重力场模型正常高计算程序|文件格式补充说明

当前时间： 2026-04-18 12:54:21 更新时间： 2026-04-18 分类：软件教程 评论(0)

重力场模型正常高计算程序|文件格式补充说明

@

分享测绘学科相关的信息，转载请注明

来源GEOsurvey

文件格式说明

在使用『重力场模型正常高计算程序』过程中，部分用户对于批量计算的文件格式不太理解，对此，补充说明如下：

软件介绍：

几款测绘工具软件（2026.3.5）

文件格式│├── 1.未知点文件│   ├── BLH.txt(小数度/度分秒)│   ├── 高斯坐标（南方CASS格式）.txt│   ├── 大疆智图POS.csv│   └── 图新地球POS.csv└── 2.已知点文件    ├── BLH.txt(仅支持度分秒)    └── 高斯坐标.txt

1.1 未知点格式-度分秒/小数度

点名,纬度,经度,大地高（不含标题）1,38.150260868,116.03548727,30.002,38.122108492,115.45187529,30.003,38.020754014,115.29252103,30.004,38.263645595,115.532776253,30.005,38.024860882,115.580568081,30.00
点名,纬度,经度,大地高（不含标题）1,38.680260868,116.80548727,30.002,38.702108492,115.81187529,30.003,38.720754014,115.82252103,30.004,38.753645595,115.802776253,30.005,38.734860882,115.830568081,30.00

1.2 高斯坐标-南方CASS格式

点名,代码,y,x,H（不含标题）K1,aa,564890.125,2416320.398,7.553

1.3 大疆智图POS

照片名称,纬度,经度,高度,Yaw,Pitch,Roll,水平精度,垂直精度（含标题）E:/NetdiskDownload/DJI_202508021137_008_新建面状航线80/DJI_20250802114034_0001_V.JPG,36.3978967,123.6869231,109.462,-120.7,-89.9,0,0.03,0.06E:/NetdiskDownload/DJI_202508021137_008_新建面状航线80/DJI_20250802114035_0002_V.JPG,36.39789405,123.6869161,109.433,-120.2,-89.9,0,0.03,0.06E:/NetdiskDownload/DJI_202508021137_008_新建面状航线80/DJI_20250802114036_0003_V.JPG,36.39787793,123.6868876,109.431,-120.2,-89.9,0,0.03,0.06E:/NetdiskDownload/DJI_202508021137_008_新建面状航线80/DJI_20250802114037_0004_V.JPG,36.39784965,123.6868353,109.42,-120.2,-89.9,0,0.03,0.06E:/NetdiskDownload/DJI_202508021137_008_新建面状航线80/DJI_20250802114038_0005_V.JPG,36.3978121,123.6867657,109.414,59.8,-90,180,0.03,0.06

1.4 图新地球POS

名称,经度,纬度,高度,路径（含标题）DJI_20231106165555_0001_V.JPG,108.7949676,21.81946728,132.09,E:/DICM/fhy/DJI_202311061649_020_CESH/DJI_20231106165555_0001_V.JPGDJI_20231106165559_0002_V.JPG,108.7945942,21.81982714,132.07,E:/DICM/fhy/DJI_202311061649_020_CESH/DJI_20231106165559_0002_V.JPGDJI_20231106165600_0003_V.JPG,108.7945486,21.81987083,132.07,E:/DICM/fhy/DJI_202311061649_020_CESH/DJI_20231106165600_0003_V.JPGDJI_20231106165601_0004_V.JPG,108.7943819,21.82003247,132.1,E:/DICM/fhy/DJI_202311061649_020_CESH/DJI_20231106165601_0004_V.JPGDJI_20231106165603_0005_V.JPG,108.7941924,21.82021475,132.09,E:/DICM/fhy/DJI_202311061649_020_CESH/DJI_20231106165603_0005_V.JPG

2.1 已知点格式-仅支持度分秒

点名,纬度,经度,大地高,85高（不含标题）KZ01,39.3320216540,120.5614188640,-7.651,12.950

2.2 高斯坐标

点名,y,x,大地高,85高（不含标题）K1,562501.955,2418721.357,-14.792,6.371
备注：
1.以上文件格式中，均不含标题；
2.已知点校正模式下，未知点和已知点格式类型必须统一（如经纬度或高斯坐标）；
3.高斯坐标为3度带坐标，不可跨带计算。
