x64dbg插件无驱动过vmp3.9.4反调试

 复制代码 隐藏代码#include"pch.h"#include<windows.h>#include<vector>#include<string>#include"pluginsdk/bridgemain.h"#include"pluginsdk/_plugins.h"#include"pluginsdk/_scriptapi_module.h"#include"pluginsdk/_scriptapi_memory.h"#include"pluginsdk/_scriptapi_debug.h"#include"unicorn/unicorn.h"#pragma comment(lib, "unicorn.lib")#pragma comment(lib, "x64dbg.lib")      // x64dbg 的库（64位）#pragma comment(lib, "x64bridge.lib")   // x64bridge 的库（64位）#define MENU_UNICORN_ID 1int pluginHandle;duint mainModuleBase = 0;duint mainModuleSize = 0;int hMenu;// ---------------------- 全局控制变量 ----------------------HANDLE g_hSimulateEvent = NULL;        // 唤醒工作线程的事件HANDLE g_hSimulateThread = NULL;       // 工作线程句柄BOOL   g_bStopSimulation = FALSE;      // 是否停止工作线程BOOL   g_bWaitingForBreakpoint = FALSE;// 是否在等待 rdtsc 断点duint  g_rdtscNextRip = 0;             // rdtsc 下一条指令地址int    g_stop_reason = 0;              // 模拟停止原因：1=rdtsc, 2=syscall, 3=out_of_moduleBOOL   gsreg = FALSE;BOOL   api = FALSE;// ---------------------- Unicorn 钩子函数 ----------------------staticvoidhook_code(uc_engine* uc, uint64_t address, uint32_t size, void* user_data){    WORD code = 0;uc_mem_read(uc, address, &code, 2);if (code == 0x310f) {  // rdtsc        _plugin_logprintf(u8"rdtsc at address: %llx\n", address);        g_stop_reason = 1;        g_rdtscNextRip = address + size;  // 下一条指令地址uc_emu_stop(uc);return;    }if (code == 0x50f) {   // syscall        _plugin_logprintf(u8"syscall at address: %llx\n", address);        g_stop_reason = 2;uc_emu_stop(uc);return;    }// 如果指令地址超出主模块范围，停止模拟if (address < mainModuleBase || address >= (mainModuleBase + mainModuleSize)) {        _plugin_logprintf(u8"[Unicorn] 停止模拟，交回控制权给 x64dbg。api address:%llx\n", address);        g_stop_reason = 3;uc_emu_stop(uc);    }}staticboolhook_mem_unmapped(uc_engine* uc, uc_mem_type type, uint64_t address, int size, int64_t value, void* user_data){uint64_t current_rip;uc_reg_read(uc, UC_X86_REG_RIP, ¤t_rip);    _plugin_logprintf(u8"[Unicorn] MEM_UNMAPPED at RIP=0x%llX: type=%d, addr=0x%llX, size=%d\n",        current_rip, type, address, size);    duint pageBase = (duint)address & ~0xFFF;if (!Script::Memory::IsValidPtr(pageBase)) {        _plugin_logprintf(u8"[Unicorn] 致命错误：尝试访问无效指针 0x%llX \n", pageBase);uc_emu_stop(uc);returnfalse;    }    _plugin_logprintf(u8"[Unicorn] 触发缺页中断，懒加载映射内存页: 0x%llX\n", pageBase);    uc_err err = uc_mem_map(uc, pageBase, 0x1000, UC_PROT_ALL);if (err != UC_ERR_OK && err != UC_ERR_MAP) {        _plugin_logprintf(u8"[Unicorn] 内存映射失败: %s\n", uc_strerror(err));returnfalse;    }unsignedchar pageBuf[0x1000] = { 0 };if (Script::Memory::Read(pageBase, pageBuf, 0x1000, nullptr)) {uc_mem_write(uc, pageBase, pageBuf, 0x1000);returntrue;    }returnfalse;}// ---------------------- 工作线程：执行模拟 ----------------------DWORD WINAPI SimulationWorker(LPVOID lpParam){while (!g_bStopSimulation) {// 等待事件触发WaitForSingleObject(g_hSimulateEvent, INFINITE);ResetEvent(g_hSimulateEvent);// 如果是因为断点唤醒，需要删除之前设置的硬件断点if (g_bWaitingForBreakpoint) {            Script::Debug::DeleteHardwareBreakpoint(g_rdtscNextRip);            g_bWaitingForBreakpoint = FALSE;        }// 重新初始化 Unicorn 引擎        uc_engine* uc;        uc_err err = uc_open(UC_ARCH_X86, UC_MODE_64, &uc);if (err != UC_ERR_OK) {            _plugin_logprintf(u8"uc_open 失败: %u\n", err);continue;        }// 1. 获取主模块范围（每次重新获取，因为调试器可能已加载新模块）        mainModuleBase = Script::Module::GetMainModuleBase();        mainModuleSize = Script::Module::SizeFromAddr(mainModuleBase);// 2. 映射所有已提交的内存页到 Unicorn        MEMMAP memoryMap = { 0 };DbgMemMap(&memoryMap);for (int i = 0; i < memoryMap.count; i++) {auto& page = memoryMap.page[i];if (page.mbi.State == MEM_COMMIT) {                duint base = (duint)page.mbi.BaseAddress;                SIZE_T size = page.mbi.RegionSize;                duint alignedBase = base & ~0xFFF;                duint alignedSize = (size + 0xFFF) & ~0xFFF;uc_mem_map(uc, alignedBase, alignedSize, UC_PROT_ALL);std::vector<uint8_t> buffer(size);if (Script::Memory::Read(base, buffer.data(), size, nullptr)) {uc_mem_write(uc, base, buffer.data(), size);                }            }        }// 3. 同步寄存器状态（64位）        REGDUMP_AVX512 regdump = { 0 };if (!DbgGetRegDumpEx(®dump, sizeof(regdump))) {            _plugin_logprintf(u8"[Unicorn] 无法获取寄存器，模拟跳过\n");uc_close(uc);continue;        }uint64_t rax = regdump.regcontext.cax;uint64_t rbx = regdump.regcontext.cbx;uint64_t rcx = regdump.regcontext.ccx;uint64_t rdx = regdump.regcontext.cdx;uint64_t rsi = regdump.regcontext.csi;uint64_t rdi = regdump.regcontext.cdi;uint64_t rsp = regdump.regcontext.csp;uint64_t rbp = regdump.regcontext.cbp;uint64_t rip = regdump.regcontext.cip;uint64_t rflags = regdump.regcontext.eflags;        rflags &= ~0x100;  // 清除 TF 位uint64_t r8 = regdump.regcontext.r8;uint64_t r9 = regdump.regcontext.r9;uint64_t r10 = regdump.regcontext.r10;uint64_t r11 = regdump.regcontext.r11;uint64_t r12 = regdump.regcontext.r12;uint64_t r13 = regdump.regcontext.r13;uint64_t r14 = regdump.regcontext.r14;uint64_t r15 = regdump.regcontext.r15;uc_reg_write(uc, UC_X86_REG_RAX, &rax);uc_reg_write(uc, UC_X86_REG_RBX, &rbx);uc_reg_write(uc, UC_X86_REG_RCX, &rcx);uc_reg_write(uc, UC_X86_REG_RDX, &rdx);uc_reg_write(uc, UC_X86_REG_RSI, &rsi);uc_reg_write(uc, UC_X86_REG_RDI, &rdi);uc_reg_write(uc, UC_X86_REG_RSP, &rsp);uc_reg_write(uc, UC_X86_REG_RBP, &rbp);uc_reg_write(uc, UC_X86_REG_RIP, &rip);uc_reg_write(uc, UC_X86_REG_RFLAGS, &rflags);uc_reg_write(uc, UC_X86_REG_R8, &r8);uc_reg_write(uc, UC_X86_REG_R9, &r9);uc_reg_write(uc, UC_X86_REG_R10, &r10);uc_reg_write(uc, UC_X86_REG_R11, &r11);uc_reg_write(uc, UC_X86_REG_R12, &r12);uc_reg_write(uc, UC_X86_REG_R13, &r13);uc_reg_write(uc, UC_X86_REG_R14, &r14);uc_reg_write(uc, UC_X86_REG_R15, &r15);// 4. 设置钩子        uc_hook trace_code, trace_mem;uc_hook_add(uc, &trace_code, UC_HOOK_CODE, hook_code, NULL, 1, 0);uc_hook_add(uc, &trace_mem, UC_HOOK_MEM_UNMAPPED, hook_mem_unmapped, NULL, 1, 0);// 5. 开始模拟        _plugin_logprintf(u8"[Unicorn] 开始模拟，起始 RIP: 0x%llX\n", rip);        g_stop_reason = 0;   // 清除停止原因        err = uc_emu_start(uc, rip, UINT64_MAX, 0, 0);if (err != UC_ERR_OK) {            _plugin_logprintf(u8"[Unicorn] 模拟停止，原因: %s\n", uc_strerror(err));        }else {            _plugin_logprintf(u8"[Unicorn] 模拟正常完成。\n");        }// 获取停止时的 RIPuint64_t stop_rip = 0;uc_reg_read(uc, UC_X86_REG_RIP, &stop_rip);        _plugin_logprintf(u8"[Unicorn] 停止时 RIP: 0x%llX, 停止原因: %d\n", stop_rip, g_stop_reason);// 根据停止原因决定后续动作if (g_stop_reason == 1) {   // rdtsc// 在 rdtsc 下一条指令设置硬件断点            g_rdtscNextRip = stop_rip+2;  // 实际上 stop_rip 就是 rdtsc 地址，但 hook_code 中已存储 g_rdtscNextRip            Script::Debug::SetHardwareBreakpoint(g_rdtscNextRip);            g_bWaitingForBreakpoint = TRUE;// 让调试器继续执行到断点DbgCmdExec("go");        }elseif (g_stop_reason == 2) {   // syscall            _plugin_logprintf(u8"[Unicorn] 遇到 syscall，模拟结束。\n");            Script::Debug::SetHardwareBreakpoint(stop_rip);DbgCmdExec("go");// 不再继续模拟，线程回到等待状态（等待用户再次触发）        }elseif (g_stop_reason == 3) {   // 超出模块范围            _plugin_logprintf(u8"[Unicorn] 超出主模块，模拟结束。\n");            api = TRUE;            Script::Debug::SetHardwareBreakpoint(stop_rip);DbgCmdExec("go");// 不再继续模拟，线程回到等待状态        }else {// 其他未知停止原因（可能 uc_emu_start 错误），也不继续            gsreg = TRUE;            BASIC_INSTRUCTION_INFO info;DbgDisasmFastAt(stop_rip, &info);            Script::Debug::SetHardwareBreakpoint(stop_rip+info.size);DbgCmdExec("go");            _plugin_logprintf(u8"[Unicorn] 模拟因未知原因停止。\n");        }uc_close(uc);    }return0;}// ---------------------- 断点回调 ----------------------BOOL g_bDebugMenuActive = FALSE;  // 标记是否处于调试模式（菜单 DEBUG_ID 按下后）extern"C" __declspec(dllexport) voidCBBREAKPOINT(CBTYPE cbType, PLUG_CB_BREAKPOINT * info){// 处理调试模式下的硬件断点（仅当 g_bDebugMenuActive 为真）if (g_bDebugMenuActive && info->breakpoint->type == bp_hardware) {// 如果是之前为 rdtsc 设置的下一条指令断点if (info->breakpoint->addr == g_rdtscNextRip) {            _plugin_logprintf(u8"[Unicorn] rdtsc 下一条指令断点命中: 0x%llX\n", info->breakpoint->addr);// 唤醒工作线程继续模拟            Script::Debug::DeleteHardwareBreakpoint(g_rdtscNextRip);SetEvent(g_hSimulateEvent);// 注意：断点命中后调试器处于暂停状态，工作线程会重新获取寄存器并模拟// 此时不要执行 go，否则工作线程还没准备好就继续运行了return;        }        WORD op = 0;if (DbgMemRead(info->breakpoint->addr, &op, 2)) {if (op == 0x50f) {                _plugin_logprintf(u8"syscall:%llx\n", info->breakpoint->addr);                Script::Debug::DeleteHardwareBreakpoint(info->breakpoint->addr);return;            }/*else {                DbgCmdExec("StepInto");            }*/        }    }if (gsreg && info->breakpoint->type == bp_hardware) {        gsreg = FALSE;        Script::Debug::DeleteHardwareBreakpoint(info->breakpoint->addr);SetEvent(g_hSimulateEvent);return;    }if (api && info->breakpoint->type == bp_hardware) {        api = FALSE;        Script::Debug::DeleteHardwareBreakpoint(info->breakpoint->addr);return;    }}// ---------------------- 菜单回调 ----------------------extern"C" __declspec(dllexport) voidCBMENUENTRY(CBTYPE cbType, PLUG_CB_MENUENTRY * info){if (info->hEntry == MENU_UNICORN_ID) {// 启动模拟（唤醒工作线程）        g_bDebugMenuActive = TRUE;          // 确保不在调试模式下        g_bWaitingForBreakpoint = FALSE;     // 清除等待断点标志SetEvent(g_hSimulateEvent);return;    }}// ---------------------- 插件入口函数 ----------------------extern"C" __declspec(dllexport) boolpluginit(PLUG_INITSTRUCT * initStruct){    initStruct->pluginVersion = 1;    initStruct->sdkVersion = PLUG_SDKVERSION;strcpy_s(initStruct->pluginName, "UnicornPlugin");    pluginHandle = initStruct->pluginHandle;returntrue;}extern"C" __declspec(dllexport) voidplugsetup(PLUG_SETUPSTRUCT * setupStruct){    hMenu = setupStruct->hMenu;    _plugin_menuaddentry(hMenu, MENU_UNICORN_ID, "sys_trace");// 创建事件和常驻工作线程    g_hSimulateEvent = CreateEvent(NULL, FALSE, FALSE, NULL);    g_hSimulateThread = CreateThread(NULL, 0, SimulationWorker, NULL, 0, NULL);    _plugin_logputs("[UnicornPlugin] plugsetup called, worker thread started.");}extern"C" __declspec(dllexport) boolplugstop(){// 停止工作线程if (g_hSimulateEvent) {        g_bStopSimulation = TRUE;SetEvent(g_hSimulateEvent);if (g_hSimulateThread) {WaitForSingleObject(g_hSimulateThread, INFINITE);CloseHandle(g_hSimulateThread);            g_hSimulateThread = NULL;        }CloseHandle(g_hSimulateEvent);        g_hSimulateEvent = NULL;    }    _plugin_logputs("[UnicornPlugin] plugstop called, worker thread stopped.");returntrue;}// ---------------------- DllMain ----------------------BOOL APIENTRY DllMain(HMODULE hModule, DWORD ul_reason_for_call, LPVOID lpReserved){switch (ul_reason_for_call) {case DLL_PROCESS_ATTACH:case DLL_THREAD_ATTACH:case DLL_THREAD_DETACH:case DLL_PROCESS_DETACH:break;    }return TRUE;}

通过网盘分享的文件：plugin.zip链接: https://pan.baidu.com/s/1KIxIQjQCCzhqMfhRXNfklQ?pwd=b228 提取码: b228–来自百度网盘超级会员v8的分享
