1：概念
Cliosoft SOS 7.05.p3 是专为 EDA（电子设计自动化）行业设计的硬件配置管理（HCM）与版本控制系统，核心用于多工程师协作下的 IC 设计数据隔离、版本控制、变更追踪及与 Cadence Virtuoso 等工具的深度集成 。
工作区隔离机制：为每位设计工程师创建独立的本地工作区（Workarea），防止对共享“黄金库”进行意外直接修改，确保主库数据完整性 。
版本控制与回溯：支持 Check-out/Check-in 流程，自动记录文件/视图的历史版本，允许随时回滚至任意历史状态，并保留完整的变更日志 。
可视化差异对比：内置 Visual Design Diff 工具，可图形化高亮显示电路原理图、版图等设计对象在不同版本间的具体差异 。
权限与发布管理：提供基于角色的访问控制（RBAC），限制特定用户对关键库的写权限；支持创建项目快照（Snapshot）以标记里程碑或发布版本 。
EDA工具无缝集成：通过插件形式深度嵌入 Cadence Virtuoso Library Manager 等界面，设计师无需离开设计环境即可完成版本操作，避免命令行误用导致冲突 。
管理员端（SE）：使用 sosadmin 图形界面创建项目服务器、定义工艺库结构、分配用户权限及管理全局版本策略 。
设计端（DE）：通过 sos 客户端或 Virtuoso 菜单创建个人工作区，执行“下载（Populate）”获取最新库文件，修改后执行“提交（Check-in）”同步变更 。
冲突处理：系统自动检测并发修改冲突，强制要求解决差异后方可提交，确保多人协作时数据一致性 。
2：环境
操作系统：AlmaLinux release 8.10 (Cerulean Leopard)
安装包：sos_7.05.p3_linux64
安装用户：eda
3：安装过程
[eda@bogon ~/soft]$ cd /home/eda/soft/sos_7.05.p3_linux64/[eda@bogon sos_7.05.p3_linux64]$ ll -alh总用量 407Mdrwxr-xr-x 2 eda yanfa 91 6月 26 10:35 .drwxr-xr-x. 10 eda yanfa 150 6月 26 11:50 ..-rwxr-xr-x 1 eda yanfa 19K 2月 7 2022 cliosoft.install-rwxr-xr-x 1 eda yanfa 407M 2月 7 2022 cliosoft.tar-rwxr-xr-x 1 eda yanfa 114K 2月 13 2020 gzip-rwxr-xr-x 1 eda yanfa 3.2K 2月 13 2020 README-rwxr-xr-x 1 eda yanfa 61 2月 13 2020 RELEASE[eda@bogon ~]$ mkdir /home/eda/tool/sos_7.05.p3##[eda@bogon sos_7.05.p3_linux64]$ pwd/home/eda/soft/sos_7.05.p3_linux64[eda@bogon sos_7.05.p3_linux64]$ ./cliosoft.installcat: /home/eda/soft/sos_7.05.p3_linux64/PLATFORM: 没有那个文件或目录# 创建 PLATFORM 文件[eda@bogon sos_7.05.p3_linux64]$ echo "linux64" > /home/eda/soft/sos_7.05.p3_linux64/PLATFORM[eda@bogon sos_7.05.p3_linux64]$ ./cliosoft.installOnly RHEL releases >= 6.x supported. Current RHEL is:AlmaLinux release 8.10 (Cerulean Leopard)[eda@bogon sos_7.05.p3_linux64]$## 安装脚本不识别 AlmaLinux，认为不是 RHEL 系统。## 临时伪装系统版本[root@bogon ~]# cat /etc/redhat-releaseAlmaLinux release 8.10 (Cerulean Leopard)[root@bogon ~]# cp /etc/redhat-release /etc/redhat-release.bak[root@bogon ~]# echo "Red Hat Enterprise Linux release 8.10 (Ootpa)" > /etc/redhat-release[root@bogon ~]# cat /etc/redhat-releaseRed Hat Enterprise Linux release 8.10 (Ootpa)# 安装完后改回来cp /etc/redhat-release.bak /etc/redhat-release##[eda@bogon sos_7.05.p3_linux64]$ ./cliosoft.install----------------------------------------------------------------------** Starting ClioSoft-SOS installation...Release: 7.05.p3Platform: linux64** Installation owner : edaIt is good practice (though not required) to install SOSusing a pseudo account created for tool administration,such as 'toolman', that is NOT 'root' or a real user account.** Current directory : /home/eda/soft/sos_7.05.p3_linux64----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y----------------------------------------------------------------------** Select the root directory for the ClioSoft installation.Note: The installation of different releases/platforms willbe done in sub-directories of this root directory.Example: <ROOT_INSTALL_DIR>/sos_6.30_linux** Current directory : /home/eda/soft/sos_7.05.p3_linux64----------------------------------------------------------------------Root installation dir (<enter> = /home/eda/soft): /home/eda/tool/sos_7.05.p3----------------------------------------------------------------------** Please select type of installation:1 - Full installation (default)2 - Visual Design Diff (VDD) installation only----------------------------------------------------------------------Select intallation type [1|2] (<enter> = 1)? 1----------------------------------------------------------------------** Select the directory where the server definitions are maintained.Note: If this is the first time you are installing SOS,the SERVERS directory will be created.** Current directory : /home/eda/soft/sos_7.05.p3_linux64Root installation dir : /home/eda/tool/sos_7.05.p3----------------------------------------------------------------------Server definition dir (<enter> = /home/eda/tool/sos_7.05.p3/SERVERS7):----------------------------------------------------------------------** Specify a name for a SUB-directory where the release for thisplatform should be installed. The sub-directory will be createdin the root directory for the ClioSoft installation.** Current directory : /home/eda/tool/sos_7.05.p3Root installation dir : /home/eda/tool/sos_7.05.p3Server definition dir : /home/eda/tool/sos_7.05.p3/SERVERS7** Release : 7.05.p3Platform : linux64----------------------------------------------------------------------SUB-directory name to install release (<enter> = sos_7.05.p3_linux64):----------------------------------------------------------------------** Confirm installation settings.** Release : 7.05.p3Platform : linux64** Installation dir : /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64Server definition dir : /home/eda/tool/sos_7.05.p3/SERVERS7----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y** Extracting files from the tarfile '/home/eda/soft/sos_7.05.p3_linux64/cliosoft.tar'Checking of shared lib dependency for 'sos' successChecking of shared lib dependency for 'soscmd' successChecking of shared lib dependency for 'sosadmin' successChecking of shared lib dependency for 'sostclsh' successChecking of shared lib dependency for 'sospack' successChecking of shared lib dependency for 'sosd' successChecking of shared lib dependency for 'soscd' successChecking of shared lib dependency for 'soslaunch' success----------------------------------------------------------------------** ClioSoft installation complete.--------------------------------------------------------------------------------------------------------------------------------------------** The following screens will provide information about setting up** the user environment and also display the release notes.----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y----------------------------------------------------------------------** User setup----------------------------------------------------------------------All users must set the environment variable CLIOSOFT_DIR andand add $CLIOSOFT_DIR/bin to their search path.If using C shell then add the following to the .cshrc file:setenv CLIOSOFT_DIR /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64set path = ($path $CLIOSOFT_DIR/bin)If using Bourne shell then add the following to the .profile file:export CLIOSOFT_DIR=/home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64PATH=$PATH:$CLIOSOFT_DIR/binNOTE: Please remove automounter artifacts like/tmp_mntfrom the pathname.----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y----------------------------------------------------------------------** Cadence DFII setup----------------------------------------------------------------------To use SOS viaDFII with Cadence release 5.0 and higher you need to set yourshared library search path env variable to include $CLIOSOFT_DIR/lib.----------------------------------------------------------------------If using C shell then add the following to the .cshrc file:setenv LD_LIBRARY_PATH ${LD_LIBRARY_PATH}:${CLIOSOFT_DIR}/libsetenv GDM_USE_SHLIB_ENVVAR 1If using Bourne shell then add the following to the .profile file:export GDM_USE_SHLIB_ENVVAR=1LD_LIBRARY_PATH=$LD_LIBRARY_PATH:$CLIOSOFT_DIR/lib----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y----------------------------------------------------------------------** Getting a license key.----------------------------------------------------------------------To run the programs you need to get a license key which requires youto email us the hostname and hostid of the machine on which you planto run the license server.To get the hostname and hostid of the license server host:rlogin to the host machineGet the hostname by running: hostnameGet the hostid by running: $CLIOSOFT_DIR/license/lmhostidIf you plan to run the license server on THIS machine then:Host name = bogonHost id = c8f750f64607To request a license email the following information:Host nameHost idProducts you are interested inYour contact information including phone number to:support@cliosoft.com----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y----------------------------------------------------------------------Display release notes and documentation----------------------------------------------------------------------Continue [y/n] (<enter> = y)? y----------------------------------------------------------------------** Invoking release notes and documentation in web browser.----------------------------------------------------------------------** Invoking firefox to open: file:/home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/docs/help/index.htm
[eda@bogon sos_7.05.p3_linux64]$ ls -la /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/总用量 5448drwxr-xr-x 2 eda yanfa 4096 6月 26 18:44 .drwxr-xr-x 21 eda yanfa 4096 6月 26 18:44 ..-rwxr-xr-x 1 eda yanfa 1581968 2月 13 2020 cliolmd-rwxr-xr-x 1 eda yanfa 2688 2月 6 2022 license.datlrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmcksum -> ../license/lmutil-rwxr-xr-x 1 eda yanfa 1211160 2月 6 2022 lmcryptlrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmdiag -> ../license/lmutillrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmdown -> ../license/lmutil-rwxr-xr-x 1 eda yanfa 1392208 2月 13 2020 lmgrdlrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmhostid -> ../license/lmutillrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmremove -> ../license/lmutillrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmreread -> ../license/lmutillrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmstat -> ../license/lmutillrwxrwxrwx 1 eda yanfa 17 6月 26 18:44 lmswitchr -> ../license/lmutil-rwxr-xr-x 1 eda yanfa 1364872 2月 13 2020 lmutil-rwxr-xr-x 1 eda yanfa 596 2月 6 2022 readme-rwxr-xr-x 1 eda yanfa 1181 2月 13 2020 users.lst[eda@bogon sos_7.05.p3_linux64]$ cat /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.datSERVER eda ANYVENDOR cliolmd cliolmdFEATURE clio_sos cliolmd 2300.00 1-dec-2300 114514 \5A7A4A8A7FDF545EE9C8 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_viadfII cliolmd 2300.00 1-dec-2300 114514 \CA0A5A2A0D0831582315 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_viaICstudio cliolmd 2300.00 1-dec-2300 114514 \1AEA5A9A237F3FBADD7B VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_viaLaker cliolmd 2300.00 1-dec-2300 114514 \3ABABACAA30A508D5247 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_viaCD cliolmd 2300.00 1-dec-2300 114514 \3ACAAA5A358C0797656D VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_viaADS cliolmd 2300.00 1-dec-2300 114514 \2ABA5AFA14F7EC032961 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_udma cliolmd 2300.00 1-dec-2300 114514 \8ABA6A0AEB03F73D7021 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_extref cliolmd 2300.00 1-dec-2300 114514 \EA8ADADACD724733BAF4 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_grdiff cliolmd 2300.00 1-dec-2300 114514 \BA1ABAFA654398C7D6DB VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_eepack cliolmd 2300.00 1-dec-2300 114514 \DA9A0A2AB5084124C6CB VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_grdiff cliolmd 2300.00 1-dec-2300 114514 \EAEAEA1AC4EB0F6CB57C VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_vdd cliolmd 2300.00 1-dec-2300 114514 \1A6ADA5A7DC39B8E6CC0 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_alt_licid cliolmd 2300.00 1-dec-2300 114514 \8A7A8A0A3C1AB4892387 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE clio_sos_ent cliolmd 2300.00 1-dec-2300 114514 \AA6ADA1A293F8AE362B6 VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=UFEATURE FEATURE_FAILED2CHKOUT_4TEST cliolmd 2300.00 1-dec-2300 114514 \0ADACA0AA90DBB87E2FF VENDOR_STRING="Crack by EricYu \Distribution through any channel is not allowed" DUP_GROUP=U[eda@bogon sos_7.05.p3_linux64]$
[eda@bogon ~]$ cp /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.dat /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.dat.bak[eda@bogon ~]$ sed -i 's/SERVER eda ANY/SERVER bogon ANY/' /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.dat[eda@bogon ~]$ head -3 /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.datSERVER bogon ANYVENDOR cliolmd cliolmdFEATURE clio_sos cliolmd 2300.00 1-dec-2300 114514 \[eda@bogon ~]$ cd /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license[eda@bogon license]$ ./lmgrd -c license.dat -l sos_7_05.p3_license.log[eda@bogon license]$ ./lmstat -c license.dat -almstat - Copyright (c) 1989-2016 Flexera Software LLC. All Rights Reserved.Flexible License Manager status on Fri 6/26/2026 18:55License server status: 27000@bogonLicense file(s) on bogon: /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.dat:bogon: license server UP (MASTER) v11.14.0Vendor daemon status (on bogon):cliolmd: UP v11.14.0Feature usage info:Users of clio_sos: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_viadfII: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_viaICstudio: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_viaLaker: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_viaCD: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_viaADS: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_udma: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_extref: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_grdiff: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_eepack: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_grdiff: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_vdd: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_alt_licid: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of clio_sos_ent: (Total of 114514 licenses issued; Total of 0 licenses in use)Users of FEATURE_FAILED2CHKOUT_4TEST: (Error: 114514 licenses, unsupported by licensed server)[eda@bogon license]$
[eda@bogon cshrc]$ pwd/home/eda/tool/cshrc[eda@bogon cshrc]$ cat /home/eda/tool/cshrc/eda.cshrc# ================================================# EDA 统一环境变量配置# 使用方法:# source /home/eda/tool/cshrc/eda.cshrc ic231 # IC23.1 + SPECTRE231 + Calibre + SOS# source /home/eda/tool/cshrc/eda.cshrc ic618 # IC618 + SPECTRE181 + Calibre + SOS# source /home/eda/tool/cshrc/eda.cshrc calibre # 只加载 Calibre + SOS# source /home/eda/tool/cshrc/eda.cshrc sos # 只加载 SOS# ================================================# ============== 检查参数 ==============if ($#argv == 0) thenecho "用法: source eda.cshrc [ic231|ic618|calibre|sos]"echo " ic231 - 加载 IC23.1 + SPECTRE231 + Calibre2023 + SOS"echo " ic618 - 加载 IC618 + SPECTRE181 + Calibre2023 + SOS"echo " calibre - 只加载 Calibre2023 + SOS"echo " sos - 只加载 SOS"exit 1endifset version = $1# ============== SOS 公共配置（所有版本都加载） ==============setenv CLIOSOFT_DIR /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64setenv CLIOLMD_LICENSE_FILE 27000@bogon# LD_LIBRARY_PATH（处理变量不存在的情况）if ($?LD_LIBRARY_PATH) thensetenv LD_LIBRARY_PATH "${CLIOSOFT_DIR}/lib:${CLIOSOFT_DIR}/lib/64bit:${LD_LIBRARY_PATH}"elsesetenv LD_LIBRARY_PATH "${CLIOSOFT_DIR}/lib:${CLIOSOFT_DIR}/lib/64bit"endifsetenv GDM_USE_SHLIB_ENVVAR 1# ============== Calibre 公共配置 ==============setenv MGC_HOME /home/eda/tool/calibre/Calibre2023/aoi_cal_2023.2_16.9setenv CALIBRE_HOME $MGC_HOMEsetenv CALIBRE_VIRTUOSO_SKILL "${MGC_HOME}/lib"setenv MGLS_LICENSE_FILE /home/eda/tool/license/lic_Calibre2023/license.dat# ============== 根据版本加载 ==============switch ($version)case "ic231":# ---------- IC23.1 ----------setenv CDSHOME /home/eda/tool/cadence/IC23.10setenv CDS_INST_DIR $CDSHOMEsetenv CDS_LIC_FILE /home/eda/tool/license/lic_IC231/license.datsetenv CDS_SKIP_OS_CHECK_ON_STARTUP 1setenv CDS_Netlisting_Mode Analogsetenv CDS_LOAD_ENV CWD# ---------- SPECTRE231 ----------setenv SPECTRE_HOME /home/eda/tool/cadence/SPECTRE231# 合并 Licensesetenv LM_LICENSE_FILE "${CDS_LIC_FILE}:${MGLS_LICENSE_FILE}:${CLIOLMD_LICENSE_FILE}"# 路径（SOS 放最前面，避免和系统 sos 冲突）set path = ( \$CLIOSOFT_DIR/bin \$MGC_HOME/bin \$SPECTRE_HOME/tools/bin \$SPECTRE_HOME/tools/dfII/bin \$SPECTRE_HOME/tools/spectre/bin \$CDSHOME/tools/bin \$CDSHOME/tools/dfII/bin \$CDSHOME/tools/dracula/bin \$CDSHOME/tools/plot/bin \$path \)echo "========================================"echo " ✅ IC23.1 + SPECTRE231 + Calibre2023 + SOS"echo "----------------------------------------"echo " IC23.1: IC23.1-64b Hotfix 110"echo " SPECTRE: 23.10.538 Hotfix"echo " Calibre: v2023.2_16.9"echo " SOS: 7.05.p3"echo " 启动: virtuoso &"echo "========================================"breakswcase "ic618":# ---------- IC618 ----------setenv CDSHOME /home/eda/tool/cadence/IC618setenv CDS_INST_DIR $CDSHOMEsetenv CDS_LIC_FILE /home/eda/tool/license/lic_IC618/license.datsetenv CDS_SKIP_OS_CHECK_ON_STARTUP 1setenv CDS_Netlisting_Mode Analogsetenv CDS_LOAD_ENV CWD# ---------- SPECTRE181 ----------setenv SPECTRE_HOME /home/eda/tool/cadence/SPECTRE181# 合并 Licensesetenv LM_LICENSE_FILE "${CDS_LIC_FILE}:${MGLS_LICENSE_FILE}:${CLIOLMD_LICENSE_FILE}"# 路径（SOS 放最前面，避免和系统 sos 冲突）set path = ( \$CLIOSOFT_DIR/bin \$MGC_HOME/bin \$SPECTRE_HOME/tools/bin \$SPECTRE_HOME/tools/dfII/bin \$SPECTRE_HOME/tools/spectre/bin \$CDSHOME/tools/bin \$CDSHOME/tools/dfII/bin \$CDSHOME/tools/dracula/bin \$CDSHOME/tools/plot/bin \$path \)echo "========================================"echo " ✅ IC618 + SPECTRE181 + Calibre2023 + SOS"echo "----------------------------------------"echo " IC618: IC6.1.8-64b Hotfix 360"echo " SPECTRE: 18.10.287 Hotfix"echo " Calibre: v2023.2_16.9"echo " SOS: 7.05.p3"echo " 启动: virtuoso &"echo "========================================"breakswcase "calibre":# ---------- 只加载 Calibre + SOS ----------setenv LM_LICENSE_FILE "${MGLS_LICENSE_FILE}:${CLIOLMD_LICENSE_FILE}"set path = ( \$CLIOSOFT_DIR/bin \$MGC_HOME/bin \$path \)echo "========================================"echo " ✅ Calibre2023 + SOS 环境已加载"echo " 版本: Calibre v2023.2_16.9 + SOS 7.05.p3"echo "========================================"breakswcase "sos":# ---------- 只加载 SOS ----------setenv LM_LICENSE_FILE $CLIOLMD_LICENSE_FILEset path = ( \$CLIOSOFT_DIR/bin \$path \)echo "========================================"echo " ✅ SOS 7.05.p3 环境已加载"echo " License: 27000@bogon"echo " 启动: sos &"echo "========================================"breakswdefault:echo "❌ 错误: 未知版本 '$version'"echo "用法: source eda.cshrc [ic231|ic618|calibre|sos]"exit 1breakswendsw# ============== Alias 设置 ==============alias cls 'clear'alias vi 'gvim'alias g 'gedit'alias chm 'chmod -R 755'alias vir 'virtuoso &'alias cali 'calibre -gui &'alias cp_cds 'cp -r /home/eda/.cdsinit .'alias sosgui 'sos &'# ============== 其他常用设置 ==============# 显示彩色 lsalias ls 'ls --color=auto'alias ll 'ls -l --color=auto'alias la 'ls -la --color=auto'# 常用目录快捷方式alias cds 'cd /home/eda/tool/cadence'alias cals 'cd /home/eda/tool/calibre'alias soft 'cd /home/eda/soft'alias sospath 'cd /home/eda/tool/sos_7.05.p3'echo ""echo "💡 提示: 执行 cp_cds 可将 .cdsinit 复制到当前目录"echo " 这样启动 Virtuoso 时会自动加载 Calibre 集成"echo ""
## 开机自启license服务[root@bogon ~]# ls -la /etc/rc.d/rc.local-rw-r--r--. 1 root root 474 6月 17 01:17 /etc/rc.d/rc.local[root@bogon ~]# cp /etc/rc.d/rc.local /etc/rc.d/rc.local.bak[root@bogon ~]# chmod +x /etc/rc.d/rc.local[root@bogon ~]# vim /etc/rc.d/rc.local[root@bogon ~]# cat /etc/rc.d/rc.local#!/bin/bash# THIS FILE IS ADDED FOR COMPATIBILITY PURPOSES## It is highly advisable to create own systemd services or udev rules# to run scripts during boot instead of using this file.## In contrast to previous versions due to parallel execution during boot# this script will NOT be run after all other services.## Please note that you must run 'chmod +x /etc/rc.d/rc.local' to ensure# that this script will be executed during boot.touch /var/lock/subsys/localsu - eda -c "/home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/lmgrd -c /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/license.dat -l /home/eda/tool/sos_7.05.p3/sos_7.05.p3_linux64/license/sos_license.log"
