -hda $DISK \ -boot c \ -append "root=/dev/sda rw"# In case ofqemu-system-i386: -device pci-assign,host=0b:00.0: Failed to assign device "(null)" : Operation not permittedqemu-system-i386: -device pci-assign,host=0b:00.0: Device initialization failed.qemu-system-i386: -device pci-assign,host=0b:00.0: Device 'kvm-pci-assign' could not be initialized$ dmesg | tail[  112.129138] kvm_iommu_map_guest: No interrupt remapping support, disallowing device assignment. Re-enble with "allow_unsafe_assigned_interrupts=1" module option.# run$ echo 1 > /sys/module/kvm/parameters/allow_unsafe_assigned_interrupts

总结一下基本步骤：

1. 在内核启动参数中配置intel_iommu=on，开启IOMMU（从这里就可以看出，PCI-Assign不支持IOMMU的话，要配置IOMMU干什么呢？）；
2. 向pci-stub驱动的new_id文件写入要绑定设备的VendorID和DeviceID；
3. 把PCI设备与原有驱动解绑；
4. 把PCI设备绑定到pci-stub驱动上。
5. 在Qemu上以PCI设备的PCI地址为形参启动虚拟机。

疑问：我们知道用户态程序使用一个设备，必须要使用它的用户态接口，通常就是一个设备文件，而这里指定一个地址是什么意思？Qemu是如何使用这个PCI设备的？

PCI设备与pci-stub驱动绑定

接下来我们就看看这个pci-stub驱动到底是怎么绑定到PCI设备上的。

驱动内核模块加载时绑定

• 这是内核中pci-stub驱动的源码，如果在模块加载时指定了ids参数，将会在加载时为这个pci-stub驱动动态增加匹配的VendorID和DeviceID。我们知道，Linux内核的Device、Driver和Bus驱动模型中，PCI总线是通过VendorID和DeviceID进行匹配的，因此这时就可对应的PCI设备进行了匹配绑定。同时，这个驱动啥都没干，没有提供任何上层的应用接口，比如说字符设备或者块设备等（drivers/pci/pci-stub.c）：

// SPDX-License-Identifier: GPL-2.0/* * Simple stub driver to reserve a PCI device * * Copyright (C) 2008 Red Hat, Inc. * Author: * Chris Wright * * Usage is simple, allocate a new id to the stub driver and bind the * device to it.  For example: * * # echo "8086 10f5" > /sys/bus/pci/drivers/pci-stub/new_id * # echo -n 0000:00:19.0 > /sys/bus/pci/drivers/e1000e/unbind * # echo -n 0000:00:19.0 > /sys/bus/pci/drivers/pci-stub/bind * # ls -l /sys/bus/pci/devices/0000:00:19.0/driver * .../0000:00:19.0/driver -> ../../../bus/pci/drivers/pci-stub */#include<linux/module.h>#include<linux/pci.h>staticchar ids[1024] __initdata;module_param_string(ids, ids, sizeof(ids), 0);MODULE_PARM_DESC(ids, "Initial PCI IDs to add to the stub driver, format is ""\"vendor:device[:subvendor[:subdevice[:class[:class_mask]]]]\""" and multiple comma separated entries can be specified");staticintpci_stub_probe(struct pci_dev *dev, const struct pci_device_id *id){ pci_info(dev, "claimed by stub\n");return0;}staticstructpci_driverstub_driver = { .name  = "pci-stub", .id_table = NULL, /* only dynamic id's */ .probe  = pci_stub_probe,};staticint __init pci_stub_init(void){char *p, *id;int rc; rc = pci_register_driver(&stub_driver);if (rc)return rc;/* no ids passed actually */if (ids[0] == '\0')return0;/* add ids specified in the module parameter */ p = ids;while ((id = strsep(&p, ","))) {unsignedint vendor, device, subvendor = PCI_ANY_ID,   subdevice = PCI_ANY_ID, class = 0, class_mask = 0;int fields;if (!strlen(id))continue;  fields = sscanf(id, "%x:%x:%x:%x:%x:%x",    &vendor, &device, &subvendor, &subdevice,    &class, &class_mask);if (fields < 2) {   printk(KERN_WARNING"pci-stub: invalid id string \"%s\"\n", id);continue;  }  printk(KERN_INFO"pci-stub: add %04X:%04X sub=%04X:%04X cls=%08X/%08X\n",         vendor, device, subvendor, subdevice, class, class_mask);  rc = pci_add_dynid(&stub_driver, vendor, device,       subvendor, subdevice, class, class_mask, 0);if (rc)   printk(KERN_WARNING"pci-stub: failed to add dynamic id (%d)\n", rc); }return0;}staticvoid __exit pci_stub_exit(void){ pci_unregister_driver(&stub_driver);}module_init(pci_stub_init);module_exit(pci_stub_exit);MODULE_LICENSE("GPL");MODULE_AUTHOR("Chris Wright <chrisw@sous-sol.org>");

• 我们再看看pci_add_dynid这个函数的实现，他申请并初始化了一个pci_dynid结构，增加到Driver的一个链表中，最后调用了driver_attach函数触发PCIBus的Device与Driver匹配（drivers/pci/pci-driver.c）：

/** * pci_add_dynid - add a new PCI device ID to this driver and re-probe devices * @drv: target pci driver * @vendor: PCI vendor ID * @device: PCI device ID * @subvendor: PCI subvendor ID * @subdevice: PCI subdevice ID * @class: PCI class * @class_mask: PCI class mask * @driver_data: private driver data * * Adds a new dynamic pci device ID to this driver and causes the * driver to probe for all devices again.  @drv must have been * registered prior to calling this function. * * CONTEXT: * Does GFP_KERNEL allocation. * * RETURNS: * 0 on success, -errno on failure. */intpci_add_dynid(struct pci_driver *drv,unsignedint vendor, unsignedint device,unsignedint subvendor, unsignedint subdevice,unsignedint class, unsignedint class_mask,unsignedlong driver_data){structpci_dynid *dynid; dynid = kzalloc(sizeof(*dynid), GFP_KERNEL);if (!dynid)return -ENOMEM; dynid->id.vendor = vendor; dynid->id.device = device; dynid->id.subvendor = subvendor; dynid->id.subdevice = subdevice; dynid->id.class = class; dynid->id.class_mask = class_mask; dynid->id.driver_data = driver_data; spin_lock(&drv->dynids.lock); list_add_tail(&dynid->node, &drv->dynids.list); spin_unlock(&drv->dynids.lock);return driver_attach(&drv->driver);}EXPORT_SYMBOL_GPL(pci_add_dynid);

• driver_attach遍历PCIBus上的所有Device，使用VendorID和DeviceID与Driver进行匹配（匹配方法由Bus驱动提供）和绑定（drivers/base/dd.c）：

staticint __driver_attach(struct device *dev, void *data){structdevice_driver *drv = data;int ret;/*  * Lock device and try to bind to it. We drop the error  * here and always return 0, because we need to keep trying  * to bind to devices and some drivers will return an error  * simply if it didn't support the device.  *  * driver_probe_device() will spit a warning if there  * is an error.  */ ret = driver_match_device(drv, dev);if (ret == 0) {/* no match */return0; } elseif (ret == -EPROBE_DEFER) {  dev_dbg(dev, "Device match requests probe deferral\n");  driver_deferred_probe_add(dev); } elseif (ret < 0) {  dev_dbg(dev, "Bus failed to match device: %d", ret);return ret; } /* ret > 0 means positive match */if (dev->parent) /* Needed for USB */  device_lock(dev->parent); device_lock(dev);if (!dev->driver)  driver_probe_device(drv, dev); device_unlock(dev);if (dev->parent)  device_unlock(dev->parent);return0;}/** * driver_attach - try to bind driver to devices. * @drv: driver. * * Walk the list of devices that the bus has on it and try to * match the driver with each one.  If driver_probe_device() * returns 0 and the @dev->driver is set, we've found a * compatible pair. */intdriver_attach(struct device_driver *drv){return bus_for_each_dev(drv->bus, NULL, drv, __driver_attach);}EXPORT_SYMBOL_GPL(driver_attach);

通过设备的sysfs文件绑定

• PCIBus驱动在注册时分别注册了三个（Bus、Device、Driver）的SysFS属性组，而Driver的SysFS属性组包含new_id这个SysFS属性文件。在对这个文件的进行设置的函数new_id_store中，写入数据中解析出VendorID和DeviceID，最后调用pci_add_dynid进行与设备的绑定（drivers/pci/pci-driver.c）：

/** * store_new_id - sysfs frontend to pci_add_dynid() * @driver: target device driver * @buf: buffer for scanning device ID data * @count: input size * * Allow PCI IDs to be added to an existing driver via sysfs. */staticssize_tnew_id_store(struct device_driver *driver, constchar *buf,size_t count){structpci_driver *pdrv = to_pci_driver(driver);conststructpci_device_id *ids = pdrv->id_table; __u32 vendor, device, subvendor = PCI_ANY_ID,  subdevice = PCI_ANY_ID, class = 0, class_mask = 0;unsignedlong driver_data = 0;int fields = 0;int retval = 0; fields = sscanf(buf, "%x %x %x %x %x %x %lx",   &vendor, &device, &subvendor, &subdevice,   &class, &class_mask, &driver_data);if (fields < 2)return -EINVAL;if (fields != 7) {structpci_dev *pdev = kzalloc(sizeof(*pdev), GFP_KERNEL);if (!pdev)return -ENOMEM;  pdev->vendor = vendor;  pdev->device = device;  pdev->subsystem_vendor = subvendor;  pdev->subsystem_device = subdevice;  pdev->class = class;if (pci_match_id(pdrv->id_table, pdev))   retval = -EEXIST;  kfree(pdev);if (retval)return retval; }/* Only accept driver_data values that match an existing id_table    entry */if (ids) {  retval = -EINVAL;while (ids->vendor || ids->subvendor || ids->class_mask) {if (driver_data == ids->driver_data) {    retval = 0;break;   }   ids++;  }if (retval) /* No match */return retval; } retval = pci_add_dynid(pdrv, vendor, device, subvendor, subdevice,          class, class_mask, driver_data);if (retval)return retval;return count;}staticDRIVER_ATTR_WO(new_id);staticstructattribute *pci_drv_attrs[] = { &driver_attr_new_id.attr, &driver_attr_remove_id.attr,NULL,};ATTRIBUTE_GROUPS(pci_drv);structbus_typepci_bus_type = { .name  = "pci", .match  = pci_bus_match, .uevent  = pci_uevent, .probe  = pci_device_probe, .remove  = pci_device_remove, .shutdown = pci_device_shutdown, .dev_groups = pci_dev_groups, .bus_groups = pci_bus_groups, .drv_groups = pci_drv_groups, .pm  = PCI_PM_OPS_PTR, .num_vf  = pci_bus_num_vf, .force_dma = true,};EXPORT_SYMBOL(pci_bus_type);staticint __init pci_driver_init(void){return bus_register(&pci_bus_type);}postcore_initcall(pci_driver_init);

Qemu中的pci-assign设备

• 快速查一下Qemu源码中引用pci-assign的位置，我们要看的源码应该就在hw/i386/kvm/pci-assign.c这个位置（至于为什么？自己猜）：

$ grep -rHn pci-assignhw/i386/kvm/pci-assign.c:868:    error_report("pci-assign: error: requires KVM with in-kernel irqchip "hw/i386/kvm/pci-assign.c:1058: * because this is what worked for pci-assign for a long time.  This makeshw/i386/kvm/pci-assign.c:1677:    .name = "pci-assign",hw/i386/kvm/pci-assign.c:1745:        error_report("pci-assign: error: requires KVM support");hw/i386/kvm/pci-assign.c:1754:        error_report("pci-assign: Maximum supported assigned devices (%d) "hw/i386/kvm/pci-assign.c:1761:        error_report("pci-assign: error: no host device specified");hw/i386/kvm/pci-assign.c:1787:        error_report("pci-assign: Error: Couldn't get real device (%s)!",hw/i386/kvm/pci-assign.c:1879:    .name               = "kvm-pci-assign",hw/i386/kvm/pci-assign.c:1920:        error_report("pci-assign: Insufficient privileges for %s", rom_file);hw/i386/kvm/pci-assign.c:1943:        error_report("pci-assign: Cannot read from host %s", rom_file);hw/i386/kvm/Makefile.objs:1:obj-y += clock.o apic.o i8259.o ioapic.o i8254.o pci-assign.oqdev-monitor.c:50:    { "kvm-pci-assign", "pci-assign" },docs/qdev-device-use.txt:379:    -device pci-assign,host=ADDR,iommu=IOMMU,id=ID

注册pci-assign设备

• 查看pci-assign设备的注册，从其类型定义中可以看出，使用 assigned_realize函数进行设备的初始化（hw/i386/kvm/pci-assign.c）：

staticvoidassign_class_init(ObjectClass *klass, void *data){    PCIDeviceClass *k = PCI_DEVICE_CLASS(klass);    DeviceClass *dc = DEVICE_CLASS(klass);    k->realize      = assigned_realize;    k->exit         = assigned_exitfn;    k->config_read  = assigned_dev_pci_read_config;    k->config_write = assigned_dev_pci_write_config;    dc->props       = assigned_dev_properties;    dc->vmsd        = &vmstate_assigned_device;    dc->reset       = reset_assigned_device;    set_bit(DEVICE_CATEGORY_MISC, dc->categories);    dc->desc        = "KVM-based PCI passthrough";}staticconst TypeInfo assign_info = {    .name               = TYPE_PCI_ASSIGN,    .parent             = TYPE_PCI_DEVICE,    .instance_size      = sizeof(AssignedDevice),    .class_init         = assign_class_init,    .instance_init      = assigned_dev_instance_init,};staticvoidassign_register_types(void){    type_register_static(&assign_info);}

实例化pci-assign设备

• 实例化设备函数 assigned_realize如下（hw/i386/kvm/pci-assign.c）：

staticvoidassigned_realize(struct PCIDevice *pci_dev, Error **errp){    AssignedDevice *dev = PCI_ASSIGN(pci_dev);uint8_t e_intx;int r;    Error *local_err = NULL;// 如果不支持KVM，直接报错：if (!kvm_enabled()) {        error_setg(&local_err, "pci-assign requires KVM support");goto exit_with_error;    }if (!dev->host.domain && !dev->host.bus && !dev->host.slot &&        !dev->host.function) {        error_setg(&local_err, "no host device specified");goto exit_with_error;    }// 初始化模拟设备的配置数据，Qemu在Host内存中申请了一块区域用于模拟PCI的配置空间数据，同时保持与真实设备的同步更新。/*     * Set up basic config space access control. Will be further refined during     * device initialization.     */    assigned_dev_emulate_config_read(dev, 0, PCI_CONFIG_SPACE_SIZE);    assigned_dev_direct_config_read(dev, PCI_STATUS, 2);    assigned_dev_direct_config_read(dev, PCI_REVISION_ID, 1);    assigned_dev_direct_config_read(dev, PCI_CLASS_PROG, 3);    assigned_dev_direct_config_read(dev, PCI_CACHE_LINE_SIZE, 1);    assigned_dev_direct_config_read(dev, PCI_LATENCY_TIMER, 1);    assigned_dev_direct_config_read(dev, PCI_BIST, 1);    assigned_dev_direct_config_read(dev, PCI_CARDBUS_CIS, 4);    assigned_dev_direct_config_read(dev, PCI_SUBSYSTEM_VENDOR_ID, 2);    assigned_dev_direct_config_read(dev, PCI_SUBSYSTEM_ID, 2);    assigned_dev_direct_config_read(dev, PCI_CAPABILITY_LIST + 1, 7);    assigned_dev_direct_config_read(dev, PCI_MIN_GNT, 1);    assigned_dev_direct_config_read(dev, PCI_MAX_LAT, 1);memcpy(dev->emulate_config_write, dev->emulate_config_read,sizeof(dev->emulate_config_read));// 从PCI设备的SysFS属性文件中读PCI设备的配置数据，并保存起来：    get_real_device(dev, &local_err);if (local_err) {goto out;    }// 从配置数据中解析设备属性，并根据需要进行修改：if (assigned_device_pci_cap_init(pci_dev, &local_err) < 0) {goto out;    }// 如果支持MSIX，对MSIX内存进行MMIO内存映射：/* intercept MSI-X entry page in the MMIO */if (dev->cap.available & ASSIGNED_DEVICE_CAP_MSIX) {        assigned_dev_register_msix_mmio(dev, &local_err);if (local_err) {goto out;        }    }// 为PCI设备的MMIO/PIO BARs注册对应的虚拟机内存空间：/* handle real device's MMIO/PIO BARs */    assigned_dev_register_regions(dev->real_device.regions,                                  dev->real_device.region_number, dev,                                  &local_err);if (local_err) {goto out;    }/* handle interrupt routing */    e_intx = dev->dev.config[PCI_INTERRUPT_PIN] - 1;    dev->intpin = e_intx;    dev->intx_route.mode = PCI_INTX_DISABLED;    dev->intx_route.irq = -1;// 通过ioctl调用KVM内核模块，进行IOMMU等的配置和初始化：/* assign device to guest */    assign_device(dev, &local_err);if (local_err) {goto out;    }// 新型传统的INTX型中断模拟初始化：/* assign legacy INTx to the device */    r = assign_intx(dev, &local_err);if (r < 0) {goto assigned_out;    }    assigned_dev_load_option_rom(dev);return;assigned_out:    deassign_device(dev);out:    free_assigned_device(dev);exit_with_error:    assert(local_err);    error_propagate(errp, local_err);}

初始化模拟配置数据

• PCI-Assign设备的私有数据结构，集成自基类PCIDevice，可以看到模拟设备的配置空间数据都保存在这里，对其进行读写只不过是修改那个数组里的内存而已，然后会在设备Reset时（这个就不分析了）写入真实的物理设备（hw/i386/kvm/pci-assign.c）：

typedefstructAssignedDevice {    PCIDevice dev;    PCIHostDeviceAddress host;uint32_t dev_id;uint32_t features;int intpin;    AssignedDevRegion v_addrs[PCI_NUM_REGIONS - 1];    PCIDevRegions real_device;    PCIINTxRoute intx_route;    AssignedIRQType assigned_irq_type;struct {#define ASSIGNED_DEVICE_CAP_MSI (1 << 0)#define ASSIGNED_DEVICE_CAP_MSIX (1 << 1)uint32_t available;#define ASSIGNED_DEVICE_MSI_ENABLED (1 << 0)#define ASSIGNED_DEVICE_MSIX_ENABLED (1 << 1)#define ASSIGNED_DEVICE_MSIX_MASKED (1 << 2)uint32_t state;    } cap;uint8_t emulate_config_read[PCI_CONFIG_SPACE_SIZE];uint8_t emulate_config_write[PCI_CONFIG_SPACE_SIZE];int msi_virq_nr;int *msi_virq;    MSIXTableEntry *msix_table;    hwaddr msix_table_addr;uint16_t msix_table_size;uint16_t msix_max;    MemoryRegion mmio;char *configfd_name;int32_t bootindex;} AssignedDevice;staticvoidassigned_dev_emulate_config_read(AssignedDevice *dev,uint32_t offset, uint32_t len){memset(dev->emulate_config_read + offset, 0xff, len);}staticvoidassigned_dev_direct_config_read(AssignedDevice *dev,uint32_t offset, uint32_t len){memset(dev->emulate_config_read + offset, 0, len);}staticvoidassigned_dev_direct_config_write(AssignedDevice *dev,uint32_t offset, uint32_t len){memset(dev->emulate_config_write + offset, 0, len);}

读取设备真实配置数据

• get_real_device在读取PCI物理设备的配置数据时，实际上读取的是Device的SysFS属性文件config，并保存在私有数据结构的config变量中，然后再通过读取resource和遍历resource%d，获取这个PCI设备的全部资源，每个resource其实都是一个PCI的BAR资源，同时打开这些资源的SysFS属性文件，保存其fd：

staticvoidget_real_device(AssignedDevice *pci_dev, Error **errp){char dir[128], name[128];int fd, r = 0;    FILE *f;uint64_t start, end, size, flags;uint16_t id;    PCIRegion *rp;    PCIDevRegions *dev = &pci_dev->real_device;    Error *local_err = NULL;    dev->region_number = 0;snprintf(dir, sizeof(dir), "/sys/bus/pci/devices/%04x:%02x:%02x.%x/",             pci_dev->host.domain, pci_dev->host.bus,             pci_dev->host.slot, pci_dev->host.function);snprintf(name, sizeof(name), "%sconfig", dir);if (pci_dev->configfd_name && *pci_dev->configfd_name) {        dev->config_fd = monitor_fd_param(cur_mon, pci_dev->configfd_name,                                          &local_err);if (local_err) {            error_propagate(errp, local_err);return;        }    } else {        dev->config_fd = open(name, O_RDWR);if (dev->config_fd == -1) {            error_setg_file_open(errp, errno, name);return;        }    }again:    r = read(dev->config_fd, pci_dev->dev.config,             pci_config_size(&pci_dev->dev));if (r < 0) {if (errno == EINTR || errno == EAGAIN) {goto again;        }        error_setg_errno(errp, errno, "read(\"%s\")",                         (pci_dev->configfd_name && *pci_dev->configfd_name) ?                         pci_dev->configfd_name : name);return;    }/* Restore or clear multifunction, this is always controlled by qemu */if (pci_dev->dev.cap_present & QEMU_PCI_CAP_MULTIFUNCTION) {        pci_dev->dev.config[PCI_HEADER_TYPE] |= PCI_HEADER_TYPE_MULTI_FUNCTION;    } else {        pci_dev->dev.config[PCI_HEADER_TYPE] &= ~PCI_HEADER_TYPE_MULTI_FUNCTION;    }/* Clear host resource mapping info.  If we choose not to register a     * BAR, such as might be the case with the option ROM, we can get     * confusing, unwritable, residual addresses from the host here. */memset(&pci_dev->dev.config[PCI_BASE_ADDRESS_0], 0, 24);memset(&pci_dev->dev.config[PCI_ROM_ADDRESS], 0, 4);snprintf(name, sizeof(name), "%sresource", dir);    f = fopen(name, "r");if (f == NULL) {        error_setg_file_open(errp, errno, name);return;    }for (r = 0; r < PCI_ROM_SLOT; r++) {if (fscanf(f, "%" SCNi64 " %" SCNi64 " %" SCNi64 "\n",                   &start, &end, &flags) != 3) {break;        }        rp = dev->regions + r;        rp->valid = 0;        rp->resource_fd = -1;        size = end - start + 1;        flags &= IORESOURCE_IO | IORESOURCE_MEM | IORESOURCE_PREFETCH                 | IORESOURCE_MEM_64;if (size == 0 || (flags & ~IORESOURCE_PREFETCH) == 0) {continue;        }if (flags & IORESOURCE_MEM) {            flags &= ~IORESOURCE_IO;        } else {            flags &= ~IORESOURCE_PREFETCH;        }snprintf(name, sizeof(name), "%sresource%d", dir, r);        fd = open(name, O_RDWR);if (fd == -1) {continue;        }        rp->resource_fd = fd;        rp->type = flags;        rp->valid = 1;        rp->base_addr = start;        rp->size = size;        pci_dev->v_addrs[r].region = rp;        DEBUG("region %d size %" PRIu64 " start 0x%" PRIx64" type %d resource_fd %d\n",              r, rp->size, start, rp->type, rp->resource_fd);    }    fclose(f);/* read and fill vendor ID */    get_real_vendor_id(dir, &id, &local_err);if (local_err) {        error_propagate(errp, local_err);return;    }    pci_dev->dev.config[0] = id & 0xff;    pci_dev->dev.config[1] = (id & 0xff00) >> 8;/* read and fill device ID */    get_real_device_id(dir, &id, &local_err);if (local_err) {        error_propagate(errp, local_err);return;    }    pci_dev->dev.config[2] = id & 0xff;    pci_dev->dev.config[3] = (id & 0xff00) >> 8;    pci_word_test_and_clear_mask(pci_dev->emulate_config_write + PCI_COMMAND,                                 PCI_COMMAND_MASTER | PCI_COMMAND_INTX_DISABLE);    dev->region_number = r;}

解析和设置设备配置

• 从刚才读取的二进制PCI配置数据中分析设备的属性，并进行一些初始设定：

staticintassigned_device_pci_cap_init(PCIDevice *pci_dev, Error **errp){    AssignedDevice *dev = PCI_ASSIGN(pci_dev);    PCIRegion *pci_region = dev->real_device.regions;int ret, pos;/* Clear initial capabilities pointer and status copied from hw */    pci_set_byte(pci_dev->config + PCI_CAPABILITY_LIST, 0);    pci_set_word(pci_dev->config + PCI_STATUS,                 pci_get_word(pci_dev->config + PCI_STATUS) &                 ~PCI_STATUS_CAP_LIST);/* Expose MSI capability     * MSI capability is the 1st capability in capability config */    pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_MSI, 0);if (pos != 0 && kvm_check_extension(kvm_state, KVM_CAP_ASSIGN_DEV_IRQ)) {if (verify_irqchip_in_kernel(errp) < 0) {return -ENOTSUP;        }        dev->dev.cap_present |= QEMU_PCI_CAP_MSI;        dev->cap.available |= ASSIGNED_DEVICE_CAP_MSI;/* Only 32-bit/no-mask currently supported */        ret = pci_add_capability(pci_dev, PCI_CAP_ID_MSI, pos, 10,                                  errp);if (ret < 0) {return ret;        }        pci_dev->msi_cap = pos;        pci_set_word(pci_dev->config + pos + PCI_MSI_FLAGS,                     pci_get_word(pci_dev->config + pos + PCI_MSI_FLAGS) &                     PCI_MSI_FLAGS_QMASK);        pci_set_long(pci_dev->config + pos + PCI_MSI_ADDRESS_LO, 0);        pci_set_word(pci_dev->config + pos + PCI_MSI_DATA_32, 0);/* Set writable fields */        pci_set_word(pci_dev->wmask + pos + PCI_MSI_FLAGS,                     PCI_MSI_FLAGS_QSIZE | PCI_MSI_FLAGS_ENABLE);        pci_set_long(pci_dev->wmask + pos + PCI_MSI_ADDRESS_LO, 0xfffffffc);        pci_set_word(pci_dev->wmask + pos + PCI_MSI_DATA_32, 0xffff);    }/* Expose MSI-X capability */    pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_MSIX, 0);if (pos != 0 && kvm_device_msix_supported(kvm_state)) {int bar_nr;uint32_t msix_table_entry;uint16_t msix_max;if (verify_irqchip_in_kernel(errp) < 0) {return -ENOTSUP;        }        dev->dev.cap_present |= QEMU_PCI_CAP_MSIX;        dev->cap.available |= ASSIGNED_DEVICE_CAP_MSIX;        ret = pci_add_capability(pci_dev, PCI_CAP_ID_MSIX, pos, 12,                                  errp);if (ret < 0) {return ret;        }        pci_dev->msix_cap = pos;        msix_max = (pci_get_word(pci_dev->config + pos + PCI_MSIX_FLAGS) &                    PCI_MSIX_FLAGS_QSIZE) + 1;        msix_max = MIN(msix_max, KVM_MAX_MSIX_PER_DEV);        pci_set_word(pci_dev->config + pos + PCI_MSIX_FLAGS, msix_max - 1);/* Only enable and function mask bits are writable */        pci_set_word(pci_dev->wmask + pos + PCI_MSIX_FLAGS,                     PCI_MSIX_FLAGS_ENABLE | PCI_MSIX_FLAGS_MASKALL);        msix_table_entry = pci_get_long(pci_dev->config + pos + PCI_MSIX_TABLE);        bar_nr = msix_table_entry & PCI_MSIX_FLAGS_BIRMASK;        msix_table_entry &= ~PCI_MSIX_FLAGS_BIRMASK;        dev->msix_table_addr = pci_region[bar_nr].base_addr + msix_table_entry;        dev->msix_table_size = msix_max * sizeof(MSIXTableEntry);        dev->msix_max = msix_max;    }/* Minimal PM support, nothing writable, device appears to NAK changes */    pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_PM, 0);if (pos) {uint16_t pmc;        ret = pci_add_capability(pci_dev, PCI_CAP_ID_PM, pos, PCI_PM_SIZEOF,                                  errp);if (ret < 0) {return ret;        }        assigned_dev_setup_cap_read(dev, pos, PCI_PM_SIZEOF);        pmc = pci_get_word(pci_dev->config + pos + PCI_CAP_FLAGS);        pmc &= (PCI_PM_CAP_VER_MASK | PCI_PM_CAP_DSI);        pci_set_word(pci_dev->config + pos + PCI_CAP_FLAGS, pmc);/* assign_device will bring the device up to D0, so we don't need         * to worry about doing that ourselves here. */        pci_set_word(pci_dev->config + pos + PCI_PM_CTRL,                     PCI_PM_CTRL_NO_SOFT_RESET);        pci_set_byte(pci_dev->config + pos + PCI_PM_PPB_EXTENSIONS, 0);        pci_set_byte(pci_dev->config + pos + PCI_PM_DATA_REGISTER, 0);    }    pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_EXP, 0);if (pos) {uint8_t version, size = 0;uint16_t type, devctl, lnksta;uint32_t devcap, lnkcap;        version = pci_get_byte(pci_dev->config + pos + PCI_EXP_FLAGS);        version &= PCI_EXP_FLAGS_VERS;if (version == 1) {            size = 0x14;        } elseif (version == 2) {/*             * Check for non-std size, accept reduced size to 0x34,             * which is what bcm5761 implemented, violating the             * PCIe v3.0 spec that regs should exist and be read as 0,             * not optionally provided and shorten the struct size.             */            size = MIN(0x3c, PCI_CONFIG_SPACE_SIZE - pos);if (size < 0x34) {                error_setg(errp, "Invalid size PCIe cap-id 0x%x",                           PCI_CAP_ID_EXP);return -EINVAL;            } elseif (size != 0x3c) {                warn_report("%s: PCIe cap-id 0x%x has ""non-standard size 0x%x; std size should be 0x3c",                            __func__, PCI_CAP_ID_EXP, size);            }        } elseif (version == 0) {uint16_t vid, did;            vid = pci_get_word(pci_dev->config + PCI_VENDOR_ID);            did = pci_get_word(pci_dev->config + PCI_DEVICE_ID);if (vid == PCI_VENDOR_ID_INTEL && did == 0x10ed) {/*                 * quirk for Intel 82599 VF with invalid PCIe capability                 * version, should really be version 2 (same as PF)                 */                size = 0x3c;            }        }if (size == 0) {            error_setg(errp, "Unsupported PCI express capability version %d",                       version);return -EINVAL;        }        ret = pci_add_capability(pci_dev, PCI_CAP_ID_EXP, pos, size,                                  errp);if (ret < 0) {return ret;        }        assigned_dev_setup_cap_read(dev, pos, size);        type = pci_get_word(pci_dev->config + pos + PCI_EXP_FLAGS);        type = (type & PCI_EXP_FLAGS_TYPE) >> 4;if (type != PCI_EXP_TYPE_ENDPOINT &&            type != PCI_EXP_TYPE_LEG_END && type != PCI_EXP_TYPE_RC_END) {            error_setg(errp, "Device assignment only supports endpoint ""assignment, device type %d", type);return -EINVAL;        }/* capabilities, pass existing read-only copy         * PCI_EXP_FLAGS_IRQ: updated by hardware, should be direct read *//* device capabilities: hide FLR */        devcap = pci_get_long(pci_dev->config + pos + PCI_EXP_DEVCAP);        devcap &= ~PCI_EXP_DEVCAP_FLR;        pci_set_long(pci_dev->config + pos + PCI_EXP_DEVCAP, devcap);/* device control: clear all error reporting enable bits, leaving         *                 only a few host values.  Note, these are         *                 all writable, but not passed to hw.         */        devctl = pci_get_word(pci_dev->config + pos + PCI_EXP_DEVCTL);        devctl = (devctl & (PCI_EXP_DEVCTL_READRQ | PCI_EXP_DEVCTL_PAYLOAD)) |                  PCI_EXP_DEVCTL_RELAX_EN | PCI_EXP_DEVCTL_NOSNOOP_EN;        pci_set_word(pci_dev->config + pos + PCI_EXP_DEVCTL, devctl);        devctl = PCI_EXP_DEVCTL_BCR_FLR | PCI_EXP_DEVCTL_AUX_PME;        pci_set_word(pci_dev->wmask + pos + PCI_EXP_DEVCTL, ~devctl);/* Clear device status */        pci_set_word(pci_dev->config + pos + PCI_EXP_DEVSTA, 0);/* Link capabilities, expose links and latencues, clear reporting */        lnkcap = pci_get_long(pci_dev->config + pos + PCI_EXP_LNKCAP);        lnkcap &= (PCI_EXP_LNKCAP_SLS | PCI_EXP_LNKCAP_MLW |                   PCI_EXP_LNKCAP_ASPMS | PCI_EXP_LNKCAP_L0SEL |                   PCI_EXP_LNKCAP_L1EL);        pci_set_long(pci_dev->config + pos + PCI_EXP_LNKCAP, lnkcap);/* Link control, pass existing read-only copy.  Should be writable? *//* Link status, only expose current speed and width */        lnksta = pci_get_word(pci_dev->config + pos + PCI_EXP_LNKSTA);        lnksta &= (PCI_EXP_LNKSTA_CLS | PCI_EXP_LNKSTA_NLW);        pci_set_word(pci_dev->config + pos + PCI_EXP_LNKSTA, lnksta);if (version >= 2) {/* Slot capabilities, control, status - not needed for endpoints */            pci_set_long(pci_dev->config + pos + PCI_EXP_SLTCAP, 0);            pci_set_word(pci_dev->config + pos + PCI_EXP_SLTCTL, 0);            pci_set_word(pci_dev->config + pos + PCI_EXP_SLTSTA, 0);/* Root control, capabilities, status - not needed for endpoints */            pci_set_word(pci_dev->config + pos + PCI_EXP_RTCTL, 0);            pci_set_word(pci_dev->config + pos + PCI_EXP_RTCAP, 0);            pci_set_long(pci_dev->config + pos + PCI_EXP_RTSTA, 0);/* Device capabilities/control 2, pass existing read-only copy *//* Link control 2, pass existing read-only copy */        }    }    pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_PCIX, 0);if (pos) {uint16_t cmd;uint32_t status;/* Only expose the minimum, 8 byte capability */        ret = pci_add_capability(pci_dev, PCI_CAP_ID_PCIX, pos, 8,                                  errp);if (ret < 0) {return ret;        }        assigned_dev_setup_cap_read(dev, pos, 8);/* Command register, clear upper bits, including extended modes */        cmd = pci_get_word(pci_dev->config + pos + PCI_X_CMD);        cmd &= (PCI_X_CMD_DPERR_E | PCI_X_CMD_ERO | PCI_X_CMD_MAX_READ |                PCI_X_CMD_MAX_SPLIT);        pci_set_word(pci_dev->config + pos + PCI_X_CMD, cmd);/* Status register, update with emulated PCI bus location, clear         * error bits, leave the rest. */        status = pci_get_long(pci_dev->config + pos + PCI_X_STATUS);        status &= ~(PCI_X_STATUS_BUS | PCI_X_STATUS_DEVFN);        status |= pci_get_bdf(pci_dev);        status &= ~(PCI_X_STATUS_SPL_DISC | PCI_X_STATUS_UNX_SPL |                    PCI_X_STATUS_SPL_ERR);        pci_set_long(pci_dev->config + pos + PCI_X_STATUS, status);    }    pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_VPD, 0);if (pos) {/* Direct R/W passthrough */        ret = pci_add_capability(pci_dev, PCI_CAP_ID_VPD, pos, 8,                                  errp);if (ret < 0) {return ret;        }        assigned_dev_setup_cap_read(dev, pos, 8);/* direct write for cap content */        assigned_dev_direct_config_write(dev, pos + 2, 6);    }/* Devices can have multiple vendor capabilities, get them all */for (pos = 0; (pos = pci_find_cap_offset(pci_dev, PCI_CAP_ID_VNDR, pos));        pos += PCI_CAP_LIST_NEXT) {uint8_t len = pci_get_byte(pci_dev->config + pos + PCI_CAP_FLAGS);/* Direct R/W passthrough */        ret = pci_add_capability(pci_dev, PCI_CAP_ID_VNDR, pos, len,                                  errp);if (ret < 0) {return ret;        }        assigned_dev_setup_cap_read(dev, pos, len);/* direct write for cap content */        assigned_dev_direct_config_write(dev, pos + 2, len - 2);    }/* If real and virtual capability list status bits differ, virtualize the     * access. */if ((pci_get_word(pci_dev->config + PCI_STATUS) & PCI_STATUS_CAP_LIST) !=        (assigned_dev_pci_read_byte(pci_dev, PCI_STATUS) &         PCI_STATUS_CAP_LIST)) {        dev->emulate_config_read[PCI_STATUS] |= PCI_STATUS_CAP_LIST;    }return0;}

注册PCI设备的MSIX资源

• 对PCI设备MSIX中断的模拟，其实是申请一块内存，对这块内存的读写操作进行捕捉，并使用KVM的ioctl进行中断注入（KVM目前已经提供了irqfd的中断注入方法）：

staticuint64_tassigned_dev_msix_mmio_read(void *opaque, hwaddr addr,unsigned size){    AssignedDevice *adev = opaque;uint64_t val;memcpy(&val, (void *)((uint8_t *)adev->msix_table + addr), size);return val;}staticvoidassigned_dev_msix_mmio_write(void *opaque, hwaddr addr,uint64_t val, unsigned size){    AssignedDevice *adev = opaque;    PCIDevice *pdev = &adev->dev;uint16_t ctrl;    MSIXTableEntry orig;int i = addr >> 4;if (i >= adev->msix_max) {return; /* Drop write */    }    ctrl = pci_get_word(pdev->config + pdev->msix_cap + PCI_MSIX_FLAGS);    DEBUG("write to MSI-X table offset 0x%lx, val 0x%lx\n", addr, val);if (ctrl & PCI_MSIX_FLAGS_ENABLE) {        orig = adev->msix_table[i];    }memcpy((uint8_t *)adev->msix_table + addr, &val, size);if (ctrl & PCI_MSIX_FLAGS_ENABLE) {        MSIXTableEntry *entry = &adev->msix_table[i];if (!assigned_dev_msix_masked(&orig) &&            assigned_dev_msix_masked(entry)) {/*             * Vector masked, disable it             *             * XXX It's not clear if we can or should actually attempt             * to mask or disable the interrupt.  KVM doesn't have             * support for pending bits and kvm_assign_set_msix_entry             * doesn't modify the device hardware mask.  Interrupts             * while masked are simply not injected to the guest, so             * are lost.  Can we get away with always injecting an             * interrupt on unmask?             */        } elseif (assigned_dev_msix_masked(&orig) &&                   !assigned_dev_msix_masked(entry)) {/* Vector unmasked */if (i >= adev->msi_virq_nr || adev->msi_virq[i] < 0) {/* Previously unassigned vector, start from scratch */                assigned_dev_update_msix(pdev);return;            } else {/* Update an existing, previously masked vector */                MSIMessage msg;int ret;                msg.address = entry->addr_lo |                    ((uint64_t)entry->addr_hi << 32);                msg.data = entry->data;                ret = kvm_irqchip_update_msi_route(kvm_state,                                                   adev->msi_virq[i], msg,                                                   pdev);if (ret) {                    error_report("Error updating irq routing entry (%d)", ret);                }                kvm_irqchip_commit_routes(kvm_state);            }        }    }}staticconst MemoryRegionOps assigned_dev_msix_mmio_ops = {    .read = assigned_dev_msix_mmio_read,    .write = assigned_dev_msix_mmio_write,    .endianness = DEVICE_NATIVE_ENDIAN,    .valid = {        .min_access_size = 4,        .max_access_size = 8,    },    .impl = {        .min_access_size = 4,        .max_access_size = 8,    },};staticvoidassigned_dev_register_msix_mmio(AssignedDevice *dev, Error **errp){    dev->msix_table = mmap(NULL, dev->msix_table_size, PROT_READ | PROT_WRITE,                           MAP_ANONYMOUS | MAP_PRIVATE, 0, 0);if (dev->msix_table == MAP_FAILED) {        error_setg_errno(errp, errno, "failed to allocate msix_table");        dev->msix_table = NULL;return;    }    dev->dev.msix_table = (uint8_t *)dev->msix_table;    assigned_dev_msix_reset(dev);    memory_region_init_io(&dev->mmio, OBJECT(dev), &assigned_dev_msix_mmio_ops,                          dev, "assigned-dev-msix", dev->msix_table_size);}

• kvm_irqchip_commit_routes函数通过ioctl通知KVM进行中断注入（这是一种目前不被推荐的方法，最新的Qemu和KVM推荐使用irqfd来实现，accel/kvm/kvm-all.c）：

voidkvm_irqchip_commit_routes(KVMState *s){int ret;if (kvm_gsi_direct_mapping()) {return;    }if (!kvm_gsi_routing_enabled()) {return;    }    s->irq_routes->flags = 0;    trace_kvm_irqchip_commit_routes();    ret = kvm_vm_ioctl(s, KVM_SET_GSI_ROUTING, s->irq_routes);    assert(ret == 0);}

注册PCI设备的内存资源

• 注册PCI设备的内存资源，这里直接映射PCI设备的resource%d文件，然后添加到KVM的内存域中，期间不需要Copy，这应该是PCI透传之所以性能高的地方吧：

staticvoidassigned_dev_register_regions(PCIRegion *io_regions,unsignedlong regions_num,                                          AssignedDevice *pci_dev,                                          Error **errp){uint32_t i;    PCIRegion *cur_region = io_regions;for (i = 0; i < regions_num; i++, cur_region++) {if (!cur_region->valid) {continue;        }/* handle memory io regions */if (cur_region->type & IORESOURCE_MEM) {int t = PCI_BASE_ADDRESS_SPACE_MEMORY;if (cur_region->type & IORESOURCE_PREFETCH) {                t |= PCI_BASE_ADDRESS_MEM_PREFETCH;            }if (cur_region->type & IORESOURCE_MEM_64) {                t |= PCI_BASE_ADDRESS_MEM_TYPE_64;            }/* map physical memory */            pci_dev->v_addrs[i].u.r_virtbase = mmap(NULL, cur_region->size,                                                    PROT_WRITE | PROT_READ,                                                    MAP_SHARED,                                                    cur_region->resource_fd,                                                    (off_t)0);if (pci_dev->v_addrs[i].u.r_virtbase == MAP_FAILED) {                pci_dev->v_addrs[i].u.r_virtbase = NULL;                error_setg_errno(errp, errno, "Couldn't mmap 0x%" PRIx64 "!",                                 cur_region->base_addr);return;            }            pci_dev->v_addrs[i].r_size = cur_region->size;            pci_dev->v_addrs[i].e_size = 0;/* add offset */            pci_dev->v_addrs[i].u.r_virtbase +=                (cur_region->base_addr & 0xFFF);if (cur_region->size & 0xFFF) {                error_report("PCI region %d at address 0x%" PRIx64 " has ""size 0x%" PRIx64 ", which is not a multiple of ""4K.  You might experience some performance hit ""due to that.",                             i, cur_region->base_addr, cur_region->size);                memory_region_init_io(&pci_dev->v_addrs[i].real_iomem,                                      OBJECT(pci_dev), &slow_bar_ops,                                      &pci_dev->v_addrs[i],"assigned-dev-slow-bar",                                      cur_region->size);            } else {void *virtbase = pci_dev->v_addrs[i].u.r_virtbase;char name[32];snprintf(name, sizeof(name), "%s.bar%d",                         object_get_typename(OBJECT(pci_dev)), i);                memory_region_init_ram_ptr(&pci_dev->v_addrs[i].real_iomem,                                           OBJECT(pci_dev), name,                                           cur_region->size, virtbase);                vmstate_register_ram(&pci_dev->v_addrs[i].real_iomem,                                     &pci_dev->dev.qdev);            }            assigned_dev_iomem_setup(&pci_dev->dev, i, cur_region->size);            pci_register_bar((PCIDevice *) pci_dev, i, t,                             &pci_dev->v_addrs[i].container);continue;        } else {/* handle port io regions */uint32_t val;int ret;/* Test kernel support for ioport resource read/write.  Old             * kernels return EIO.  New kernels only allow 1/2/4 byte reads             * so should return EINVAL for a 3 byte read */            ret = pread(pci_dev->v_addrs[i].region->resource_fd, &val, 3, 0);if (ret >= 0) {                error_report("Unexpected return from I/O port read: %d", ret);abort();            } elseif (errno != EINVAL) {                error_report("Kernel doesn't support ioport resource ""access, hiding this region.");                close(pci_dev->v_addrs[i].region->resource_fd);                cur_region->valid = 0;continue;            }            pci_dev->v_addrs[i].u.r_baseport = cur_region->base_addr;            pci_dev->v_addrs[i].r_size = cur_region->size;            pci_dev->v_addrs[i].e_size = 0;            assigned_dev_ioport_setup(&pci_dev->dev, i, cur_region->size);            pci_register_bar((PCIDevice *) pci_dev, i,                             PCI_BASE_ADDRESS_SPACE_IO,                             &pci_dev->v_addrs[i].container);        }    }/* success */}

通过KVM分配PCI设备

• 终于调用KVM的PCI设备分配接口了，前面只是做一些简单检查，必须支持IOMMU，后面就进入kvm_device_pci_assign函数了：

staticvoidassign_device(AssignedDevice *dev, Error **errp){uint32_t flags = KVM_DEV_ASSIGN_ENABLE_IOMMU;int r;/* Only pass non-zero PCI segment to capable module */if (!kvm_check_extension(kvm_state, KVM_CAP_PCI_SEGMENT) &&        dev->host.domain) {        error_setg(errp, "Can't assign device inside non-zero PCI segment ""as this KVM module doesn't support it.");return;    }if (!kvm_check_extension(kvm_state, KVM_CAP_IOMMU)) {        error_setg(errp, "No IOMMU found.  Unable to assign device \"%s\"",                   dev->dev.qdev.id);return;    }if (dev->features & ASSIGNED_DEVICE_SHARE_INTX_MASK &&        kvm_has_intx_set_mask()) {        flags |= KVM_DEV_ASSIGN_PCI_2_3;    }    r = kvm_device_pci_assign(kvm_state, &dev->host, flags, &dev->dev_id);if (r < 0) {switch (r) {case -EBUSY: {char *cause;            cause = assign_failed_examine(dev);            error_setg_errno(errp, -r, "Failed to assign device \"%s\"",                             dev->dev.qdev.id);            error_append_hint(errp, "%s", cause);            g_free(cause);break;        }default:            error_setg_errno(errp, -r, "Failed to assign device \"%s\"",                             dev->dev.qdev.id);break;        }    }}

• 最后通过KVM提供的KVM_ASSIGN_PCI_DEVICE功能进行PCI设备分配（target/i386/kvm.c）：

/* Classic KVM device assignment interface. Will remain x86 only. */intkvm_device_pci_assign(KVMState *s, PCIHostDeviceAddress *dev_addr,uint32_t flags, uint32_t *dev_id){structkvm_assigned_pci_devdev_data = {        .segnr = dev_addr->domain,        .busnr = dev_addr->bus,        .devfn = PCI_DEVFN(dev_addr->slot, dev_addr->function),        .flags = flags,    };int ret;    dev_data.assigned_dev_id =        (dev_addr->domain << 16) | (dev_addr->bus << 8) | dev_data.devfn;    ret = kvm_vm_ioctl(s, KVM_ASSIGN_PCI_DEVICE, &dev_data);if (ret < 0) {return ret;    }    *dev_id = dev_data.assigned_dev_id;return0;}

分配PCI传统中断INTX

• 最后在对传统的INTX中断模拟部分进行初始化，最终还是使用KVM实现的这部分捕捉与注入功能：

staticintassign_intx(AssignedDevice *dev, Error **errp){    AssignedIRQType new_type;    PCIINTxRoute intx_route;bool intx_host_msi;int r;/* Interrupt PIN 0 means don't use INTx */if (assigned_dev_pci_read_byte(&dev->dev, PCI_INTERRUPT_PIN) == 0) {        pci_device_set_intx_routing_notifier(&dev->dev, NULL);return0;    }if (verify_irqchip_in_kernel(errp) < 0) {return -ENOTSUP;    }    pci_device_set_intx_routing_notifier(&dev->dev,                                         assigned_dev_update_irq_routing);    intx_route = pci_device_route_intx_to_irq(&dev->dev, dev->intpin);    assert(intx_route.mode != PCI_INTX_INVERTED);if (!pci_intx_route_changed(&dev->intx_route, &intx_route)) {return0;    }switch (dev->assigned_irq_type) {case ASSIGNED_IRQ_INTX_HOST_INTX:case ASSIGNED_IRQ_INTX_HOST_MSI:        intx_host_msi = dev->assigned_irq_type == ASSIGNED_IRQ_INTX_HOST_MSI;        r = kvm_device_intx_deassign(kvm_state, dev->dev_id, intx_host_msi);break;case ASSIGNED_IRQ_MSI:        r = kvm_device_msi_deassign(kvm_state, dev->dev_id);break;case ASSIGNED_IRQ_MSIX:        r = kvm_device_msix_deassign(kvm_state, dev->dev_id);break;default:        r = 0;break;    }if (r) {        perror("assign_intx: deassignment of previous interrupt failed");    }    dev->assigned_irq_type = ASSIGNED_IRQ_NONE;if (intx_route.mode == PCI_INTX_DISABLED) {        dev->intx_route = intx_route;return0;    }retry:if (dev->features & ASSIGNED_DEVICE_PREFER_MSI_MASK &&        dev->cap.available & ASSIGNED_DEVICE_CAP_MSI) {        intx_host_msi = true;        new_type = ASSIGNED_IRQ_INTX_HOST_MSI;    } else {        intx_host_msi = false;        new_type = ASSIGNED_IRQ_INTX_HOST_INTX;    }    r = kvm_device_intx_assign(kvm_state, dev->dev_id, intx_host_msi,                               intx_route.irq);if (r < 0) {if (r == -EIO && !(dev->features & ASSIGNED_DEVICE_PREFER_MSI_MASK) &&            dev->cap.available & ASSIGNED_DEVICE_CAP_MSI) {/* Retry with host-side MSI. There might be an IRQ conflict and             * either the kernel or the device doesn't support sharing. */            error_report("Host-side INTx sharing not supported, ""using MSI instead");            error_printf("Some devices do not work properly in this mode.\n");            dev->features |= ASSIGNED_DEVICE_PREFER_MSI_MASK;goto retry;        }        error_setg_errno(errp, -r, "Failed to assign irq for \"%s\"",                         dev->dev.qdev.id);        error_append_hint(errp, "Perhaps you are assigning a device ""that shares an IRQ with another device?\n");return r;    }    dev->intx_route = intx_route;    dev->assigned_irq_type = new_type;return r;}/* The pci config space got updated. Check if irq numbers have changed * for our devices */staticvoidassigned_dev_update_irq_routing(PCIDevice *dev){    AssignedDevice *assigned_dev = PCI_ASSIGN(dev);    Error *err = NULL;int r;    r = assign_intx(assigned_dev, &err);if (r < 0) {        error_report_err(err);        err = NULL;        qdev_unplug(&dev->qdev, &err);        assert(!err);    }}intkvm_device_intx_assign(KVMState *s, uint32_t dev_id, bool use_host_msi,uint32_t guest_irq){uint32_t irq_type = KVM_DEV_IRQ_GUEST_INTX |        (use_host_msi ? KVM_DEV_IRQ_HOST_MSI : KVM_DEV_IRQ_HOST_INTX);return kvm_assign_irq_internal(s, dev_id, irq_type, guest_irq);}staticintkvm_assign_irq_internal(KVMState *s, uint32_t dev_id,uint32_t irq_type, uint32_t guest_irq){structkvm_assigned_irqassigned_irq = {        .assigned_dev_id = dev_id,        .guest_irq = guest_irq,        .flags = irq_type,    };if (kvm_check_extension(s, KVM_CAP_ASSIGN_DEV_IRQ)) {return kvm_vm_ioctl(s, KVM_ASSIGN_DEV_IRQ, &assigned_irq);    } else {return kvm_vm_ioctl(s, KVM_ASSIGN_IRQ, &assigned_irq);    }}

内核中的KVM ASSIGN实现

• KVM模块的初始化与退出（arch/x86/kvm/svm.c）：

staticint __init svm_init(void){return kvm_init(&svm_x86_ops, sizeof(struct vcpu_svm),   __alignof__(struct vcpu_svm), THIS_MODULE);}staticvoid __exit svm_exit(void){ kvm_exit();}module_init(svm_init)module_exit(svm_exit)

• KVM字符设备文件的注册与实现（virt/kvm/kvm_main.c）：

staticlongkvm_dev_ioctl(struct file *filp,unsignedint ioctl, unsignedlong arg){long r = -EINVAL;switch (ioctl) {case KVM_GET_API_VERSION:if (arg)goto out;  r = KVM_API_VERSION;break;case KVM_CREATE_VM:  r = kvm_dev_ioctl_create_vm(arg);break;case KVM_CHECK_EXTENSION:  r = kvm_vm_ioctl_check_extension_generic(NULL, arg);break;case KVM_GET_VCPU_MMAP_SIZE:if (arg)goto out;  r = PAGE_SIZE;     /* struct kvm_run */#ifdef CONFIG_X86  r += PAGE_SIZE;    /* pio data page */#endif#ifdef CONFIG_KVM_MMIO  r += PAGE_SIZE;    /* coalesced mmio ring page */#endifbreak;case KVM_TRACE_ENABLE:case KVM_TRACE_PAUSE:case KVM_TRACE_DISABLE:  r = -EOPNOTSUPP;break;default:return kvm_arch_dev_ioctl(filp, ioctl, arg); }out:return r;}staticstructfile_operationskvm_chardev_ops = { .unlocked_ioctl = kvm_dev_ioctl, .compat_ioctl   = kvm_dev_ioctl, .llseek  = noop_llseek,};staticstructmiscdevicekvm_dev = { KVM_MINOR,"kvm", &kvm_chardev_ops,};intkvm_init(void *opaque, unsigned vcpu_size, unsigned vcpu_align,    struct module *module){int r;int cpu;... r = misc_register(&kvm_dev);if (r) {  pr_err("kvm: misc device register failed\n");goto out_unreg; }...}EXPORT_SYMBOL_GPL(kvm_init);KVM_ASSIGN_PCI_DEVICE

• KVM字符设备ioctl中调用进行设备分配的地方（arch/x86/kvm/x86.c）：

longkvm_arch_vm_ioctl(struct file *filp,unsignedint ioctl, unsignedlong arg){...switch (ioctl) {...default:  r = kvm_vm_ioctl_assigned_device(kvm, ioctl, arg); }out:return r;}

• 获取Qemu或其他用户态程序传来的设备地址信息（arch/x86/kvm/assigned-dev.c）：

longkvm_vm_ioctl_assigned_device(struct kvm *kvm, unsigned ioctl,unsignedlong arg){void __user *argp = (void __user *)arg;int r;switch (ioctl) {case KVM_ASSIGN_PCI_DEVICE: {structkvm_assigned_pci_devassigned_dev;  r = -EFAULT;if (copy_from_user(&assigned_dev, argp, sizeof assigned_dev))goto out;  r = kvm_vm_ioctl_assign_device(kvm, &assigned_dev);if (r)goto out;break; }...default:  r = -ENOTTY;break; }out:return r;}

• 根据设备地址找到设备的Device设备结构，为其分配内核态的数据结构，并注册对应的KVM设备Slot，最后调用kvm_assign_device函数：

staticintkvm_vm_ioctl_assign_device(struct kvm *kvm,          struct kvm_assigned_pci_dev *assigned_dev){int r = 0, idx;structkvm_assigned_dev_kernel *match;structpci_dev *dev;if (!(assigned_dev->flags & KVM_DEV_ASSIGN_ENABLE_IOMMU))return -EINVAL; mutex_lock(&kvm->lock); idx = srcu_read_lock(&kvm->srcu); match = kvm_find_assigned_dev(&kvm->arch.assigned_dev_head,          assigned_dev->assigned_dev_id);if (match) {/* device already assigned */  r = -EEXIST;goto out; } match = kzalloc(sizeof(struct kvm_assigned_dev_kernel), GFP_KERNEL);if (match == NULL) {  printk(KERN_INFO "%s: Couldn't allocate memory\n",         __func__);  r = -ENOMEM;goto out; } dev = pci_get_domain_bus_and_slot(assigned_dev->segnr,       assigned_dev->busnr,       assigned_dev->devfn);if (!dev) {  printk(KERN_INFO "%s: host device not found\n", __func__);  r = -EINVAL;goto out_free; }/* Don't allow bridges to be assigned */if (dev->hdr_type != PCI_HEADER_TYPE_NORMAL) {  r = -EPERM;goto out_put; } r = probe_sysfs_permissions(dev);if (r)goto out_put;if (pci_enable_device(dev)) {  printk(KERN_INFO "%s: Could not enable PCI device\n", __func__);  r = -EBUSY;goto out_put; } r = pci_request_regions(dev, "kvm_assigned_device");if (r) {  printk(KERN_INFO "%s: Could not get access to device regions\n",         __func__);goto out_disable; } pci_reset_function(dev); pci_save_state(dev); match->pci_saved_state = pci_store_saved_state(dev);if (!match->pci_saved_state)  printk(KERN_DEBUG "%s: Couldn't store %s saved state\n",         __func__, dev_name(&dev->dev));if (!pci_intx_mask_supported(dev))  assigned_dev->flags &= ~KVM_DEV_ASSIGN_PCI_2_3; match->assigned_dev_id = assigned_dev->assigned_dev_id; match->host_segnr = assigned_dev->segnr; match->host_busnr = assigned_dev->busnr; match->host_devfn = assigned_dev->devfn; match->flags = assigned_dev->flags; match->dev = dev; spin_lock_init(&match->intx_lock); spin_lock_init(&match->intx_mask_lock); match->irq_source_id = -1; match->kvm = kvm; match->ack_notifier.irq_acked = kvm_assigned_dev_ack_irq; list_add(&match->list, &kvm->arch.assigned_dev_head);if (!kvm->arch.iommu_domain) {  r = kvm_iommu_map_guest(kvm);if (r)goto out_list_del; } r = kvm_assign_device(kvm, match->dev);if (r)goto out_list_del;out: srcu_read_unlock(&kvm->srcu, idx); mutex_unlock(&kvm->lock);return r;out_list_del:if (pci_load_and_free_saved_state(dev, &match->pci_saved_state))  printk(KERN_INFO "%s: Couldn't reload %s saved state\n",         __func__, dev_name(&dev->dev)); list_del(&match->list); pci_release_regions(dev);out_disable: pci_disable_device(dev);out_put: pci_dev_put(dev);out_free: kfree(match); srcu_read_unlock(&kvm->srcu, idx); mutex_unlock(&kvm->lock);return r;}

• kvm_assign_device其实只是配置设备的IOMMU（arch/x86/kvm/iommu.c）：

intkvm_assign_device(struct kvm *kvm, struct pci_dev *pdev){structiommu_domain *domain = kvm->arch.iommu_domain;int r;bool noncoherent;/* check if iommu exists and in use */if (!domain)return0;if (pdev == NULL)return -ENODEV; r = iommu_attach_device(domain, &pdev->dev);if (r) {  dev_err(&pdev->dev, "kvm assign device failed ret %d", r);return r; } noncoherent = !iommu_capable(&pci_bus_type, IOMMU_CAP_CACHE_COHERENCY);/* Check if need to update IOMMU page table for guest memory */if (noncoherent != kvm->arch.iommu_noncoherent) {  kvm_iommu_unmap_memslots(kvm);  kvm->arch.iommu_noncoherent = noncoherent;  r = kvm_iommu_map_memslots(kvm);if (r)goto out_unmap; } kvm_arch_start_assignment(kvm); pci_set_dev_assigned(pdev); dev_info(&pdev->dev, "kvm assign device\n");return0;out_unmap: kvm_iommu_unmap_memslots(kvm);return r;}

• kvm_arch_start_assignment函数只是增加设备的分配计数而已（arch/x86/kvm/x86.c）：

voidkvm_arch_start_assignment(struct kvm *kvm){ atomic_inc(&kvm->arch.assigned_device_count);}

• pci_set_dev_assigned函数设置设备已被分配的标志（include/linux/pci.h）：

/* Helper functions for operation of device flag */staticinlinevoidpci_set_dev_assigned(struct pci_dev *pdev){ pdev->dev_flags |= PCI_DEV_FLAGS_ASSIGNED;}

分析总结

1. Linux内核中的pci-stub驱动生成的Driver结构只是与PCIBus产生的Device结构进行绑定，没有提供任何用户调用接口，主要作用是防止其他驱动占用这个Device；
2. 用户态的Qemu访问这个PCI设备主要通过这个PCIBUS驱动为这个PCIDevice提供的SysFS属性文件进行，通过config文件读取和配置PCI配置空间，通过resource文件获取PCIBAR的数量级地址和长度，通过resource%d文件进内存映射和中断读写；
3. Qemu调用KVM的ioctl主要是进行这个设备的IOMMU配置和KVM数据结构初始化，以及中断的注入。这应该是为了弥补pci-stub驱动和SysFS的不足，感觉这是一种修修补补的写法，原本的框架不支持相关功能，而VFIO和irqfd在设计之初就是为了解决这个问题，且更加优雅和强大（VFIO还可以提供MDev功能），这应该是其备受推崇的根本原因；
4. 无论是PCI-Assign还是VFIO，或者MDev，其实他们真正透传的只有内存区域，对于配置区域和中断的处理，其实都是需要宿主机的软件参与，他们能降低的主要是大量数据的传输，对于中断和配置的性能并没有本质改善。由于设备配置部分原本在设备的访问中占比不高，所以不是性能瓶颈。但对于中断，在高性能场景，应尽可能减少中断的使用，使用查的方式处理状态变化，可以获取更好的性能。
