通达信缠论主图插件

VAR1:=TDXDLL3(100,PERIOD,HIGH,LOW); {初始周期}VAR2:=TDXDLL3(1,HIGH,LOW,CLOSE); {VAR2和VAR4相同，1和2都是顶分型，-1和-2是底分型，1为笔高点，-1为笔低点}VAR3:=TDXDLL3(14,HIGH,LOW,CLOSE);VAR4:=TDXDLL3(4,HIGH,LOW,CLOSE); {VAR2和VAR4相同，1和2都是顶分型，-1和-2是底分型，1为笔高点，-1为笔低点}VAR5:=TDXDLL3(2,HIGH,LOW,CLOSE); {等同于HIGH}VAR6:=TDXDLL3(3,HIGH,LOW,CLOSE); {等同于LOW}VAR7:=TDXDLL3(6,HIGH,LOW,CLOSE); {笔的长度，笔的高低点第2根K线开始计数为1}{ VAR4 判断峰，VAR5 为峰值}DRAWLINE(VAR4=1,VAR5,VAR4=(-1),VAR6,0),DOTLINE,COLORGREEN,LINETHICK2;DRAWLINE(VAR4=(-1),VAR6,VAR4=1,VAR5,0),DOTLINE,COLORMAGENTA,LINETHICK2;VAR8:=TDXDLL3(5,HIGH,LOW,CLOSE); {无数据}VAR9:=TDXDLL3(7,HIGH,LOW,CLOSE); {笔起点，即笔高低点第2根K线置1，其它为0}VAR10:=TDXDLL3(8,HIGH,LOW,CLOSE); {无数据}VAR11:=TDXDLL3(9,HIGH,LOW,CLOSE); {中枢高点}VAR12:=TDXDLL3(10,HIGH,LOW,CLOSE); {中枢低点}VAR13:=TDXDLL3(11,HIGH,LOW,CLOSE); {中枢起点，蓝色赋值1，红色赋值2}VAR14:=TDXDLL3(12,HIGH,LOW,CLOSE); {中枢结束，蓝色赋值1，红色赋值2}VAR15:=-REF(VAR4,VAR7);{画中枢,VAR11中枢上线，VAR12中枢下线}DRAWLINE(VAR13=1,VAR11,VAR14=1,VAR11,0),COLORBLUE;DRAWLINE(VAR13=1,VAR12,VAR14=1,VAR12,0),COLORBLUE;DRAWLINE(VAR13=1,(VAR11+VAR12)/2,VAR14=1,(VAR11+VAR12)/2,0),DOTLINE,COLORYELLOW;STICKLINE(VAR13=1,VAR11,VAR12,VAR13=1,0),COLORBLUE;STICKLINE(VAR14=1,VAR11,VAR12,VAR14=1,0),COLORBLUE;DRAWLINE(VAR13=2,VAR11,VAR14=2,VAR11,0),COLORRED;DRAWLINE(VAR13=2,VAR12,VAR14=2,VAR12,0),COLORRED;DRAWLINE(VAR13=2,(VAR11+VAR12)/2,VAR14=2,(VAR11+VAR12)/2,0),DOTLINE,COLORRED;STICKLINE(VAR13=2,VAR11,VAR12,VAR13=2,0),COLORRED;STICKLINE(VAR14=2,VAR11,VAR12,VAR14=2,0),COLORRED;
