openclaw根据Excel表格ArcGIS 创建数据库GDB
"""根据 Excel 属性结构表创建 ArcGIS 要素类功能：读取 Excel 中的字段定义，创建带别名和坐标系的空要素类"""import arcpyimport pandas as pdimport os# ==================== 配置区域 ====================# 输出路径desktop_gis = r"C:\Users\yl\Desktop\GIS"gdb_name = "d.gdb"gdb_path = os.path.join(desktop_gis, gdb_name)# Excel 文件路径excel_dir = r"E:\2026\Pro\data\data"# 坐标系 WKIDspatial_ref_wkid = 4546 # CGCS2000_3_Degree_GK_CM_111E# ================================================def find_excel_file(base_path):"""查找 chp5 目录下的 Excel 文件（排除临时文件）"""for item in os.listdir(base_path):if "chp5" in item: chp5_path = os.path.join(base_path, item)for file in os.listdir(chp5_path):if file.endswith(".xlsx") and not file.startswith("~$"):return os.path.join(chp5_path, file)return Nonedef parse_excel(excel_path):"""解析 Excel 文件，提取要素类配置信息"""xl = pd.ExcelFile(excel_path) sheet_names = xl.sheet_names fc_configs = []for sheet in sheet_names:# 读取前 3 行获取要素信息df_header = pd.read_excel(excel_path, sheet_name=sheet, nrows=3, header=None)# 行 0: 要素名称代码fc_code = str(df_header.iloc[0, 1]).strip() if pd.notna(df_header.iloc[0, 1]) else sheet# 行 1: 别名fc_alias = str(df_header.iloc[1, 1]).strip() if pd.notna(df_header.iloc[1, 1]) else ""# 行 2: 要素类型fc_type_raw = str(df_header.iloc[2, 1]).strip() if pd.notna(df_header.iloc[2, 1]) else "面"# 转换要素类型if fc_type_raw == "点" or "点" in fc_type_raw: geom_type = "POINT"elif fc_type_raw == "线" or "线" in fc_type_raw: geom_type = "POLYLINE"elif fc_type_raw == "面" or "面" in fc_type_raw or "多边形" in fc_type_raw: geom_type = "POLYGON"else: geom_type = "POLYGON" # 默认面# 读取字段定义（从第 4 行开始，跳过表头行 3）df_fields = pd.read_excel(excel_path, sheet_name=sheet, skiprows=4, header=None) fields = []for idx, row in df_fields.iterrows():if pd.notna(row.iloc[0]) and pd.notna(row.iloc[1]) and pd.notna(row.iloc[2]): field_order = row.iloc[0] field_alias = str(row.iloc[1]).strip() if pd.notna(row.iloc[1]) else ""field_name = str(row.iloc[2]).strip() if pd.notna(row.iloc[2]) else ""field_type_raw = str(row.iloc[3]).strip() if pd.notna(row.iloc[3]) else "Char"field_length = int(row.iloc[4]) if pd.notna(row.iloc[4]) else None# 跳过表头行if field_name in ["字段名称", "字段代码", "NaN", "nan", ""]:continue# 转换字段类型if field_type_raw in ["Char", "String", "Text"]: field_type = "TEXT"elif field_type_raw in ["Int", "Integer", "Long"]: field_type = "LONG"elif field_type_raw in ["Float", "Single"]: field_type = "FLOAT"elif field_type_raw in ["Double"]: field_type = "DOUBLE"elif field_type_raw in ["Date"]: field_type = "DATE"else: field_type = "TEXT"fields.append({"name": field_name,"type": field_type,"length": field_length,"alias": field_alias }) fc_configs.append({"sheet_name": sheet,"fc_code": fc_code,"fc_alias": fc_alias,"geom_type": geom_type,"fields": fields })return fc_configsdef create_gdb(gdb_path):"""创建文件地理数据库"""if arcpy.Exists(gdb_path): arcpy.Delete_management(gdb_path) print(f"已删除现有的地理数据库：{gdb_path}") arcpy.CreateFileGDB_management(os.path.dirname(gdb_path), os.path.basename(gdb_path)) print(f"已创建地理数据库：{gdb_path}")def create_featureclasses(gdb_path, fc_configs, spatial_ref):"""创建要素类并添加字段"""for fc_config in fc_configs: fc_name = fc_config["fc_code"] fc_alias = fc_config["fc_alias"] geom_type = fc_config["geom_type"] print(f"\n创建要素类：{fc_name} (别名：{fc_alias}) ({geom_type})")# 创建要素类fc_path = arcpy.CreateFeatureclass_management( out_path=gdb_path, out_name=fc_name, geometry_type=geom_type, spatial_reference=spatial_ref ).getOutput(0) print(f" 路径：{fc_path}")# 设置要素类别名if fc_alias: arcpy.AlterAliasName(fc_path, fc_alias) print(f" 已设置别名：{fc_alias}")# 添加字段for field in fc_config["fields"]:try:if field["type"] == "TEXT" and field["length"]: arcpy.AddField_management(fc_path, field["name"], field["type"], field_length=field["length"], field_alias=field["alias"])elif field["type"] in ["FLOAT", "DOUBLE", "LONG", "DATE"]: arcpy.AddField_management(fc_path, field["name"], field["type"], field_alias=field["alias"])else: arcpy.AddField_management(fc_path, field["name"], field["type"], field_alias=field["alias"]) print(f" 添加字段：{field['name']} ({field['type']}) - {field['alias']}")except Exception as e: print(f" 添加字段 {field['name']} 失败：{e}")def verify_gdb(gdb_path):"""验证地理数据库内容"""print("\n\n=== 地理数据库内容 ===") arcpy.env.workspace = gdb_path fcs = arcpy.ListFeatureClasses()if fcs:for fc in fcs: fc_path = os.path.join(gdb_path, fc) desc = arcpy.Describe(fc_path) print(f"\n{fc}") print(f" 别名：{desc.aliasName}") print(f" 几何类型：{desc.shapeType}") print(f" 坐标系：{desc.spatialReference.name} (WKID: {desc.spatialReference.factoryCode})") fields = arcpy.ListFields(fc_path)for field in fields:if field.name not in ["OID", "Shape", "Shape_Length", "Shape_Area"]: print(f" - {field.name}: {field.type} (别名：{field.aliasName})")else: print("未找到要素类")def main():"""主函数"""print("=" * 60) print("ArcGIS 要素类创建工具") print("=" * 60)# 查找 Excel 文件excel_path = find_excel_file(excel_dir)if not excel_path: print("错误：未找到 Excel 文件")returnprint(f"\nExcel 文件：{excel_path}")# 创建空间参考spatial_ref = arcpy.SpatialReference(spatial_ref_wkid) print(f"使用坐标系：{spatial_ref.name} (WKID: {spatial_ref_wkid})")# 解析 Excelfc_configs = parse_excel(excel_path) print(f"\n解析到 {len(fc_configs)} 个要素类配置")# 创建地理数据库create_gdb(gdb_path)# 创建要素类create_featureclasses(gdb_path, fc_configs, spatial_ref)# 验证结果verify_gdb(gdb_path) print(f"\n\n完成！地理数据库位于：{gdb_path}")if __name__ == "__main__":# 需要 ArcGIS Pro Python 环境运行main()
